EBU00801
IMPORTANT MANUAL
INFORMATION
FAILURE TO FOLLOW THE WARNINGS CON-
TAINED IN THIS MANUAL CAN RESULT IN
SERIOUS INJURY OR DEATH.
Particularly important information is distinguished
in this manual by the following notations:QThe Safety Alert Symbol means ATTENTION!
BECOME ALERT! YOUR SAFETY IS INVOLVED!wFailure to follow WARNING instructions couldresult in severe injury or death
to the machine
operator, a bystander or a person inspecting or
repairing the machine.
cCA CAUTION indicates special precautions that
must be taken to avoid damage to the machine.NOTE:A NOTE provides key information to make proce-
dures easier or clearer.
5VJ-9-60-01 3/26/02 9:18 PM Page 6
