spark YAMAHA KODIAK 400 2002 Owners Manual

EBU00011
IMPORTANT NOTICE
This machine is designed and manufactured for
OFF-ROAD use only. It is illegal and unsafe to op-
erate this machine on any public street, road or
highway.
This machine complies with all applicable OFF-
ROAD noise level and spark arrester laws and
regulations in effect at the time of manufacture.
Please check your local riding laws and regula-
tions before operating this machine.
EBU00712
YFM4FAP
OWNER’S MANUAL
© 2001 by Yamaha Motor Co., Ltd.
1st Edition, June 2001
All rights reserved. Any reprinting or unau-
thorized use without the written permission
of Yamaha Motor Co., Ltd.
is expressly prohibited.
Printed in Japan.
U5GH62.book Page 1 Monday, August 6, 2001 9:09 AM

Tires ...................................................5-25
How to measure tire pressure ............5-29
Tire wear limit .....................................5-31
OPERATION ...........................................6-1
Starting a cold engine ..........................6-3
Starting a warm engine ........................6-9
Warming up ..........................................6-9
Drive select lever operation and
reverse driving ..................................6-11
Engine break-in ..................................6-17
Parking ...............................................6-19
Parking on a slope .............................6-21
Accessories and loading ....................6-23
Loading ..............................................6-27
RIDING YOUR ATV..................................7-1
Getting to know your ATV .....................7-3
Ride with care and good judgement .....7-5
Be careful where you ride ...................7-27
Turning your ATV ................................7-39
Climbing uphill.....................................7-45
Riding downhill ....................................7-55
Crossing a slope .................................7-59
Crossing through shallow water ..........7-63
Riding over rough terrain ....................7-69
Sliding and skidding ............................7-71
67
What to do if ... ................................... 7-75
What to do ... ...................................... 7-75
PERIODIC MAINTENANCE AND
ADJUSTMENT ........................................ 8-1
Owner’s manual and tool kit ................ 8-3
Periodic maintenance/lubrication ......... 8-7
Panel removal and installation ........... 8-15
Engine oil ............................................ 8-31
Final gear oil ....................................... 8-41
Differential gear oil ............................. 8-47
Cooling system .................................. 8-53
Changing the coolant.......................... 8-57
Axle boots ........................................... 8-63
Spark plug inspection ........................ 8-65
Air filter cleaning ................................ 8-71
V-belt cooling duct check hose .......... 8-77
Carburetor adjustment ....................... 8-81
Idle speed adjustment ....................... 8-83
Valve clearance adjustment .............. 8-85
Throttle lever adjustment ................... 8-87
Front brake pad inspection ................ 8-89
Rear brake pad inspection ................. 8-89
Inspecting the brake fluid level .......... 8-91
Brake fluid replacement ...................... 8-95
Front brake adjustment ...................... 8-97
Rear brake lever adjustment ............. 8-99
8
U5GH62.book Page 2 Monday, August 6, 2001 9:09 AM

2-15
WARNING


Always turn off the engine when refueling.


Do not refuel right after the engine has
been running and is still very hot.


Do not spill gasoline on the engine or ex-
haust pipe/muffler when refueling. Never
refuel while smoking, or while in the vicini-
ty of sparks, open flames, or other sources
of ignition such as the pilot lights of water
heaters and clothes dryers. Gasoline can
catch fire and you could be burned.


When transporting the machine in another
vehicle, be sure it is kept upright and that
the fuel cock is in the “OFF” position. Oth-
erwise, fuel may leak out of the carburetor
or fuel tank.


Gasoline is poisonous. If you should swal-
low some gasoline or inhale a lot of gaso-
line vapor, or get some gasoline in your
eyes, see your doctor immediately. If gaso-
line spills on your skin, wash with soap
and water. If gasoline spills on your cloth-
ing, change your clothes.
U5GH62.book Page 15 Monday, August 6, 2001 9:09 AM

3-1
EBU00032
DESCRIPTION AND MACHINE
IDENTIFICATION1. Rear spring preload
adjusting ring
2. Storage box and tool kit
3. Spark plug
4. Rear brake fluid reservoir
5. Radiator cap
6. Front spring preload
adjusting ring
7. V-belt case
8. Rear brake pedal
9. Front spring preload
adjusting ring
10. Fuel cock
11. Air filter case
12. Fuses
13. Tail/brake light14. V-belt cooling duct check
hose
15. Coolant reservoir
16. Oil filter cartridge
17. Engine oil dipstick
18. Rear brake lever
19. Left handlebar switches
20. Starter (choke)
21. Horn switch
22. Drive select lever
23. Speedometer
24. Main switch
25. Fuel tank cap
26. Auxiliary DC jack
27. Right handlebar switch
28. Throttle lever
29. Front brake leverNOTE:The machine you have purchased may differ
slightly from those shown in the figures of this
manual.
U5GH62.book Page 1 Monday, August 6, 2001 9:09 AM

