fuel tank capacity YAMAHA KODIAK 450 2020 Owners Manual

4-17
4
3. Wipe up any spilled fuel immediately.
NOTICE: Immediately wipe off spilled fuel
with a clean, dry, soft cloth, since fuel may
deteriorate painted surfaces or plastic
parts.
[ECB00982]
4. Turn the fuel tank cap fully clockwise to make sure it is securely closed.EBU38023FuelMake sure there is sufficient gasoline in the tank
before starting off. Refuel if necessary.
WARNING
EWB02532Gasoline is poisonous and can cause injury or
death. Handle gasoline with care. Never siphon
gasoline by mouth. If you should swallow some
gasoline or inhale a lot of gasoline vapor, or get
some gasoline in your eyes, see your doctor
immediately. If gasoline spills on your skin,
wash with soap and water. If gasoline spills on
your clothing, change your clothes.
For EuropeTIPConfirm the gasoline pump nozzle has the same
fuel identification mark. Recommended fuel:Regular unleaded gasoline (Gasohol [E10]
acceptable)
Fuel tank capacity: 14 L (3.7 US gal, 3.1 Imp.gal)
Fuel reserve amount: 4.0 L (1.06 US gal, 0.88 Imp.gal)1. EN228 fuel identification mark
1
E5
E10
UBB562E0.book Page 17 Thursday, March 14, 2019 9:59 AM

10-3
10
Differential gear oil:Type:Yamaha Friction Modified Plus Shaft Drive Oil (Part No.: ACC-SHAFT-PL-32) or SAE 80 API GL-4 Hypoid gear oil
(B5R1/B5R2/B5R3)
Yamaha Friction Modified Shaft Drive Gear Oil or SAE 80 API GL-4 Hypoid gear oil
(BJ5H/BB5R/BJ5D/BJ5E/BB5M)
Quantity: 0.23 L (0.24 US qt, 0.20 Imp.qt) (B5R1/B5R2/B5R3)
0.35 L (0.37 US qt, 0.31 Imp.qt)
(BJ5H/BB5R/BJ5D/BJ5E/BB5M)Coolant quantity:Radiator (including all routes):1.32 L (1.40 US qt, 1.16 Imp.qt)
Coolant reservoir (up to the maximum level mark): 0.25 L (0.26 US qt, 0.22 Imp.qt)Air filter:Air filter element:Wet element
Air filter oil grade: Foam air-filter oilFuel:Recommended fuel:Regular unleaded gasoline (Gasohol [E10] acceptable)
Minimum research octane: 91
Fuel tank capacity:
14 L (3.7 US gal, 3.1 Imp.gal)
Fuel reserve amount: 4.0 L (1.06 US gal, 0.88 Imp.gal)
Throttle body:ID mark:BB51 00Spark plug (s):Manufacturer/model:NGK/DR7EA
Spark plug gap: 0.6–0.7 mm (0.024–0.028 in)Drivetrain:Primary reduction ratio:1.000
Secondary reduction ratio: 7.944 (39/24 x 24/18 x 33/9)
Final drive:
Shaft
Clutch type: Wet, centrifugal, shoe
Transmission type: CVT automatic with reverse
Gear ratio:
Transmission ratio:2.550–0.750 : 1
Reverse gear:
1.706 (29/17)
Low range: 2.813 (45/16)
High range: 1.652 (38/23)Front tire:Size:AT25x8-12
UBB562E0.book Page 3 Thursday, March 14, 2019 9:59 AM
