AUX YAMAHA KODIAK 700 2018 Owners Manual

EBU17421
TABLE OF CONTENTS
LOCATION OF THE WARNING AND
SPECIFICATION LABELS .............................. 1-1
SAFETY INFORMATION ................................ 2-1
DESCRIPTION................................................ 3-1Left view ...................................................... 3-1
Right view.................................................... 3-1
Controls and instruments............................ 3-2
INSTRUMENT AND CONTROL
FUNCTIONS ................................................... 4-1 Main switch ................................................. 4-1
Indicator lights and warning lights .............. 4-1
Multi-function display (YFM70KPXJ / YFM70KPAJ / YFM70KPHJ /
YFM70KPSJ) ............................................. 4-5
Handlebar switches .................................... 4-8
Drive lever “2WD/4WD” (YFM70KDXJ / YFM70KDHJ) .......................................... 4-13
Throttle lever ............................................. 4-14
Speed limiter ............................................. 4-15
Front brake lever ....................................... 4-15
Brake pedal and rear brake lever .............. 4-16 Drive select lever ...................................... 4-16
Fuel tank cap ............................................ 4-17
Fuel ........................................................... 4-17
Seat .......................................................... 4-19
Storage compartment............................... 4-20
Front carrier .............................................. 4-21
Rear carrier ............................................... 4-22
Front and rear shock absorbers
(YFM70KPXJ / YFM70KPAJ /
YFM70KPHJ / YFM70KPSJ) .................. 4-22
Trailer hitch (YFM70KPXJ / YFM70KPAJ / YFM70KPHJ /
YFM70KPSJ) .......................................... 4-23
Auxiliary DC jack....................................... 4-24
PRE-OPERATION CHECKS .......................... 5-1 Fuel ............................................................. 5-3
Engine oil .................................................... 5-3
Final gear oil ............................................... 5-3
Differential gear oil ...................................... 5-3
Coolant ....................................................... 5-3
Front and rear brakes ................................. 5-3
Throttle lever ............................................... 5-4
Tires ............................................................ 5-4UB1662E0.book Page 1 Monday, April 17, 2017 11:39 AM

3-2
3
EBU17715Controls and instrumentsYFM70KDXJ / YFM70KDHJYFM70KPXJ / YFM70KPAJ / YFM70KPHJ /
YFM70KPSJ1. Drive select lever
2. Rear brake lever
3. Handlebar switches
4. Horn switch
5. Drive lever “2WD / 4WD”
6. Warning and indicator lights
7. Front brake fluid reservoir
8. Front brake lever
9. Throttle lever
10.Auxiliary DC jack
11.Main switch123
4 5 6 7 8 9 10 11
1. Drive select lever
2. Rear brake lever
3. Handlebar switches
4. Horn switch
5. Multi-function display
6. Front brake fluid reservoir
7. On-Command 4WD switches
8. Front brake lever
9. Throttle lever
10.Auxiliary DC jack
11.Main switch123 56
7891011
4
UB1662E0.book Page 2 Monday, April 17, 2017 11:39 AM

4-24
4
EBU19185Auxiliary DC jackA 12-V accessory, such as a work light or radio
with the proper adapter, can be used when the en-
gine is running and the headlights are turned off.1. Start the engine. (See page 6-1.)
2. Turn the headlights off. (See page 4-10.)
3. Turn the accessory off.
4. Open the auxiliary DC jack cap.
5. Insert the accessory power plug into the jack. 6. Turn the accessory on.
TIP
When inserting or removing the accessory pow-
er plug, turn the accessory off.
 When the auxiliary DC jack is not being used,
cover it with the cap. NOTICEECB00121Do not use accessories requiring more than
the above maximum capacity. This may
overload the circuit and cause the fuse to
blow.
 If accessories are used without the engine
running or with the headlights turned on, the
battery will lose its charge and engine start-
ing may become difficult.
 Do not use an automotive cigarette lighter or
other accessories with a plug that gets hot
because the jack can be damaged.
1. Auxiliary DC jack cap
2. Auxiliary DC jackAuxiliary DC jack maximum capacity:
10 A (120 W)
21
UB1662E0.book Page 24 Monday, April 17, 2017 11:39 AM

