YAMAHA EX DELUXE 2021 Owners Manual

Specifications
84
EJU45442
Specifications
Watercraft capacity:
Maximum people on board:3 person
Maximum load capacity: 225 kg (496 lb)
Dimensions and weight:
Length:
3.13 m (123.2 in) (EX)
3.14 m (123.6 in) (EX SPORT / EX DELUXE /
EX LIMITED)
Width: 1.13 m (44.5 in)
Height: 1.15 m (45.3 in)
Dry weight:
262 kg (578 lb) (EX)
265 kg (584 lb) (EX SPORT)
272 kg (600 lb) (EX DELUXE)
273 kg (602 lb) (EX LIMITED)
Performance:
Maximum output (according to ISO 8665/SAE
J1228):74.6 kW at 7300 r/min
Maximum fuel consumption: 29.2 L/h (7.7 US gal/h, 6.4 Imp.gal/h)
Cruising range at full throttle:
1.71 hour
Trolling speed: 1500 ±100 r/min
Engine:
Engine type:
Liquid cooled 4-stroke, DOHC
Number of cylinders: 3
Engine displacement: 1049 cm³
Bore × stroke:
82.0 × 66.2 mm (3.23 × 2.61 in)
Compression ratio: 11.0 : 1
Valve clearance-intake (cold): 0.15–0.22 mm (0.0059–0.0087 in)
Valve clearance-exhaust (cold):
0.26–0.32 mm (0.0102–0.0126 in)
Lubrication system: Dry sump Cooling system:
Water
Starting system: Electric
Ignition system:
T.C.I.
Spark plug (NGK): CR9EB
Spark plug gap: 0.7–0.8 mm (0.028–0.031 in)
Battery capacity:
12 V, 18 Ah
Battery type: YTX20L-BS
Charging system: Flywheel magneto
Drive unit:
Propulsion system:
Jet pump
Jet pump type: Axial flow, single stage
Impeller rotation: Counterclockwise
Jet thrust nozzle angle:
24+24 °
Fuel and oil:
Recommended fuel:Regular unleaded gasoline
Minimum octane rating (PON):
86
Minimum octane rating (RON): 90
Recommended engine oil: YAMALUBE 4W or 4-stroke motor oil
Recommended engine oil type SAE: SAE 10W-30, 10W-40, 20W-40, 20W-50
Recommended engine oil grade API: API SG, SH, SJ, SL
Fuel tank total capacity: 50 L (13.2 US gal, 11.0 Imp.gal)
Engine oil quantity with oil filter replacement:
3.4 L (3.59 US qt, 2.99 Imp.qt)
Engine oil quantity without oil filter replacement: 3.2 L (3.38 US qt, 2.82 Imp.qt)
UF3Y74E0.book Page 84 Monday, June 22, 2020 5:11 PM

Specifications
85
Engine oil total quantity:3.7 L (3.91 US qt, 3.26 Imp.qt)
UF3Y74E0.book Page 85 Monday, June 22, 2020 5:11 PM

Trouble recovery
86
EJU34562
Troubleshooting
If you have any trouble with your watercraft, use the troubleshooting chart to check for the
possible cause.
If you cannot find the cause, consult a Yamaha dealer.
EJU44430Troubleshooting chart
Confirm the possible cause and remedy, and then refer to the applicable page.
TROUBLEPOSSIBLE CAUSE REMEDYPAGE
Engine does not
start (Starter motor
does not turn over) Engine shut-
off switch
Clip not in place Install clip
24
Fuse Burned out Have serviced by
Yamaha dealer —
Battery Run down Recharge75
Poor terminal con-
nections Tighten as required
75
Terminal corroded Clean or replace 75
Starter motor Faulty Have serviced by
Yamaha dealer —
Engine does not
start (Starter motor
turns over) Throttle lever Squeezed
Release24
Faulty Have serviced by
Yamaha dealer —
RiDE lever
(EX
DELUXE / EX
LIMITED) Squeezed
Release 24
Faulty Have serviced by
Yamaha dealer —
Fuel Fuel tank empty Refill as soon as pos-
sible 43
Stale or contaminat-
ed Have serviced by
Yamaha dealer
—
Fuel tank Water or dirt present Have serviced by Yamaha dealer—
Spark plug Fouled or defective Have serviced by Yamaha dealer—
Fuel injec-
tion system Fuel pump faulty Have serviced by
Yamaha dealer —
UF3Y74E0.book Page 86 Monday, June 22, 2020 5:11 PM

Trouble recovery
87
Engine runs irregu-
larly or stallsFuel Fuel tank empty Refill as soon as pos-
sible43
Stale or contaminat-
ed Have serviced by
Yamaha dealer
—
Fuel tank Water or dirt present Have serviced by Yamaha dealer—
Spark plug Fouled or defective Have serviced by Yamaha dealer—
Incorrect heat range Have serviced by Yamaha dealer —
Gap incorrect Have serviced by Yamaha dealer —
Electrical wir-
ing Loose connection Have serviced by
Yamaha dealer —
Fuel injec-
tion system Faulty or clogged in-
jectors Have serviced by
Yamaha dealer
—
Warning light or in-
dicator blinks or
comes on Fuel level
warning
Fuel tank empty Refill as soon as pos-
sible 43
Oil pressure
warning Oil pressure dropped Have serviced by
Yamaha dealer 35
Engine over-
heat warning Jet intake clogged Clean
89
Check en-
gine warning Faulty sensors Have serviced by
Yamaha dealer 36
TROUBLE POSSIBLE CAUSE REMEDY PAGE
UF3Y74E0.book Page 87 Monday, June 22, 2020 5:11 PM

