engine YAMAHA BREEZE 2002 User Guide

4-15
EBU00565
Speed limiter
The speed limiter keeps the throttle from fully
opening, even when the throttle lever is pushed
to the maximum. Screwing in the adjuster limits
the maximum engine power available and
decreases the maximum speed of the ATV.
w
Improper adjustment of the speed limiter and
throttle could cause throttle cable damage or
improper throttle operation. You could lose
control, have an accident or be injured. Do
not turn the speed adjuster out more than 12
mm or the throttle cable could be damaged.
Always make sure the throttle lever free play
is adjusted to 4 ~ 6 mm. See page 8-47.
wq a
1. Locknut 2. Adjuster a. 12 mm1. Contre-écrou 2. Dispositif de réglage1. Contratuerca 2. Ajustador
5KJ-62 (4~5 shou) 4/23/01 3:04 PM Page 16

4-19
EBU00071
Rear brake pedal
The brake pedal is located on the right side of
the machine. Push down on the pedal to apply
the rear brake.
EBU00077
Parking brake
Use the parking brake when you have to start
the engine or park the machine, especially on a
slope. Apply the front brake lever while pushing
the button, then push down the lock plate to
apply the parking brake. Squeeze the front
brake lever to release the parking brake.
q
qw
1. Rear brake pedal1. Pédale de frein arrière1. Pedal del freno trasero
1. Button 2. Lock plate
1. Bouton 2. Plaque de verrouillage1. Botón 2. Placa de bloqueo
5KJ-62 (4~5 shou) 4/23/01 3:04 PM Page 20

4-21
w
8Always set the parking brake before start-
ing the engine. The ATV could start mov-
ing unexpectedly if the parking brake is
not applied. This could cause loss of con-
trol or a collision.
8Always be sure you have released the
parking brake before you begin to ride.
The brake could overheat if you ride the
ATV without releasing the parking brake.
You could lose braking performance
which could cause an accident. You could
also wear out the brakes prematurely.
5KJ-62 (4~5 shou) 4/23/01 3:04 PM Page 22

4-23
EBU00082
Shift pedal
This machine is equipped with a constant-mesh
6-speed transmission. The shift pedal is located
on the left side of the engine and is used in com-
bination with the clutch when shifting.
EBU00089
Kick starter
Rotate the kick starter away from the engine.
Push the starter down lightly with your foot until
the gears engage, then kick smoothly and force-
fully to start the engine. This model has a prima-
ry-coupled kick starter so the engine can be
started in any gear if the clutch is disengaged.
However, shifting to neutral before starting is
recommended.
q
6
5
4
3
2
N
1
q
1. Shift pedal N. Neutral1. Pédale de sélection N. Point mort1. Pedal del cambio N. Punto muerto
1. Kick starter
1. Pédale de kick1. Pedal de arranque
5KJ-62 (4~5 shou) 4/23/01 3:04 PM Page 24

4-25
EBU00092
Fuel tank cap
Remove the fuel tank cap by turning it counter-
clockwise.
EBU00093
Fuel cock
The fuel cock supplies fuel from the fuel tank to
the carburetor.
The fuel cock has three positions.
OFF: With the lever in this position fuel will not
flow. Always turn the lever to this position
when the engine is not running.
ON: With the lever in this position, fuel flows
to the carburetor. Normal riding is done
with the lever in this position.
RES: This indicates reserve. If you run out of
fuel while riding, turn the lever to this
position. THEN FILL THE FUEL TANK
AT THE FIRST OPPORTUNITY. After
refuelling, return the fuel cock lever to the
“ON” position.
q
RES
OFF
ON
1. Fuel tank cap1. Bouchon de réservoir de carburant1. Tapón del depósito de combustible
5KJ-62 (4~5 shou) 4/23/01 3:04 PM Page 26

4-27
EBU00094
Starter (choke)
Starting a cold engine requires a richer air-fuel
mixture. A separate starter circuit supplies this
mixture.
Move in direction ato turn on the starter
(choke).
Move in direction bto turn off the starter
(choke).
Refer to “Starting a cold engine” for proper oper-
ation. (See page 6-3.)
q
ab
1. Starter (choke)1. Starter (choke)1. Starter (choke)
5KJ-62 (4~5 shou) 4/23/01 3:04 PM Page 28

5-1
EBU00113
PRE-OPERATION CHECKS
Before using this machine, check the following points:
ITEM ROUTINE PAGE
Front brake9Check operation, condition and free play.
5-5~ 5-7, 8-49 ~ 8-53
9Adjust if necessary.
Rear brake9Check operation and brake pad. 5-5 ~ 5-7, 8-49
Clutch9Check operation, condition and lever free play. 8-59
Parking brake9Check operation, condition and cable free play. 8-55
Fuel 9Check fuel level.
9Fill with fuel if necessary.5-9 ~ 5-11
Transmission oil9Check oil level.
9Fill with oil if necessary.5-15, 8-13 ~ 8-19
Engine oil9Check oil level.
9Fill with oil if necessary.5-13
Drive chain9Check chain slack and condition.
9Adjust if necessary.5-17, 8-61 ~ 8-67
Throttle9Check for proper throttle cable operation. 5-17, 8-47
Wheels and tires9Check tire pressure, wear and damage. 5-21 ~ 5-27, 8-73
Fittings and Fasteners9Check all fittings and fasteners. 5-17
Lights9Check for proper operation. 5-19, 8-75 ~ 8-81
5KJ-62 (4~5 shou) 4/23/01 3:04 PM Page 38

5-11
w
8Do not overfill the fuel tank. Fuel expands
when it heats up. If the fuel tank is over-
filled, fuel could spill out due to heat from
the engine or the sun.
8Be careful not to spill fuel, especially on
the engine or exhaust pipe which can
cause a fire and severe injury. Wipe up
any spilled fuel immediately.
8Do not refuel right after the engine has
been running and is still very hot.
8Be sure the fuel tank cap is closed secure-
ly.
5KJ-62 (4~5 shou) 4/23/01 3:04 PM Page 48

5-13
EBU00134
Engine oil
Make sure the engine oil is at the specified level.
Add oil as necessary (see page 10-2).
NOTE:
Be sure to push the cap into the filler neck until it
is properly seated.
q
1. Oil tank filler cap1. Bouchon de remplissage de réservoir d’huile1. Tapa de llenado de depósito de aceite
Recommended oil:
Air-cooled 2-stroke engine oil
Oil quantity:
Total amount:
1.3 L
5KJ-62 (4~5 shou) 4/23/01 3:04 PM Page 50

5-15
EBU00490
Transmission oil
Make sure the transmission oil is at the specified
level. Add oil as necessary. (See pages 8-13 ~
8-19.)
cC
Be sure to use motor oils that do not contain
anti-friction modifiers. Passenger car motor
oils (often labeled “Energy Conserving”)
contain anti-friction additives which will
cause clutch and/or starter clutch slippage,
resulting in reduced component life and poor
engine performance.
Recommended oil:
SAE 10W30
Recommended oil classification:
API Service SE, SF, SG type or higher
Oil quantity:
Total amount:
0.7 L
Periodic oil change:
0.65 L
5KJ-62 (4~5 shou) 4/23/01 3:04 PM Page 52
