8-64
8
EBU25740Troubleshooting Although Yamaha ATVs receive a thorough in-
spection before shipment from the factory, trouble
may occur during operation. Any problem in the fu-
el, compression, or ignition systems, for example,
can cause poor starting and loss of power.
The following troubleshooting charts represent
quick and easy procedures for checking these vital
systems yourself. However, should your ATV re-
quire any repair, take it to a Yamaha dealer, whose
skilled technicians have the necessary tools, expe-
rience, and know-how to service the ATV properly.
Use only genuine Yamaha replacement parts. Im-
itation parts may look like Yamaha parts, but they
are often inferior, have a shorter service life and
can lead to expensive repair bills.
WARNING
EWB02280Do not smoke when checking the fuel system.
Fuel can ignite or explode, causing severe inju-
ry or property damage. Make sure there are no
open flames or sparks in the area, including pi-
lot lights from water heaters or furnaces.U2LC60E0.book Page 64 Friday, March 8, 2013 1:18 PM
10-1
10
EBU25961
SPECIFICATIONS
Dimensions:Overall length:1993 mm (78.5 in)
Overall width: 1093 mm (43.0 in)
Overall height:
1120 mm (44.1 in)
Seat height: 840 mm (33.1 in)
Wheelbase: 1233 mm (48.5 in)
Ground clearance:
245 mm (9.6 in)
Minimum turning radius: 3000 mm (118 in)Weight:With oil and fuel:
YFM450DE 275.0 kg (606 lb) (AUS)(NZL)
YFM450DE 276.0 kg (608 lb) (EUR)(FRA)(GBR)
YFM450PE 281.0 kg (619 lb) (AUS)(NZL)
YFM450PE 282.0 kg (622 lb) (EUR)(FRA)(GBR)
YFM450PHE 282.0 kg (622 lb)Noise and vibration level:Noise level (77/311/EEC):YFM450DE 78.3 dB(A) (EUR)(FRA)(GBR)
YFM450PE 78.3 dB(A) (EUR)(FRA)(GBR)
YFM450PHE 78.3 dB(A) Vibration on seat (EN1032, ISO5008):
YFM450DE 0.6 m/s² (EUR)(FRA)(GBR)
YFM450PE 0.6 m/s² (EUR)(FRA)(GBR)
YFM450PHE 0.6 m/s²
Vibration on handlebar (EN1032, ISO5008): YFM450DE Will not exceed 2.5 m/s² (EUR)(FRA)(GBR)
YFM450PE Will not exceed 2.5 m/s² (EUR)(FRA)(GBR)
YFM450PHE Will not exceed 2.5 m/s²
Engine:Engine type:Liquid cooled 4-stroke, SOHC
Cylinder arrangement:
Single cylinder
Displacement: 421 cm³
Bore × stroke:
84.5 × 75.0 mm (3.33 × 2.95 in)
Compression ratio:
10.00 : 1
Starting system: Electric starter
Lubrication system: Wet sumpEngine oil:Recommended brand:YAMALUBE
