Page 18 of 442
Rear brake adjustment .................... 8-101
Adjusting the rear brake light
switch ............................................. 8-105
Cable inspection and lubrication ..... 8-107
Brake lever and brake pedal
lubrication ...................................... 8-109
Rear knuckle upper and lower pivot
lubrication ....................................... 8-111
Wheel removal ................................ 8-113
Wheel installation ............................ 8-115
Battery ............................................. 8-117
Battery maintenance ....................... 8-121
Fuse replacement ............................ 8-123
Replacing the headlight bulb ........... 8-127
Headlight beam adjustment ............. 8-131
Tail/brake light bulb replacement ..... 8-133
Troubleshooting ............................... 8-135
Troubleshooting chart ...................... 8-137CLEANING AND STORAGE .................. 9-1
A. Cleaning ......................................... 9-1
B. Storage ........................................... 9-7
SPECIFICATIONS................................. 10-1
HOW TO USE THE CONVERSION
TABLE .................................................. 11-1
91011
U5KM60.book Page 3 Thursday, June 21, 2001 2:40 PM
Page 80 of 442
4-17 1. Lights switch
2. Engine stop switch
3. Start switch “”
4. Horn switch “”
1. Contacteur d’éclairage
2. Coupe-circuit du moteur
3. Contacteur du démarreur “”
4. Contacteur de l’avertisseur “”
1. Interruptor de luces
2. Interruptor de paro del motor
3. Interruptor de arranque “”
4. Interruptor de la bocina “”
EBU00053
Handlebar switches
EBU00735
Light switch
Turn the switch to the “” position to switch on
the low beam and the taillight.
Turn the switch to the “” position to switch on
the high beam and the taillight.
Turn the switch to the “OFF” position to switch off
the headlight and the taillight.CAUTION:
Do not use the headlight with the engine
turned off for more than thirty minutes. The
battery may discharge to the point that the
starter motor will not operate properly. If this
should happen, remove the battery and re-
charge it.
EBU00606
Engine stop switch
Make sure that the engine stop switch is in the
“” position. The engine stop switch controls ig-
nition and can be used at all times to stop the en-
gine, especially in an emergency. The engine will
not start or run when the engine stop switch is
turned to “”.
U5KM60.book Page 17 Thursday, June 21, 2001 2:40 PM
Page 396 of 442
8-131 1. Headlight beam adjusting screw
1. Vis de réglage du faisceau de phare
1. Tornillo de ajuste de la luz del faro
EBU00409
Headlight beam adjustmentCAUTION:
It is advisable to have a Yamaha dealer make
this adjustment.1. Vertical adjustment:
To raise the beam, turn the adjusting screw
clockwise.
To lower the beam, turn the screw counter-
clockwise.
U5KM60.book Page 131 Thursday, June 21, 2001 2:40 PM