8-7
EBU00262
PERIODIC MAINTENANCE/LUBRICATION
ITEM ROUTINEINITIAL EVERY
1
month3
months6
months6
months1
year
Valves*•Check valve clearance.
•Adjust if necessary.
Cooling system•Check coolant leakage.
•Repair if necessary.
•Replace coolant every 24 months.Spark plug•Check condition.
•Adjust gap and clean.
•Replace if necessary.Air filter•Clean.
•Replace if necessary.Every 20~40 hours
(More often in wet or dusty areas.)
Crankcase breather
system*•Check breather hose for cracks or damage.
•Replace if necessary.Exhaust system*•Check for leakage.
•Retighten if necessary.
•Replace gasket(s) if necessary.Carburetor*•Check and adjust idle speed/starter operation.
•Adjust if necessary.Fuel line*•Check fuel hose for cracks or damage.
•Replace if necessary.Engine oil
•Replace (Warm engine before draining).Engine oil filter cartridge
•Replace.Engine oil strainer*
•Clean.Final gear oil
•Check oil level/oil leakage.
•Replace every 12 months.Differential gear oil
Front brake*•Check operation/fluid leakage/see NOTE page 8-8.
•Correct if necessary.Rear brake*•Check operation/fluid leakage/see NOTE page 8-8.
•Correct if necessary.U5GH62.book Page 7 Monday, August 6, 2001 9:09 AM

8-65 1. Spark plug cap
1. Capuchon de bougie
1. Tapa de bujía
1. Spark plug wrench
1. Clé à bougie
1. Llave de bujía
EBU00680
Spark plug inspection
Removal
1. Remove the spark plug cap.
2. Use the spark plug wrench in the tool kit to re-
move the spark plug as shown.
Inspection
The spark plug is an important engine component
and is easy to inspect. The condition of the spark
plug can indicate the condition of the engine.
The ideal color on the white insulator around the
center electrode is a medium-to-light tan color for a
ATV that is being ridden normally.
U5GH62.book Page 65 Monday, August 6, 2001 9:09 AM

8-67 a. Spark plug gap
a.Écartement des électrodes
a. Huelgo de la bujía
Do not attempt to diagnose such problems your-
self. Instead, take the ATV to a Yamaha dealer.
You should periodically remove and inspect the
spark plug because heat and deposits will cause
the spark plug to slowly break down and erode. If
electrode erosion becomes excessive, or if carbon
and other deposits are excessive, you should re-
place the spark plug with the specified plug.
Specified spark plug:
DR8EA (NGK)
U5GH62.book Page 67 Monday, August 6, 2001 9:09 AM

8-69
Installation
1. Measure the electrode gap with a wire thick-
ness gauge and, if necessary, adjust the gap
to specification.
2. Clean the gasket surface. Wipe off any grime
from the threads.
3. Install the spark plug and tighten it to the
specified torque.NOTE:If a torque wrench is not available when you are in-
stalling a spark plug, a good estimate of the correct
torque is 1/4 to 1/2 turn past finger tight. Have the
spark plug tightened to the specified torque as
soon as possible. 4. Install the spark plug cap.Spark plug gap:
0.6 ~ 0.7 mm
Tightening torque:
Spark plug:
17.5 Nm (1.75 m·kgf)
U5GH62.book Page 69 Monday, August 6, 2001 9:09 AM

8-115
WARNING
Battery electrolyte is poisonous and danger-
ous, causing severe burns, etc. It contains sul-
furic acid. Avoid contact with skin, eyes or
clothing.
Antidote:

EXTERNAL: Flush with water.


lNTERNAL: Drink large quantities of water
or milk. Follow with milk of magnesia, beat-
en egg or vegetable oil. Call a physician
immediately.


EYES: Flush with water for 15 minutes and
get prompt medical attention.
Batteries produce explosive gases. Keep
sparks, flame, cigarettes or other sources of
ignition away. Ventilate when charging or us-
ing in an enclosed space. Always shield your
eyes when working near batteries.
KEEP OUT OF REACH OF CHILDREN.
U5GH62.book Page 115 Monday, August 6, 2001 9:09 AM

8-133
EBU00413
Troubleshooting
Although Yamaha machines receive a rigid in-
spection before shipment from the factory, trouble
may occur during operation.
Any problem in the fuel, compression, or ignition
systems can cause poor starting and loss of pow-
er. The troubleshooting chart describes a quick,
easy procedure for making checks. If your ma-
chine requires any repair, take it to a Yamaha
dealer.
The skilled technicians at a Yamaha dealership
have the tools, experience, and know-how to prop-
erly service your machine. Use only genuine
Yamaha parts on your machine. Imitation parts
may look like Yamaha parts, but they are often in-
ferior. Consequently, they have a shorter service
life and can lead to expensive repair bills.
WARNING
Do not smoke when checking the fuel system.
Fuel can ignite or explode, causing severe in-
jury or property damage. Make sure there are
no open flames or sparks in the area, including
pilot lights from water heaters or furnaces.
U5GH62.book Page 133 Monday, August 6, 2001 9:09 AM