8-57
85. Install the panel.
TIP
Make sure the positive and negative battery
leads are installed as shown.
 Fully charge the battery before installing it. EBU30522Replacing a fuse
If an electrical problem is suspected, check the
fuse and replace it if necessary as follows.
1. Fuse box
2. Main fuse
3. EPS fuse (for EPS model)
4. Fuel injection system spare fuse
5. Fuel injection system fuse
2345
1
1. Headlight fuse
2. Signaling system fuse
3. Radiator fan motor fuse
4. Ignition fuse
5. Four-wheel-drive motor fuse (YFM70KPXJ /
YFM70KPAJ / YFM70KPHJ / YFM70KPSJ)
6. Auxiliary DC jack fuse
7. Spare fuse
8. Spare fuse (YFM70KPXJ / YFM70KPAJ / YFM70KPHJ / YFM70KPSJ)
123456
87
UB1662E0.book Page 57 Monday, April 17, 2017 11:39 AM

8-58
8
NOTICEECB00641To prevent accidental short-circuiting, turn off
the main switch when checking or replacing a
fuse. 1. Turn off all electrical systems. (See page 4-1.)
2. Remove panel A. (See page 8-9.)
3. Remove the blown fuse, and then install anew fuse of the specified amperage.
WARNING! Always use a fuse of the spec- ified rating, and never use a substitute ob-
ject in place of the proper fuse. An
improper fuse or a substitute object can
cause damage to the electrical system,
which could lead to a fire.
[EWB02173]
4. Turn on the main switch and start the engine. Specified fuses:
Main fuse:40.0 A
Headlight fuse: 10.0 A (YFM70KDHJ, YFM70KDXJ)
15.0 A (YFM70KPAJ, YFM70KPHJ,
YFM70KPSJ, YFM70KPXJ)
Ignition fuse: 10.0 A
Four-wheel-drive motor fuse: 10.0 A (YFM70KPAJ, YFM70KPHJ,
YFM70KPSJ, YFM70KPXJ)
Signaling system fuse: 10.0 A
Auxiliary DC jack fuse: 10.0 A
Radiator fan motor fuse: 20.0 A
Fuel injection system fuse: 15.0 A
EPS fuse: 40.0 A (YFM70KPAJ, YFM70KPHJ,
YFM70KPSJ, YFM70KPXJ)
UB1662E0.book Page 58 Monday, April 17, 2017 11:39 AM

10-5
10
Handlebar-mounted light:Bulb type:Halogen bulb (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)Bulb voltage, wattage × quantity:Headlight:
12 V, 30.0/30.0 W × 2
Handlebar-mounted light: 12 V, 35.0/36.5 W × 1 (YFM70KPAJ, YFM70KPHJ,
YFM70KPSJ, YFM70KPXJ)
Tail/brake light: 12 V, 5.0/21.0 W × 1
Meter lighting: EL (Electroluminescent) (YFM70KPAJ, YFM70KPHJ,
YFM70KPSJ, YFM70KPXJ)
Neutral indicator light: LED
Fuel level warning light:
LED (YFM70KDHJ, YFM70KDXJ)
Reverse indicator light: LED
Coolant temperature warning light: LED
EPS warning light:
LED (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Park indicator light:
LED
Four-wheel-drive indicator light: 12 V, 1.7 W × 1 (YFM70KDHJ, YFM70KDXJ)
Engine trouble warning light: LED High-range indicator light:
LED (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Low-range indicator light: LED (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Differential gear lock indicator light: LED (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Fuses:Main fuse:40.0 A
Fuel injection system fuse:
15.0 A
EPS fuse: 40.0 A (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Headlight fuse: 10.0 A (YFM70KDHJ, YFM70KDXJ)
15.0 A (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Signaling system fuse:
10.0 A
Ignition fuse: 10.0 A
Auxiliary DC jack fuse: 10.0 A
Four-wheel-drive motor fuse:
10.0 A (YFM70KPAJ, YFM70KPHJ, YFM70KPSJ,
YFM70KPXJ)
Radiator fan motor fuse:
20.0 A
