YAMAHA MT-07 2018 Owners Manual
Manufacturer: YAMAHA, Model Year: 2018, Model line: MT-07, Model: YAMAHA MT-07 2018Pages: 100, PDF Size: 5.44 MB
Page 91 of 100
Specifications
8-1
8
Dimensions:Overall length:2085 mm (82.1 in)
Overall width:
745 mm (29.3 in)
Overall height: 1090 mm (42.9 in)
Seat height: 805 mm (31.7 in)
Wheelbase:
1400 mm (55.1 in)
Ground clearance: 140 mm (5.51 in)
Minimum turning radius: 2.7 m (8.86 ft)Wei ght:Curb weight:
183 kg (403 lb)Engine:Combustion cycle:
4-stroke
Cooling system: Liquid cooled
Valve train: DOHC
Cylinder arrangement:
Inline
Number of cylinders: 2-cylinder
Displacement: 689 cm³
Bore × stroke:
80.0 × 68.6 mm (3.15 × 2.70 in) Compression ratio:
11.5 : 1
Starting system: Electric starter
Lubrication system:
Wet sump
Engine oil:Recommended brand:
YAMALUBE
SAE viscosity grades:
10W-40
Recommended engine oil grade: API service SG type or higher, JASO
standard MA
Engine oil quantity: Oil change:
2.30 L (2.43 US qt, 2.02 Imp.qt)
With oil filter removal: 2.60 L (2.75 US qt, 2.29 Imp.qt)Coolant quantity:Coolant reservoir (up to the maximum level
mark):0.25 L (0.26 US qt, 0.22 Imp.qt)
Radiator (including all routes):
1.60 L (1.69 US qt, 1.41 Imp.qt)Air filter:Air filter element:Oil-coated paper elementFuel:Recommended fuel:Regular unleaded gasoline (Gasohol [E10]
acceptable)
Fuel tank capacity: 14 L (3.7 US gal, 3.1 Imp.gal) Fuel reserve amount:
2.7 L (0.71 US gal, 0.59 Imp.gal)
Fuel injection:Throttle body:
ID mark:1WS1 10Spark plu g(s):Manufacturer/model:
NGK/LMAR8A-9
Spark plug gap: 0.8–0.9 mm (0.031–0.035 in)Clutch:Clutch type:Wet, multiple-discDrivetrain:Primary reduction ratio:
1.925 (77/40)
Final drive: Chain
Secondary reduction ratio: 2.688 (43/16)
Transmission type:
Constant mesh 6-speed
Gear ratio: 1st:
2.846 (37/13)
2nd: 2.125 (34/16)
3rd: 1.632 (31/19)
4th:
1.300 (26/20)
5th: 1.091 (24/22)
UB4CE0E0.book Page 1 Monday, December 11, 2017 3:53 PM
Page 92 of 100
Specifications
8-2
8
6th:0.964 (27/28)
Chassis:Frame type:
Diamond
Caster angle: 24.8 °
Trail: 90 mm (3.5 in)Front tire:Type:Tubeless
Size: 120/70 ZR 17M/C(58W)
Manufacturer/model:
MICHELIN/PILOT ROAD 4
Manufacturer/model: BRIDGESTONE/BT023F FRear tire:Type:
Tubeless
Size: 180/55 ZR 17M/C(73W)
Manufacturer/model: MICHELIN/PILOT ROAD 4
Manufacturer/model:
BRIDGESTONE/BT023R MLoa din g:Maximum load:
172 kg (379 lb)
(Total weight of rider, passenger, cargo
and accessories)
Tire air pressure (measure d on col d
tires):1 person:
Front: 225 kPa (2.25 kgf/cm², 33 psi)
Rear:
250 kPa (2.50 kgf/cm², 36 psi)
2 persons: Front:
225 kPa (2.25 kgf/cm², 33 psi)
Rear: 250 kPa (2.50 kgf/cm², 36 psi)Front wheel:Wheel type:
Cast wheel
Rim size: 17M/C x MT3.50Rear wheel:Wheel type:
Cast wheel
Rim size: 17M/C x MT5.50Front brake:Type:
Hydraulic dual disc brake
Specified brake fluid: DOT 4Rear brake:Type:
