YAMAHA FX SVHO 2021 Owners Manual

Trouble recovery
104
(7) Securely install the fuse box cover in itsoriginal position.
(8) Securely install the electrical box cover in its original position.
(9) Slide the locks to their original positions to securely lock the electrical box cover
in place.
(10) Securely install the removable watertight storage compartment and seats in their
original positions.
If the fuse immediately blows again, the elec-
trical system may be defective. If this occurs,
have a Yamaha dealer service the watercraft.
EJU34716Towing the watercraftEWJ00812
The operator of the towing boat must
keep speed to a minimum and avoid
traffic or obstacles which could be a
hazard to the operator on the water-
craft.
The towline should be long enough so
that the watercraft will not collide with
the towing boat when slowing down.
If the watercraft becomes inoperative in the
water, it can be towed to shore. To tow the watercraft:
Use a towline that is three times the com-
bined length of the towing boat and the wa-
tercraft.
(1) Securely attach the towline to the bow
eye of the watercraft being towed.
(2) Sit astride the seat and hold on to the handlebars in order to balance the water-
craft. NOTICE: The bow must be kept
up out of the water during towing, oth-
erwise water could flood the engine
compartment or water could flow
back into the engine, causing severe
engine damage.
[ECJ01331]
Tow the watercraft at 8 km/h (5 mph) or less.
NOTICE: Tow the watercraft at 8 km/h (5
mph) or less, otherwise water could flood
the engine compartment or water could
flow back into the engine, causing severe
engine damage.
[ECJ01322]
EJU36156
Submerged watercraft
If the watercraft is submerged or flooded with
water, drain the bilge water from the engine
compartment. Then, have a Yamaha dealer
service the watercraft as soon as possible.
If the watercraft was submerged:
(1) Remove the watercraft from the water and drain the water from the storage
compartments. (See page 52 for infor-
Fuse amperage:
Electronic throttle valve fuse:
10 A
Fuel pump fuse: 10 A
Main relay drive fuse: 10 A
Main fuse:
20 A
Battery fuse: 30 A
SCU fuse: 50 A
1Bow eye
1
UF3X72E0.book Page 104 Friday, May 29, 2020 10:09 AM

Trouble recovery
105
mation on draining the storage compart-
ments.)
(2) Drain the bilge water from the engine compartment. (See page 61 for informa-
tion on draining the bilge water.)
(3) Have the watercraft serviced by a Yamaha dealer as soon as possible.
NOTICE: Be sure to have a Yamaha
dealer inspect the watercraft. Other-
wise, serious engine damage could
result.
[ECJ00792]
UF3X72E0.book Page 105 Friday, May 29, 2020 10:09 AM

106
Index
A
Adjustable tilt steering system ................. 28
Adjustable tilt steering system checks .... 69
After removing the watercraft from the water ..................................................... 85
B
Battery care.............................................. 87
Battery checks ......................................... 67
Battery, jumping..................................... 101
Beaching and docking the watercraft ...... 84
Beverage holder ....................................... 55
Bilge water check..................................... 67
Bilge water, draining ................................ 61
Bilge water, draining on land ................... 61
Bilge water, draining on water ................. 61
Boarding alone ......................................... 80
Boarding and starting off from a dock ..... 83
Boarding the watercraft ........................... 80
Boarding with passenger(s) ..................... 81
Bow eye ................................................... 51
Bow storage compartment ...................... 52
Builder’s plate ............................................ 3
C
Capsized watercraft ................................. 83
Cleaning ................................................... 89
Cleaning the watercraft ............................ 87
Cleat ......................................................... 51
Cooling water pilot outlet check .............. 72
Cooling water pilot outlets ....................... 29
Craft Identification Number (CIN)............... 2
Cruise assist............................................. 38
Cruising limitations................................... 11
D
Drive control mode................................... 36
Drive control mode screen ....................... 44
E
Electric trim system.................................. 32
Electric trim system check ....................... 70
Emergency procedures .......................... 100
Engine break-in ........................................ 63
Engine compartment check ..................... 66
Engine cover, removing and installing ..... 91
Engine idling speed check ....................... 73
Engine lock screen ................................... 46
Engine oil ................................................. 59 Engine oil and oil filter .............................. 95
Engine oil level check ............................... 67
Engine oil requirements ........................... 59
Engine serial number ................................. 2
Engine shut-off cord (lanyard) check ....... 69
Engine shut-off switch ............................. 26
Engine stop switch ................................... 26
Engine unit check ..................................... 67
Enjoy your watercraft responsibly ............ 19
Equipment ................................................ 49
F
Fire extinguisher check ............................ 71
Fire extinguisher holder and cover........... 56
Fire extinguisher holder, cover, and
band checks ......................................... 70
Flushing the cooling water passages....... 86
Fuel .......................................................... 57
Fuel level check........................................ 66
Fuel requirements .................................... 57
Fuel system checks ................................. 66
Fuses, replacing ..................................... 102
G
Getting to know your watercraft .............. 74
Glossary, watercraft ................................. 20
Glove compartment ................................. 53
H
Handgrip .................................................. 50
Hazard information................................... 15
Home screen ............................................ 42
Hood check .............................................. 72
Hull and deck check ................................ 71
I
Identification numbers ............................... 1
Information screen ................................... 43
J
Jet intake and impeller, cleaning............ 100
Jet intake checks ..................................... 71
Jet thrust nozzle and reverse gate check .................................................... 71
Jumper cables, connecting .................... 101
L
Labels, important ....................................... 4
Labels, other .............................................. 8
Labels, warning .......................................... 5
Launching the watercraft ......................... 75
UF3X72E0.book Page 106 Friday, May 29, 2020 10:09 AM

