PERIODIC MAINTENANCE AND
ADJUSTMENT .........................................8-1
Owner’s manual and tool kit .................8-3
Periodic maintenance/Lubrication ........8-7
Engine oil ............................................8-13
Transmission oil .................................8-21
Spark plug inspection .........................8-27
Engine and V-belt compartment
air filter element cleaning .................8-31
Idle speed adjustment ........................8-41
Valve clearance adjustment ...............8-43
Throttle lever adjustment ....................8-43
Front and rear brake shoe
inspection .........................................8-45
Front brake lever free play
adjustment ........................................8-47
Rear brake adjustment .......................8-55
Drive chain slack check ......................8-57
Drive chain slack adjustment ..............8-59Lubricating and drive chain ................8-63
Draining the V-belt compartment ........8-65
Cable inspection and lubrication ........8-67
Brake lever lubrication ........................8-69
Knuckle shaft, lower arms and
steering shaft lubrication ..................8-69
Wheel removal ...................................8-71
Wheel installation ...............................8-71
Battery ................................................8-73
Replenishing the battery fluid .............8-77
Fuse replacement ...............................8-81
Replacing the headlight bulb ..............8-83
Tail/brake light bulb replacement .......8-87
Headlight beam adjustment ................8-89
Troubleshooting ..................................8-91
Troubleshooting chart .........................8-958
5VJ-9-61-01 3/14/03 11:48 PM Page 14

4-9
EBU00063
Throttle lever
Once the engine is running, movement of the
throttle lever will increase the engine speed.
Regulate the speed of the machine by varying
the throttle position. Because the throttle is
spring-loaded, the machine will decelerate, and
the engine will return to an idle any time the
hand is removed from the throttle lever.
Before starting the engine, check the throttle to
be sure it is operating smoothly. Make sure it
returns to the idle position as soon as the lever
is released.
w
Malfunction of the throttle could make it diffi-
cult to speed up or slow down when you
need to. This could cause an accident.
Check the operation of the throttle lever
before you start the engine. If the throttle
does not work smoothly, check for the
cause. Correct the problem before riding the
ATV or consult a Yamaha dealer.
q
1. Throttle lever1. Levier d’accélérateur1. Palanca del aceleración
5VJ-9-61-04 3/17/03 4:47 PM Page 10

5-1
EBU00113
PRE-OPERATION CHECKS
Before using this machine, check the following points:
ITEM ROUTINE PAGE
Brakes• Check operation, condition and free play. 5-5 – 5-7,
• Adjust if necessary. 8-45 – 8-55
Fuel • Check fuel level.
• Fill with fuel if necessary.5-7 – 5-11
Engine oil and• Check oil level. 5-11 – 5-15,
transmission oil• Fill with oil if necessary. 8-13 – 8-25
Drive chain• Check chain slack and condition.
5-15, 8-57 – 8-63
• Adjust if necessary.
Throttle• Check for proper throttle cable operation. 5-15
Wheels and tires• Check tire pressure, wear and damage. 5-19 – 5-25, 8-71
Fittings and fasteners• Check all fittings and fasteners. 5-15
Battery• Check fluid level.
5-17, 8-73 – 8-79
• Fill with distilled water if necessary.
Lights and switches• Check for proper operation. 5-17, 8-83 – 8-87
5VJ-9-61-05 3/17/03 4:50 PM Page 2

5-15
EBU00498
Chain
Check the general condition of the chain and
check the chain slack before every ride.
Lubricate and adjust the chain as necessary.
(See pages 8-53–8-59 for details.)
EBU01083
Throttle lever
Check to see that the throttle lever operates cor-
rectly. It must open smoothly and spring back to
the idle position when released. Have a Yamaha
dealer repair as necessary for proper operation.Engine oil quantity:
Periodic oil change:
1.25 L
Total amount:
1.45 L
Transmission oil quantity:
Total amount:
0.6 L
5VJ-9-61-05 3/17/03 4:50 PM Page 16