Hydraulic single disc brake
Specified brake fluid: DOT 4
Front suspension:Type:Telescopic fork
Spring:
Coil spring
Shock absorber: Hydraulic damper
Wheel travel: 130 mm (5.1 in)Rear suspension:Type:Swingarm (link suspension)
Spring: Coil spring
Shock absorber:
Gas-hydraulic damper
Wheel travel: 130 mm (5.1 in)Electrical system:System voltage:
12 V
Ignition system: TCI
Charging system: AC magnetoBattery:Model:YTZ10S
Voltage, capacity: 12 V, 8.6 Ah (10 HR)Hea dlig ht:Bulb type:
Halogen bulb
UB4CE0E0.book Page 2 Monday, December 11, 2017 3:53 PM
Page 93 of 100
Specifications
8-3
8
Bulb watta ge:Headlight:
H4, 60.0 W/55.0 W
Brake/tail light:
LED
Front turn signal light: 10.0 W
Rear turn signal light: 10.0 W
Auxiliary light:
5.0 W
License plate light: 5.0 W
Meter lighting: LED
Neutral indicator light:
LED
High beam indicator light: LED
Oil pressure warning light: LED
Turn signal indicator light:
LED
Coolant temperature warning light: LED
Engine trouble warning light: LED
ABS warning light:
LED
Immobilizer system indicator light: LEDFuse(s):Main fuse:
30.0 A Auxiliary fuse:
2.0 A
Headlight fuse: 15.0 A
Signaling system fuse:
10.0 A
Ignition fuse: 10.0 A
Parking lighting fuse: 7.5 A
Radiator fan motor fuse:
10.0 A
ABS control unit fuse: 7.5 A
ABS motor fuse: 30.0 A
ABS solenoid fuse:
20.0 A
Backup fuse: 7.5 A
Backup fuse 2: 10.0 A
UB4CE0E0.book Page 3 Monday, December 11, 2017 3:53 PM
Page 94 of 100
Consumer information
9-1
9
EAU53562
Id entification num bersRecord the vehicle identification num-
ber, engine serial number, and the
model label information in the spaces
provided below. These identification
numbers are needed when registering
the vehicle with the authorities in your
area and when ordering spare parts
from a Yamaha dealer.
VEHICLE IDENTIFICATION NUMBER:
ENGINE SERIAL NUMBER:
MODEL LABEL INFORMATION:
EAU26401
Vehicle i dentification num ber
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26442
En gine serial num ber
The engine serial number is stamped
into the crankcase.
EAU26521
Mo del la bel
1. Vehicle identification number
1
1. Engine serial number
1. Model label
1
1
UB4CE0E0.book Page 1 Monday, December 11, 2017 3:53 PM
Page 95 of 100
Consumer information
9-2
9
The model label is affixed to the frame
under the passenger seat. (See page
3-19.) Record the information on this
label in the space provided. This infor-
mation will be needed when ordering
spare parts from a Yamaha dealer.
EAU69910
Dia
gnostic connectorThe diagnostic connector is located as
shown.
EAU74702
Vehicle data recor din gThis model’s ECU stores certain vehi-
cle data to assist in the diagnosis of
malfunctions and for research and de-
velopment purposes. This data will be
uploaded only when a special Yamaha
diagnostic tool is attached to the vehi-
cle, such as when maintenance checks
or service procedures are performed.
