engine oil YAMAHA BLASTER 200 2005 Owners Manual

Engine oil ............................................5-13
Transmission oil .................................5-15
Chain ..................................................5-17
Throttle lever ......................................5-17
Fittings and fasteners .........................5-17
Lights ..................................................5-19
Switches .............................................5-19
Tires ...................................................5-21
How to measure tire pressure ............5-25
Tire wear limit .....................................5-27
OPERATION ............................................6-1
Starting a cold engine ...........................6-3
Starting a warm engine ........................6-9
Warming up ..........................................6-9
Shifting ...............................................6-11
To start out and accelerate .................6-15
To decelerate .....................................6-19
Engine break-in ..................................6-21
Parking ...............................................6-25
Parking on a slope ..............................6-27Accessories and loading ....................6-29
RIDING YOUR ATV .................................7-1
Getting to know your ATV.....................7-3
Ride with care and good
judgement ...........................................7-5
Be careful where you ride ...................7-27
Turning your ATV ...............................7-43
Climbing uphill ....................................7-47
Riding downhill ...................................7-59
Crossing a slope .................................7-63
Crossing through shallow water .........7-67
Riding over rough terrain ....................7-71
Sliding and skidding ...........................7-73
What to do if .......................................7-77
What to do ..........................................7-77
PERIODIC MAINTENANCE AND
ADJUSTMENT.........................................8-1
Owner’s manual and tool kit .................8-3
Periodic maintenance/Lubrication ........8-7
Transmission oil .................................8-17
6
7
8
5VM-9-62-01 3/12/04 2:33 PM Page 13

4-3
EBU00043
Indicator lights
EBU01274
Oil level warning light “7”
This light comes on when the oil level is low.
The light circuit can be checked by the following
procedure.
cC
Always make sure there is enough engine oil
before starting the engine.
1
1. Oil level warning light “7”1. Témoin d’avertissement du niveau d’huile “7”1. Luz de aviso del nivel del aceite “7”
5VM-9-62-02 3/12/04 4:13 PM Page 4

4-5
EBU00757
Oil level warning light checking method
Start the engine.
Wait a few seconds.
Engine oil level and
electrical circuit are OK.Supply engine oil.
Oil level warning light
does not come on
(see NOTE).
Ask a Yamaha dealer to
inspect the electrical circuit.
NOTE:
If the main switch is turned off after the oil level
warning light goes off and the engine is immedi-
ately started again, the oil level warning light
may not come on. This does not indicate a cir-
cuit failure.
Turn the main switch to
“ON” and the engine
stop switch to“RUN”.
Oil level warning
light comes on.
The oil level warning
light stays on.The oil level warning light
goes off.
5VM-9-62-02 3/12/04 4:13 PM Page 6

5-1
EBU00113
PRE-OPERATION CHECKS
Before using this machine, check the following points:
ITEM ROUTINE PAGE
Brakes9Check operation, free play, fluid level and fluid leakage. 5-5–5-7
9Fill with DOT 4 brake fluid if necessary. 8-55–8-63
Clutch9Check operation, condition and lever free play. 8-71
Parking brake9Check operation, condition and cable free play. 8-65–8-67
Fuel 9Check fuel level.
9Fill with fuel if necessary.5-9–5-11
Transmission oil9Check oil level.
9Fill with oil if necessary.5-15, 8-17–8-23
2-cycle engine oil9Check oil level.
9Fill with oil if necessary.5-13
Drive chain9Check chain slack and condition.
9Adjust if necessary.5-17, 8-73–8-79
Throttle9Check for proper throttle cable operation. 5-17, 8-53
Wheels and tires9Check tire pressure, wear and damage. 5-21–5-27, 8-87
Fittings and fasteners9Check all fittings and fasteners. 5-17
Lights and switches9Check for proper operation. 5-19, 8-89–8-99
5VM-9-62-02 3/12/04 4:13 PM Page 38

5-13
EBU00134
Engine oil
Make sure the engine oil is at the specified level.
Add oil as necessary (see page 10-2).
NOTE:
Be sure to push the cap into the filler neck until it
is properly seated.
q
1. Oil tank filler cap1. Bouchon de remplissage de réservoir d’huile1. Tapa de llenado de depósito de aceite
Recommended oil:
Air-cooled 2-stroke engine oil
Oil quantity:
Total amount:
1.3 L
5VM-9-62-02 3/12/04 4:13 PM Page 50

EBU08371
Transmission oil
Transmission oil measurement
1. Place the machine on a level surface.
2. Warm up the engine for several minutes,
and stop it.
3. Check the oil level through the level window
located at the right side crankcase cover.
NOTE:
Wait a few minutes until the oil level settles
before checking.
4. The oil level should be between the mini-
mum and maximum marks. If the level is
low, add the recommended oil to raise it to
the proper level.
1
2
3
1
1. Level window
2. Maximum level mark 3. Minimum level mark
1. Hublot de contrôle du niveau d’huile
2. Repère de niveau maximum 3. Repère de niveauminimum
1. Mirilla del nivel
2. Marca de máximo 3. Marca de mínimo
8-17
5VM-9-62-05 3/12/04 4:15 PM Page 18

q
1. Drain bolt1. Boulon de vidange1. Perno de drenaje
8-19
Transmission oil replacement
1. Place the machine on a level surface.
2. Warm up the engine for several minutes,
and stop it.
3. Place a container under the engine to col-
lect the used oil.
4. Remove the oil filler cap and drain bolt to
drain the oil.
5. Install the drain bolt and tighten it to the
specified torque.
6. Fill the engine with the recommended oil
and install the filler cap.
1
1. Transmission oil filler cap1. Bouchon de remplissage d’huile1. Tapón de llenado del aceite
Tightening torque
Drain bolt:
20 Nm (2.0 m0kgf)
5VM-9-62-05 3/12/04 4:15 PM Page 20

8-23
7. Start the engine and warm it up for a few
minutes. While warming up, check for oil
leakage. If oil leakage is found, stop the
engine immediately, and check for the
cause.
8. Check the oil level.
5VM-9-62-05 3/12/04 4:15 PM Page 24

8-79
3. Thoroughly lubricate the drive chain with a
special O-ring chain lubricant.
cC
Do not use engine oil or any other lubricants
for the drive chain, as they may contain sub-
stances that could damage the O-rings.
5VM-9-62-05 3/12/04 4:15 PM Page 80

8-81
EBU00570
Cable inspection and lubrication
w
Inspect cables frequently and replace if dam-
aged. Corrosion can result when the outer
covering of control cables becomes dam-
aged. Cables can also become frayed or
kinked. Operation of controls could be
restricted, which could cause an accident or
injury.
Lubricate the inner cables and the cable ends. If
the cables do not operate smoothly, ask a
Yamaha dealer to replace them.
Recommended lubricant:
Engine oil
5VM-9-62-05 3/12/04 4:15 PM Page 82