Trouble recovery
88
Watercraft slow or
loses powerCavitation Jet intake clogged Clean 89
Impeller damaged or
worn Have serviced by
Yamaha dealer
89
Engine over-
heat warning Engine speed reduc-
tion control activated Clean jet intake and
cool engine
35
Oil pressure
warning Engine speed reduc-
tion control activated Add oil
35
Spark plug Fouled or defective Have serviced by Yamaha dealer—
Incorrect heat range Have serviced by Yamaha dealer —
Gap incorrect Have serviced by Yamaha dealer —
Electrical wir-
ing Loose connection Have serviced by
Yamaha dealer —
Fuel Stale or contaminat- ed Have serviced by
Yamaha dealer
—
Air filter Clogged Have serviced by Yamaha dealer—
Oil buildup Have serviced by Yamaha dealer —
Throttle lever Faulty Have serviced by Yamaha dealer—
TROUBLE POSSIBLE CAUSE REMEDY PAGE
UF3Y74E0.book Page 88 Monday, June 22, 2020 5:11 PM

Trouble recovery
89
EJU34625
Emergency proceduresEJU44590Cleaning the jet intake and impellerEWJ00783
Before attempting to remove weeds or de-
bris from the jet intake or impeller area,
shut the engine off and remove the clip
from the engine shut-off switch. Severe in-
jury or death could result from coming in
contact with the rotating parts of the jet
pump.
If weeds or debris gets caught in the jet intake
or impeller, cavitation can occur, causing jet
thrust to decrease even though engine speed
rises. If this condition is allowed to continue,
the engine will overheat and may seize.
NOTICE: If weeds or debris gets caught in
the jet intake, do not operate the water-
craft above trolling speed until they have
been removed.
[ECJ00654]
If there is any sign that the jet intake or impel-
ler is clogged with weeds or debris, return to
shore and check the intake and impeller. Al- ways stop the engine before beaching the
watercraft.
(1) Place a suitable clean cloth or carpeting
underneath the watercraft to protect it
from abrasions and scratches. Turn the
watercraft on its side as shown.
NOTICE: When turning the watercraft
on its side, support the bow so that
the handlebars are not bent or dam-
aged.
[ECJ02690]
(2) Remove any weeds or debris from around the jet intake, drive shaft, impel-
UF3Y74E0.book Page 89 Monday, June 22, 2020 5:11 PM

Trouble recovery
90
ler, jet pump housing, and jet thrust noz-
zle.
If debris is difficult to remove, consult a
Yamaha dealer.
EJU43472Raising the reverse gate (EX
DELUXE / EX LIMITED)
If the RiDE system malfunctions and the re-
verse gate remains in the lowered position,
the watercraft will not be able to move for-
ward.
After raising the reverse gate so that the wa-
tercraft can move forward, immediately re-
turn to shore and have a Yamaha dealer
service the watercraft.
To raise the reverse gate:
(1) Stop the engine and remove the clip from the engine shut-off switch.
(2) Enter the water and move to the rear of the watercraft.
(3) Slide the shift rod joint toward the bow, and then disconnect the shift rod joint
from the ball joint. (4) Raise the reverse gate to the forward po-
sition.
TIP:
While the shift rod is disconnected, the re-
verse gate will not move to the neutral po-
sition or reverse position even if the RiDE
lever is squeezed.
If the RiDE lever is squeezed while the shift
rod is disconnected, the watercraft will
move forward.
EJU34642Jumping the battery
If the watercraft battery has run down, the en-
gine can be started using a 12-volt booster
battery and jumper cables.
EJU34664Connecting the jumper cablesEWJ01251
To avoid battery explosion and serious
damage to the electrical system:
Do not reverse the polarity of the jumper
cables when connecting to the batter-
ies.
Do not connect the negative (–) jumper
cable to the negative (–) terminal of the
watercraft battery.
Do not touch the positive (+) jumper ca-
ble to the negative (–) jumper cable.
1Shift rod joint
2 Ball joint
1 2
1
Reverse gate
2 Forward position
1
2
UF3Y74E0.book Page 90 Monday, June 22, 2020 5:11 PM