6-11
EBU00180
Starting a warm engine
To start a warm engine, refer to the “Starting a
cold engine” section. The starter (choke) should
not be used. The throttle should be opened
slightly.
EBU00182
Warming up
To get maximum engine life, always warm up
the engine before starting off. Never accelerate
hard with a cold engine! To see whether or not
the engine is warm, check if it responds to the
throttle normally with the starter (choke) turned
off.
5VJ-9-61-06 3/17/03 4:51 PM Page 12

8-7
EBU00262
PERIODIC MAINTENANCE/LUBRICATION
INITIAL EVERY
ITEM ROUTINE
13661
monthmonths months monthsyear
Valves*• Check valve clearance.
1111
• Adjust if necessary.
• Check condition.
Spark plug• Adjust gap and clean.11111
• Replace if necessary.
Air filter element
• Clean. Every 20–40 hours
(for engine and V-belt
• Replace if necessary. (more often in wet or dusty areas)
compartment)
Carburetor*• Check idle speed/starter operation.
1111
• Adjust if necessary.
Cylinder head cover• Check breather hose for cracks or damage.
111
breather system*• Replace if necessary.
• Check leakage.
Exhaust system*• Retighten if necessary.111
• Replace gasket if necessary.
Fuel line*• Check fuel hose for cracks or damage.
111
• Replace if necessary.
Engine oil• Replace (warm engine before draining).1111
Oil strainer*• Clean.
111
• Replace if necessary.
Drive chain• Check and adjust slack/alignment/clean/lube.11111
Transmission oil• Check oil level/oil leakage.
11
• Replace every 12 months.
5VJ-9-61-08 3/17/03 4:52 PM Page 8-8

8-13
EBU00896
Engine oil
Engine oil level measurement
1. Place the machine on a level surface.
2. Warm up the engine for several minutes and
stop it.
3. Remove the dipstick and wipe it off with a
clean rag. Insert the dipstick in the filler hole
without screwing it in.
NOTE:
Wait a few minutes until the oil level settles
before checking.
4. Remove the dipstick and inspect the oil level.
5. The oil level should be between the maximum
and minimum marks. If the level is low, add oil
to raise it to the proper level.
qw
e
1. Dipstick
2. Maximum level mark 3. Minimum level mark
1. Jauge
2. Repère de niveau maximum 3. Repère de niveau minimum
1. Varilla de medición
2. Marca de máximo 3. Marca de mínimo
5VJ-9-61-08 3/17/03 4:52 PM Page 8-14

8-19
cC
Be sure no foreign material enters the
crankcase.
9. Warm up the engine for several minutes at
idle speed. Check for oil leakage while warm-
ing up.
cC
If oil leakage is found, stop the engine imme-
diately and check for the cause.
Recommended oil:
See page 10-2.
Oil quantity:
Periodic oil change
1.25 L
Total amount:
1.45 L
5VJ-9-61-08 3/17/03 4:52 PM Page 8-20

8-25
cC
Be sure no foreign material enters the
crankcase.
6. Start the engine and warm up for a few min-
utes. While warming up, check for oil leakage.
If oil leakage is found, stop the engine imme-
diately and check for the cause.
7. Check the oil level.Recommended oil:
See page 10-2
Oil quantity:
Total amount:
0.6 L (0.53 Imp qt, 0.63 US qt)
5VJ-9-61-08 3/17/03 4:52 PM Page 8-26

8-31
EBU00959
Engine and V-belt case air filter element
cleaning
Both air filter elements should be cleaned at the
specified intervals in the periodic maintenance
chart.
Engine air filter element
NOTE:
There is a check hose at the bottom of the air fil-
ter case. If dust or water collects in this hose,
empty the hose and clean the air filter element
and air filter case.
1. Remove the seat.
2. Remove the breather hose and then loosen
the clamp screw.
3. Remove the air filter case cover.
q
w
e
q
1. Check hose1. Flexible de contrôle1. Manguito de comprobación
1. Air filter case cover
2. Breather hose 3. Clamp
1. Cache du boîtier de filtre à air
2. Reniflard 3. Bride
1. Tapa de la caja del filtro de aire
2. Tubo de ventilación 3. Abrazadera
