weight YAMAHA BREEZE 2004 Notices Demploi (in French)

2-7
8Never operate on excessively rough, slippery
or loose terrain until you have learned and
practiced the skills necessary to control the
ATV on such terrain. Always be especially
cautious on these kinds of terrain.
8Always follow proper procedures for turning
as described in this manual. Practice turning
at low speeds before attempting to turn at
faster speeds. Do not turn at excessive
speed.
8Never operate the ATV on hills too steep for
the ATV or for your abilities. Practice on
smaller hills before attempting larger hills.
8Always follow proper procedures for climbing
hills as described in this manual. Check the
terrain carefully before you start up any hill.
Never climb hills with excessively slippery or
loose surfaces. Shift your weight forward.
Never open the throttle suddenly. Never go
over the top of a hill at high speed.
5VJ-9-61-02 3/14/03 11:49 PM Page 8

2-9
8Always follow proper procedures for going
down hills and for braking on hills as
described in this manual. Check the terrain
carefully before you start down any hill. Shift
your weight backward. Never go down a hill at
high speed. Avoid going down a hill at an
angle that would cause the vehicle to lean
sharply to one side. Go straight down the hill
where possible.
8Always follow proper procedures for crossing
the side of a hill as described in this manual.
Avoid hills with excessively slippery or loose
surfaces. Shift your weight to the uphill side of
the ATV. Never attempt to turn the ATV
around on any hill until you have mastered
the turning technique described in this manual
on level ground. Avoid crossing the side of a
steep hill if possible.
5VJ-9-61-02 3/14/03 11:49 PM Page 10

6-31
EBU00226
Loading
As originally equipped, this ATV is not designed
to carry cargo or tow a trailer. If you choose to
add accessories so that you can carry cargo or
tow a trailer, you must use common sense and
good judgement. Keep the following points in
mind:
8Never exceed the weight limits shown. An
overloaded ATV can be unstable.
MAXIMUM LOADING LIMIT
Vehicle loading limit (total weight of
rider, cargo and accessories):
100 kg
5VJ-9-61-06 3/17/03 4:51 PM Page 32

6-33
8Load cargo on the carriers as close to the
center of the vehicle as possible. Put cargo at
the rear of the front carrier and at the front of
the rear carrier. Center the load from side to
side.
8Tie down cargo securely to the carriers. Make
sure cargo in the trailer cannot move around.
A shifting load can cause an accident.
8Make sure the load does not interfere with
controls or your ability to see where you are
going.
8Ride more slowly than you would without a
load. The more weight you carry, the slower
you should go.
8Allow more braking distance. A heavier vehi-
cle takes longer to stop.
8Avoid making sharp turns unless at very slow
speeds.
5VJ-9-61-06 3/17/03 4:51 PM Page 34

6-35
8Avoid hills and rough terrain. Choose terrain
carefully. Added weight affects the stability
and handling of the ATV.
w
Never exceed the stated load capacity for
this ATV. Overloading this ATV or carrying
or towing cargo improperly could cause
changes in vehicle handling which could
lead to an accident.
Cargo should be properly distributed and
securely attached. Reduce speed when car-
rying cargo or pulling a trailer. Allow greater
distance for braking.
5VJ-9-61-06 3/17/03 4:51 PM Page 36

7-17
Speed limiter
For riders inexperienced with this model, this
model is equipped with a speed limiter in the
throttle lever housing. The speed limiter limits
the power and top speed of the machine.
Turning the screw in decreases top speed, and
turning it out increases top speed.
Loading and accessories
Use extra caution when riding the machine with
additional loads, such as accessories or cargo.
The machine’s handling may be adversely
affected. Reduce your speed when adding addi-
tional loads.
q w
1. Adjusting screw 2. Locknut1. Vis de réglage 2. Contre-écrou1. Tornillo de ajuste 2. Contratuerca
MAXIMUM LOADING LIMIT
Vehicle loading limit
(total weight of cargo, rider and
accessories):
100 kg
5VJ-9-61-07 3/14/03 11:53 PM Page 18

7-43
As you approach a curve, slow down and begin
to turn the handlebars in the desired direction.
As you do so, put your weight on the footboard
to the outside of the turn (opposite your desired
direction) and lean your upper body into the
turn. Use the throttle to maintain an even speed
through the turn. This maneuver will let the
wheel on the inside of the turn slip slightly,
allowing the ATV to make the turn properly.
This procedure should be practiced at slow
speed many times in a large off-road area with
no obstacles. If an incorrect technique is used,
your ATV may continue to go straight. If the ATV
doesn’t turn, come to a stop and then practice
the procedure again. If the riding surface is slip-
pery or loose, it may help to position more of
your weight over the front wheels by moving for-
ward on the seat.
Once you have learned this technique you
should be able to perform it at higher speeds or
in tighter curves.
1. Lean towards inside of turn.
2. Support your weight on the outer footrest.
1. Se pencher vers l’intérieur du virage.
2. S’appuyer sur le repose-pied externe.
1. Inclínese hacia el interior del giro.
2. Descanse su peso en el descansapie externo.
q
w
5VJ-9-61-07 3/14/03 11:53 PM Page 44

7-47
w
Never operate the ATV on hills too steep for
the ATV or for your abilities. The vehicle can
overturn more easily on extremely steep hills
than on level surfaces or small hills. Practice
on smaller hills before attempting large hills.
It is important when climbing a hill to make sure
that your weight is transferred forward on the
ATV. This can be accomplished by leaning for-
ward and, on steeper inclines, standing on the
footboards and leaning forward over the handle-
bars.
5VJ-9-61-07 3/14/03 11:53 PM Page 48

7-49
w
8Always follow proper procedures for
climbing hills as described in this Owner’s
Manual.
8Always check the terrain carefully before
you start up any hill.
8Never climb hills with excessively slippery
or loose surfaces.
8Shift your weight forward.
8Never open the throttle suddenly. The ATV
could flip over backwards.
8Never go over the top of any hill at high
speed. An obstacle, a sharp drop, or
another vehicle or person could be on the
other side of the hill.OK
5VJ-9-61-07 3/14/03 11:53 PM Page 50

7-51
If you are climbing a hill and you find that you
have not properly judged your ability to make it
to the top, you should turn the ATV around while
you still have forward motion (provided you have
the room to do so) and go down the hill.
w
Never attempt to turn the ATV around on any
hill until you have mastered the turning tech-
nique as described in the Owner’s Manual on
level ground. Be very careful when turning
on any hill.
Avoid crossing the side of a steep hill if pos-
sible.
When crossing the side of a hill:
8Always follow proper procedures as
described in the Owner’s Manual.
8Avoid hills with excessively slippery or
loose surfaces.
8Shift your weight to the uphill side of the
ATV.
OK
5VJ-9-61-07 3/14/03 11:53 PM Page 52
