torque YAMAHA BREEZE 2002 Notices Demploi (in French)

4-35
4. Tighten the locknut to the specified torque.
cC
Always tighten the locknut to the specified
torque.
w
This shock absorber contains highly pres-
surized nitrogen gas. If the shock absorber
is damaged, it could explode causing injury
or property damage. Shock absorber cylin-
der damage could also result in poor han-
dling which could cause an accident.
8Do not tamper with or attempt to open the
cylinder assembly.
8Do not subject the shock absorber to an
open flame or other high heat.
8Do not deform or damage the cylinder in
any way.
8Do not dispose of a damaged or worn out
shock absorber yourself. Take the unit to a
Yamaha dealer.
Tightening torque:
55 Nm (5.5 m0kg)
5KJ-62 (4~5 shou) 4/23/01 3:04 PM Page 36

5-17
EBU00498
Chain
Check the general condition of the chain and
check the chain slack before every ride.
Lubricate and adjust the chain as necessary.
(See pages 8-61 ~ 8-67 for details.)
EBU00151
Throttle lever
Check to see that the throttle lever operates cor-
rectly. It must open smoothly and spring back to
idle position when released. Repair as neces-
sary for proper operation.
EBU00152
Fittings and Fasteners
Always check the tightness of chassis fittings
and fasteners before a ride. Take the machine
to a Yamaha dealer or refer to the Service
Manual for correct tightening torque.
5KJ-62 (4~5 shou) 4/23/01 3:04 PM Page 54

8-3
EBU00258
Owner’s manual and tool kit
You are recommended to put this owner’s man-
ual and low-pressure tire gauge in the vinyl bag
and always carry them along with the owner’s
tool kit under the seat. The service information
included in this manual is intended to provide
you, the owner, with the necessary information
for completing your own preventive maintenance
and minor repairs. The tools provided in the
Owner’s tool kit are sufficient for this purpose,
except that a torque wrench is also necessary to
properly tighten nuts and bolts.
NOTE:
If you do not have a torque wrench available
during a service operation requiring one, take
your machine to a Yamaha dealer to check the
torque settings and adjust them as necessary.
we
q
1. Owner’s manual
2. Low-pressure tire gauge
3. Tool kit
1. Manuel du propriétaire
2. Manomètre basse pression pour pneus
3. Trousse à outils
1. Manual del propietario
2. Manómetro de baja presión
3. Juego de herramientas
5KJ-62 (8 shou) 4/23/01 3:08 PM Page 4

8-15
Transmission oil replacement
1. Place the machine on a level place.
2. Warm up the engine for several minutes,
and stop it.
3. Place a container under the engine.
4. Remove filler cap and drain bolt to drain the
oil.
5. Install the drain bolt and tighten to specifica-
tion.
6. Fill the engine with oil and install the filler
cap.
q
1. Drain bolt1. Boulon de vidange1. Perno de drenaje
Tightening torque
Drain bolt:
20 Nm (2.0 m0kg)
5KJ-62 (8 shou) 4/23/01 3:08 PM Page 16

8-23
Before installing the spark plug, measure the
electrode gap with a feeler gauge and adjust to
specification.
When installing the spark plug, always clean the
gasket surface and use a new gasket. Wipe off
any grime from the threads and tighten to the
specified torque.
a
a. Spark plug gapa. Écartement des électrodesa. Separación entre electrodos de la bujía
Spark plug gap:
0.7 ~ 0.8 mm
Tightening torque:
Spark plug:
25 Nm (2.5 m0kg)
5KJ-62 (8 shou) 4/23/01 3:08 PM Page 24

1. Float 2. Needle valve 3. Main jet1. Flotteur 2. Pointeau 3. Gicleur principal1. Flotador 2. Válvula de aguja 3. Surtidor principal
8-41
8. Remove the float chamber.
9. Remove the float and needle valve.
10. Change the main jet and the jet needle clip
position. (see page 8-33)
NOTE:
Optional main jet can be obtained at a Yamaha
dealer.
Assembly
1. Reassemble the needle valve, float and float
chamber.
2. Reassemble the throttle valve.
3. Install the carburetor cap and tighten it
securely to the specified torque.
q
q
w
e
1. Float chamber1. Cuve à flotteur1. Cuba
Carburetor cap tightening torque:
4 Nm (0.4 m0kg)
5KJ-62 (8 shou) 4/23/01 3:08 PM Page 42

8-43
4. Install the carburetor and tighten the joint
screws.
5. Install the securing plate. Match one of the
projections on the carburetor cap with one
of the indents on the securing plate.
cC
If the securing plate does not match a pro-
jection, tighten the carburetor cap until they
align. Do not loosen.
6. Tighten the securing plate screw to the
specified torque.
7. Connect the fuel hose and oil delivery hose.
Tightening torque:
3.5 Nm (0.35 m0kg)
5KJ-62 (8 shou) 4/23/01 3:08 PM Page 44

8-73
EBU00370
Steering shaft lubrication
Lubricate the pivot points. Use a grease gun.
EBU00373
Wheel removal
1. Elevate the wheel by placing a suitable
stand under the frame.
2. Remove the nuts from the wheel.
3. Remove the wheel assembly.
EBU00740
Wheel installation
When installing the wheel, reverse the removal
procedure.
Tighten the wheel nuts to the specified torque.
FrontAvantDelantera
RearArrièreTrasera
Recommended lubricant:
Lithium soap base grease
Tightening torque:
Wheel nut:
Front: 45 Nm (4.5 m0kg)
Rear: 45 Nm (4.5 m0kg)
5KJ-62 (8 shou) 4/23/01 3:08 PM Page 74

11-1
EBU00429
HOW TO USE THE CONVERSION TABLE
All specification data in this manual are listed in
SI and METRIC UNITS.
Use this table to convert METRIC unit data to
IMPERIAL unit data.
Ex.
METRIC MULTIPLIER IMPERIAL
** mm×0.03937 = ** in
2 mm×0.03937 = 0.08 in
CONVERSION TABLE
METRIC TO IMPERIAL
Metric unit Multiplier Imperial unit
m•kg 7.233 ft•lb
m•kg 86.794 in•lb
Torque
m•kg 0.0723 ft•lb
cm•kg 0.8679 in•lb
kg 2.205 lb
Weight
g
0.03527 oz
Speed km/hr 0.6214 mph
km 0.6214 mi
m 3.281 ft
Distance m 1.094 yd
cm 0.3937 in
mm 0.03937 in
cc (cm
3) 0.03527 oz (IMP liq.)
Volume/ cc (cm3) 0.06102 cu•in
Capacity lt (liter) 0.8799 qt (IMP liq.)
lt (liter) 0.2199 gal (IMP liq.)
kg/mm 55.997 lb/in
Misc. kg/cm
214.2234 psi (lb/in2)Centigrade (°C)9/5 + 32 Fahrenheit (°F)