Although the sensors and recorded
data will vary by model, the main data
points are:
Vehicle status and engine perfor-
mance data
Fuel-injection and emission-relat-
ed data
Yamaha will not disclose this data to a
third party except: With the consent of the vehicle
owner
Where obligated by law
For use by Yamaha in litigation
For general Yamaha-conducted
research purposes when the data
is not related to an individual vehi-
cle nor owner
1. Diagnostic connector
1
UB4CE0E0.book Page 2 Monday, December 11, 2017 3:53 PM
Page 96 of 100
10-1
10
IndexAABS ....................................................... 3-15
ABS warning light ................................... 3-5
Air filter element and check hose,
replacing and cleaning ....................... 6-14
Auxiliary DC connector ......................... 3-25
Auxiliary light bulb, replacing ................ 6-32BBattery .................................................. 6-28
Brake and clutch levers, checking and lubricating ........................................... 6-25
Brake and shift pedals, checking and
lubricating ........................................... 6-25
Brake fluid, changing ............................ 6-21
Brake fluid level, checking .................... 6-20
Brake lever ............................................ 3-14
Brake lever free play, checking............. 6-18
Brake light switches.............................. 6-19
Brake pedal........................................... 3-14
Brake/tail light ....................................... 6-33CCables, checking and lubricating ......... 6-24
Canister................................................... 6-9
Care ........................................................ 7-1
Catalytic converter ................................ 3-19
Clutch lever ........................................... 3-13
Clutch lever free play, adjusting ........... 6-18
Coolant ................................................. 6-12
Coolant temperature warning light ......... 3-4DData recording, vehicle ........................... 9-2
Diagnostic connector.............................. 9-2
Dimmer switch ...................................... 3-13
Drive chain, cleaning and lubricating .... 6-23 Drive chain slack .................................. 6-22
EEngine break-in ...................................... 5-3
Engine oil and oil filter
cartridge ............. 6-9
Engine serial number .............................. 9-1
Engine trouble warning light ................... 3-5FFront and rear brake pads, checking ... 6-19
Front fork, checking ............................. 6-27
Fuel ....................................................... 3-16
Fuel consumption, tips for reducing ...... 5-3
Fuel tank cap ........................................ 3-16
Fuel tank overflow hose ....................... 3-18
Fuses, replacing ................................... 6-29HHandlebar switches .............................. 3-12
Hazard switch....................................... 3-13
Headlight bulb, replacing ..................... 6-31
Helmet holding cable ........................... 3-21
High beam indicator light ....................... 3-4
Horn switch .......................................... 3-13IIdentification numbers ............................ 9-1
Ignition circuit cut-off system ............... 3-26
Immobilizer system ................................ 3-1
Immobilizer system indicator light .......... 3-5
Indicator lights and warning lights ......... 3-4LLicense plate light bulb, replacing........ 6-34
Luggage strap holders ......................... 3-24MMain switch/steering lock....................... 3-2
Maintenance and lubrication, periodic ... 6-4 Maintenance, emission control
system ..................................................6-3
Matte color, caution ................................7-1
Model label .............................................9-1
Multi-function meter unit .........................3-6
NNeutral indicator light ..............................3-4OOil pressure warning light .......................3-4PParking ....................................................5-4
Part locations ..........................................2-1
Pass switch ...........................................3-13SSafety information ...................................1-1
Seats .....................................................3-19
Shifting ....................................................5-2
Shift pedal .............................................3-14
Shock absorber assembly, adjusting ....3-23
Sidestand ..............................................3-25
Sidestand, checking and lubricating.....6-26
Spark plugs, checking ............................6-8
Specifications .........................................8-1
Start/Engine stop switch .......................3-13
Starting the engine ..................................5-1
Steering, checking ................................6-27
Storage ...................................................7-3
Storage compartment ...........................3-22
Supporting the motorcycle ...................6-35
Swingarm pivots, lubricating ................6-26TThrottle grip and cable, checking and lubricating ...........................................6-24
Throttle grip free play, checking ...........6-14
UB4CE0E0.book Page 1 Monday, December 11, 2017 3:53 PM
Page 97 of 100
Index
10-2
10
Tires ...................................................... 6-15
Tool kit .................................................... 6-2
Troubleshooting.................................... 6-35
Troubleshooting charts......................... 6-36
Turn signal indicator lights ..................... 3-4
Turn signal light bulb, replacing ........... 6-33
Turn signal switch................................. 3-13VValve clearance .................................... 6-15
Vehicle identification number ................. 9-1WWheel bearings, checking .................... 6-28
Wheels .................................................. 6-17
UB4CE0E0.book Page 2 Monday, December 11, 2017 3:53 PM
Page 98 of 100
A5-yoko_Blank.fm Page 1 Thursday, December 8, 2011 2:18 PM
Page 99 of 100
A5-yoko_Blank.fm Page 1 Thursday, December 8, 2011 2:18 PM
Page 100 of 100
DIC183
PRINTED ON RECYCLED PAPER
Original instructions
PRINTED IN JAPAN2017.12-1.5×1 CR (E)