Index
107
Learning to operate your watercraft ........ 74
Leaving the watercraft ............................. 76
Limitations on who may operate the watercraft.............................................. 10
Long-term storage ................................... 89
Lubrication ............................................... 89
M
Main components, location of ................. 21
Maintenance ............................................ 91
Manufactured date label ............................ 2
Model information ...................................... 3
Multifunction information center .............. 40
Multifunction information center check ... 72
N
No-wake mode ........................................ 35
O
Operating in weeded areas ...................... 84
Operating the watercraft .......................... 76
Operating the watercraft in reverse or neutral ................................................... 79
Operating your watercraft ........................ 74
Operation buttons .................................... 41
Operation requirements ........................... 12
Optional part mounting bracket ............... 56
P
Periodic maintenance chart ..................... 93
Post-launch checks ................................. 72
Post-operation care ................................. 86
Pre-launch checks ................................... 66
Pre-operation check points ..................... 66
Pre-operation checklist ............................ 64
Primary Identification (PRI-ID) number ...... 1
Pull-up cleats (FX CRUISER SVHO / FX LIMITED SVHO) ............................... 52
R
Raising the reverse gate ........................ 101
Reboarding grip ....................................... 50
Reboarding step ...................................... 50
Recommended equipment ...................... 14
Removable watertight storage compartment ........................................ 55
Reverse assist .......................................... 34
RiDE lever................................................. 27
RiDE lever checks .................................... 69
Riding position ......................................... 75 Rustproofing ............................................ 90
S
Safe boating rules .................................... 18
Safety equipment check .......................... 71
Seats ........................................................ 49
Setting menu screen ................................ 44
Shift system ............................................. 30
Shift system check ................................... 72
Start switch .............................................. 26
Starting off ............................................... 82
Starting off from a trailer .......................... 83
Starting the engine on water .................... 75
Status area ............................................... 42
Steering system ....................................... 27
Steering system checks ........................... 68
Stern drain plug checks ........................... 71
Stern eyes ................................................ 51
Stern storage compartment ..................... 54
Stopping the engine ................................. 76
Stopping the watercraft ........................... 78
Storage compartment checks.................. 70
Storage compartments ............................ 52
Submerged watercraft ........................... 104
Switch checks .......................................... 69
T
T.D.E. (thrust directional enhancer) .......... 34
Throttle lever ............................................ 27
Throttle lever checks ................................ 69
Touch screen ........................................... 41
Towing the watercraft ............................ 104
Transporting on a trailer ........................... 62
Troubleshooting ....................................... 97
Troubleshooting chart .............................. 97
Turning the watercraft .............................. 77
W
Wakeboarding and water-skiing .............. 17
Warning function ...................................... 46
Water separator ....................................... 29
Water separator check ............................. 67
Watercraft characteristics ........................ 15
Watercraft control functions..................... 25
Watercraft operation functions ................ 30
Watercraft operation modes .................... 34
Y
Yamaha Security System ......................... 25
UF3X72E0.book Page 107 Friday, May 29, 2020 10:09 AM

Index
108
Yamaha Security System check .............. 69
Yamaha Security System setting ............. 25
UF3X72E0.book Page 108 Friday, May 29, 2020 10:09 AM

Printed in U.S.A.
June 2020–0.3 × 1 CR
UF3X72E0.book Page 1 Friday, May 29, 2020 10:09 AM