Trouble recovery
91
(1) Connect the positive (+) jumper cable tothe positive (+) battery terminals of both
batteries.
(2) Connect one end of the negative (–) jumper cable to the negative (–) battery
terminal of the booster battery.
(3) Connect the other end of the negative (–) jumper cable to an engine hanger.
(4) Start the engine, and then disconnect the jumper cables by reversing the steps
above. (See page 24 for information on
starting the engine.)
EJU34716Towing the watercraftEWJ00812
The operator of the towing boat must
keep speed to a minimum and avoid
traffic or obstacles which could be a
hazard to the operator on the water-
craft.
The towline should be long enough so
that the watercraft will not collide with
the towing boat when slowing down.
If the watercraft becomes inoperative in the
water, it can be towed to shore. To tow the watercraft:
Use a towline that is three times the com-
bined length of the towing boat and the wa-
tercraft.
(1) Securely attach the towline to the bow
eye of the watercraft being towed.
(2) Sit astride the seat and hold on to the handlebars in order to balance the water-
craft. NOTICE: The bow must be kept
up out of the water during towing, oth-
erwise water could flood the engine
compartment or water could flow
back into the engine, causing severe
engine damage.
[ECJ01331]
Tow the watercraft at 8 km/h (5 mph) or less.
NOTICE: Tow the watercraft at 8 km/h (5
mph) or less, otherwise water could flood
the engine compartment or water could
flow back into the engine, causing severe
engine damage.
[ECJ01322]
EJU42101
Submerged watercraft
If the watercraft is submerged or flooded with
water, drain the bilge water from the engine
compartment. Then, have a Yamaha dealer
service the watercraft as soon as possible.
If the watercraft was submerged:
(1) Remove the watercraft from the water and drain the water from the storage
compartments.
1Positive (+) jumper cable
2 Booster battery
3 Negative (–) jumper cable
4 Engine hanger
123
4
1Bow eye
1
UF3Y74E0.book Page 91 Monday, June 22, 2020 5:11 PM

Trouble recovery
92
(2) Drain the bilge water from the enginecompartment. (See page 47 for informa-
tion on draining the bilge water.)
(3) Have the watercraft serviced by a Yamaha dealer as soon as possible.
NOTICE: Be sure to have a Yamaha
dealer inspect the watercraft. Other-
wise, serious engine damage could
result.
[ECJ00792]
UF3Y74E0.book Page 92 Monday, June 22, 2020 5:11 PM

93
Index
A
After removing the watercraft from the water ..................................................... 73
B
Battery care.............................................. 75
Battery checks ......................................... 54
Battery, jumping....................................... 90
Beaching and docking the watercraft ...... 72
Bilge water check..................................... 54
Bilge water, draining ................................ 47
Bilge water, draining on land ................... 47
Bilge water, draining on water ................. 48
Boarding alone ......................................... 68
Boarding and starting off from a dock ..... 71
Boarding the watercraft ........................... 67
Boarding with passenger(s) ..................... 68
Bow eye ................................................... 39
Bow storage compartment ...................... 40
Builder’s plate ............................................ 3
C
Capsized watercraft ................................. 71
Check engine warning ............................. 36
Cleaning ................................................... 77
Cleaning the watercraft ............................ 75
Cleat ......................................................... 39
Cooling water pilot outlet ......................... 26
Cooling water pilot outlet check .............. 59
Craft Identification Number (CIN)............... 1
Cruising limitations................................... 10
E
Emergency procedures ............................ 89
Engine break-in ........................................ 50
Engine compartment check ..................... 53
Engine idling speed check ....................... 59
Engine oil ................................................. 45
Engine oil and oil filter .............................. 83
Engine oil level check............................... 54
Engine oil requirements ........................... 45
Engine overheat warning ......................... 35
Engine serial number ................................. 2
Engine shut-off cord (lanyard) check ....... 56
Engine shut-off switch ............................. 24
Engine stop switch................................... 24
Engine unit check..................................... 54
Enjoy your watercraft responsibly............ 18 Equipment ................................................ 37
F
Fire extinguisher check ............................ 57
Fire extinguisher holder............................ 42
Fire extinguisher holder checks ............... 57
Flushing the cooling water passages....... 74
Fuel .......................................................... 43
Fuel level check........................................ 53
Fuel level meter ........................................ 34
Fuel level warning..................................... 35
Fuel requirements .................................... 43
Fuel system checks ................................. 53
G
Getting to know your watercraft .............. 60
Glossary, watercraft ................................. 19
Glove compartment ................................. 40
H
Handgrip .................................................. 37
Hazard information................................... 14
Hood check .............................................. 58
Hour meter and voltmeter ........................ 33
Hull and deck check ................................ 58
I
Identification numbers ............................... 1
Information display................................... 32
J
Jet intake and impeller, cleaning.............. 89
Jet intake checks ..................................... 58
Jet thrust nozzle and reverse gate check
(EX SPORT / EX DELUXE / EX
LIMITED) ............................................... 58
Jumper cables, connecting ...................... 90
L
Labels, important ....................................... 4
Labels, other .............................................. 8
Labels, warning .......................................... 5
Launching the watercraft ......................... 61
Learning to operate your watercraft......... 60
Leaving the watercraft.............................. 62
Limitations on who may operate the watercraft ................................................ 9
Long-term storage ................................... 77
Lubrication ............................................... 77
M
Main components, location of ................. 20
UF3Y74E0.book Page 93 Monday, June 22, 2020 5:11 PM
