YAMAHA GP1800 2018 Owners Manual

Trouble recovery
95
(1) Connect the positive (+) jumper cable to
the positive (+) battery terminals of both
batteries.
(2) Connect one end of the negative (–)
jumper cable to the negative (–) battery
terminal of the booster battery.
(3) Connect the other end of the negative (–)
jumper cable to an engine hanger.
(4) Start the engine, and then disconnect the
jumper cables by reversing the steps
above. (See page 27 for information on
starting the engine.)EJU44050Replacing the fuses
If a fuse is blown, replace it with the proper
fuse.
To replace a fuse:
(1) Remove the seats and removable water-
tight storage compartment. (See page 42
for seat removal and installation proce-
dures and page 47 for information on the
removable watertight storage compart-
ment.)
1Negative (–) jumper cable
2Booster battery
3Positive (+) jumper cable
4Engine hanger
1
4
3
2
1Good fuse
2Blown fuse
1Good fuse
2Blown fuse
2 1
2 1
UF3P71E0.book Page 95 Tuesday, June 27, 2017 10:54 AM

Trouble recovery
96
(2) While pushing the projection on each
lock, slide the locks outward.
(3) Remove the electrical box cover from the
electrical box and move it under the deck
beam toward the stern. NOTICE: Do not
attempt to forcefully remove the elec-
trical box cover from the watercraft.
Otherwise, the electrical box cover,
electrical system, and engine could be
damaged.
[ECJ02610]
(4) While pushing both sides of the fuse box
cover inward, pull the cover toward the
bow and remove it.
(5) When replacing the SCU fuse, remove
the screws, and then remove the fuse.
Install the spare fuse, and then tighten
the screws.
(6) When replacing a fuse other than the
SCU fuse, remove the fuse using the
fuse puller. Install a spare fuse of the
proper amperage. WARNING! Do not
1Electrical box cover
2Lock
3Projection
1Electrical box cover
2
1
233
1
1Fuse box cover
1Electronic throttle valve fuse
2Fuel pump fuse
3Main relay drive fuse
4Main fuse
5Spare fuse
6Fuse puller
7Battery fuse
8Screw
9SCU fuse (BCU fuse)
10Security system fuse
1
1
5 23 4 5 6 7
8
9
8
10
5
UF3P71E0.book Page 96 Tuesday, June 27, 2017 10:54 AM

Trouble recovery
97
use fuses of a different amperage than
recommended. Substitution with a
fuse that has an improper rating can
cause extensive electrical system
damage and possible fire.
[EWJ00803]
(7) Securely install the fuse box cover in its
original position.
(8) Securely install the electrical box cover in
its original position.
(9) Slide the locks to their original positions
to securely lock the electrical box cover
in place.
(10) Securely install the removable watertight
storage compartment and seats in their
original positions.
If the fuse immediately blows again, the elec-
trical system may be defective. If this occurs,
have a Yamaha dealer service the watercraft.
EJU34716Towing the watercraft
WARNING
EWJ00812
The operator of the towing boat must
keep speed to a minimum and avoid
traffic or obstacles which could be a
hazard to the operator on the water-
craft.
The towline should be long enough so
that the watercraft will not collide with
the towing boat when slowing down.
If the watercraft becomes inoperative in the
water, it can be towed to shore.
To tow the watercraft:
Use a towline that is three times the com-
bined length of the towing boat and the wa-
tercraft.
(1) Securely attach the towline to the bow
eye of the watercraft being towed.
(2) Sit astride the seat and hold on to the
handlebars in order to balance the water-
craft. NOTICE: The bow must be kept
up out of the water during towing, oth-
erwise water could flood the engine
compartment or water could flow
back into the engine, causing severe
engine damage.
[ECJ01331]
Tow the watercraft at 8 km/h (5 mph) or less.
NOTICE: Tow the watercraft at 8 km/h (5
mph) or less, otherwise water could flood
the engine compartment or water could
flow back into the engine, causing severe
engine damage.
[ECJ01322]
EJU36156
Submerged watercraft
If the watercraft is submerged or flooded with
water, drain the bilge water from the engine Fuse amperage:
Electronic throttle valve fuse:
10 A
Fuel pump fuse:
10 A
Main relay drive fuse:
10 A
Main fuse:
20 A
Battery fuse:
30 A
SCU fuse:
50 A
Security system fuse:
3 A
1Bow eye
1
UF3P71E0.book Page 97 Tuesday, June 27, 2017 10:54 AM

Trouble recovery
98
compartment. Then, have a Yamaha dealer
service the watercraft as soon as possible.
If the watercraft was submerged:
(1) Remove the watercraft from the water
and drain the water from the storage
compartments. (See page 45 for infor-
mation on draining the storage compart-
ments.)
(2) Drain the bilge water from the engine
compartment. (See page 53 for informa-
tion on draining the bilge water.)
(3) Have the watercraft serviced by a
Yamaha dealer as soon as possible.
NOTICE: Be sure to have a Yamaha
dealer inspect the watercraft. Other-
wise, serious engine damage could
result.
[ECJ00792]
