fuse YAMAHA MT-07 2022 Owners Manual
[x] Cancel search | Manufacturer: YAMAHA, Model Year: 2022, Model line: MT-07, Model: YAMAHA MT-07 2022Pages: 100, PDF Size: 3.66 MB
Page 9 of 100

Table of contents
Replacing the fuses .......................6-31
Vehicle lights .................................6-32
Replacing a license plate light
bulb ............................................6-32
Supporting the motorcycle............6-33
Troubleshooting ............................6-33
Troubleshooting chart ...................6-35
Motorcycle care an d stora ge ..........7-1
Matte color caution .........................7-1
Care .................................................7-1
Storage ............................................7-3
Specifications ....................................8-1
Consumer information .....................9-1
Identification numbers .....................9-1
Diagnostic connector ......................9-2
Vehicle data recording ....................9-2
In dex ................................................10-1
UBATE1E0.book Page 2 Thursday, September 2, 2021 10:34 AM
Page 15 of 100

Description
2-1
2
EAU10411
Left view
14567891023
1. Seat lock (page 3-19)
2. Battery (page 6-29)
3. Fuses (page 6-31)
4. Rebound damping force adjuster (page 3-21)
5. Shift pedal (page 3-13)
6. Engine oil filler cap (page 6-10)
7. Engine oil level check window (page 6-10)
8. Engine oil drain bolt (page 6-10)
9. Engine oil filter cartridge (page 6-10)
10.Coolant reservoir (page 6-13)
UBATE1E0.book Page 1 Thursday, September 2, 2021 10:34 AM
Page 81 of 100

Periodic maintenance an d a djustment
6-31
6
EAU59876
Replacin g the fusesThe main fuse and the fuse boxes,
which contain the fuses for the individ-
ual circuits, are located under the rider
seat. (See page 3-19.)TIPTo access the main fuse, remove the
starter relay cover as shown.
If a fuse is blown, replace it as follows. 1.
the electrical circuit in question.
2. Remove the blown fuse, and then install a new fuse of the specified
amperage. WARNING! Do not
use a fuse of a hi gher ampera ge
ratin g than recommen ded to
avoi d causin g extensive dam-
a g e to the electrical system an d
possi bly a fire.
[EWA15132]
1. Starter relay cover
2. Main fuse
3. Spare main fuse
4. Fuse box
1
2
3
4 4 4
1. Radiator fan motor fuse
2. Backup fuse (for clock and immobilizer sys-tem)
3. Fuel injection system fuse
4. Headlight fuse
5. Signaling system fuse
6. Ignition fuse
7. Spare fuse
8. ABS solenoid fuse
9. ABS motor fuse
10.Accessory fuse
11.ABS ECU fuse
12.Terminal fuse 11 8 9 10 11
12
7
7
2
3
4
5
6
UBATE1E0.book Page 31 Thursday, September 2, 2021 10:34 AM
Page 82 of 100

Periodic maintenance an d a djustment
6-32
6
3. Turn the key to “ON” and turn onthe electrical circuit in question to
check if the device operates.
4. If the fuse immediately blows again, have a Yamaha dealer
check the electrical system.
EAU80380
Vehicle lig htsExcept for the license plate light bulb,
this model’s lights are all LED.
If an LED light does not come on,
check the fuses and then have a
Yamaha dealer check the vehicle. If the license plate light does not come on,
check and replace the bulb. (See page
6-32.)NOTICE
ECA16581
Do not affix any type of tinte d film or
stickers to the hea dlig ht lens.
EAU92270
Replacin g a license plate li ght
b ul b1. Remove the license plate light unit
by removing the bolts and collars.
2. Remove the license plate light bulb socket (together with the
bulb) by turning it counterclock-
wise, and then pulling it out.
3. Remove the burnt-out bulb by pulling it out.
Specifie d fuses:
Main fuse:
30.0 A
Terminal fuse 1:
3.0 A
Headlight fuse: 7.5 A
Signaling system fuse: 7.5 A
Ignition fuse:
10.0 A
Radiator fan motor fuse: 10.0 A
ABS motor fuse: 30.0 A
ABS solenoid fuse:
20.0 A
ABS ECU fuse: 7.5 A
Fuel injection system fuse: 10.0 A
Backup fuse:
7.5 A
Accessory fuse: 7.5 A
1. Headlight
2. Auxiliary light
11
2
2
1
22
1. Bolt
2. Collar
3. License plate light bulb socket
4. License plate light unit
111 1
22
2
3
4
UBATE1E0.book Page 32 Thursday, September 2, 2021 10:34 AM
Page 96 of 100

10-1
10
IndexAABS ....................................................... 3-14
ABS warning light ................................... 3-5
Air filter element and check hose,
replacing and cleaning ....................... 6-15
Air temperature display......................... 3-10
Auxiliary DC connector ......................... 3-24BBattery .................................................. 6-29
Brake and clutch levers, checking and lubricating .................................... 6-27
Brake and shift pedals, checking and
lubricating ........................................... 6-26
Brake fluid, changing ............................ 6-23
Brake fluid level, checking .................... 6-21
Brake lever ............................................ 3-14
Brake lever free play, checking............. 6-20
Brake light switches.............................. 6-20
Brake pedal........................................... 3-14
Brightness control mode ...................... 3-11CCables, checking and lubricating ......... 6-25
Canister................................................. 6-10
Care ........................................................ 7-1
Catalytic converter ................................ 3-18
Clock....................................................... 3-7
Clutch lever ........................................... 3-13
Clutch lever free play, adjusting ........... 6-19
Coolant ................................................. 6-13
Coolant temperature display ................ 3-10
Coolant temperature warning light ......... 3-4DData recording, vehicle ........................... 9-2
Diagnostic connector.............................. 9-2 Dimmer switch...................................... 3-12
Display units, switching .......................... 3-6
Drive chain, cleaning and lubricating ... 6-25
Drive chain slack .................................. 6-23
EEco indicator .......................................... 3-7
Engine break-in ...................................... 5-1
Engine idling speed, checking ............. 6-15
Engine oil and oil filter
cartridge ........... 6-10
Engine overheating ............................... 6-36
Engine serial number .............................. 9-1FFront and rear brake pads, checking ... 6-21
Front fork, checking ............................. 6-28
Fuel ....................................................... 3-16
Fuel consumption, tips for reducing ...... 5-4
Fuel meter .............................................. 3-7
Fuel tank cap ........................................ 3-15
Fuel tank overflow hose ....................... 3-18
Fuses, replacing ................................... 6-31HHandlebar switches .............................. 3-11
Hazard switch....................................... 3-12
Helmet holding cable ........................... 3-20
High beam indicator light ....................... 3-3
Horn switch .......................................... 3-12IIdentification numbers ............................ 9-1
Ignition circuit cut-off system ............... 3-25
Immobilizer system ................................ 3-1
Immobilizer system indicator light .......... 3-5
Indicator lights and warning lights ......... 3-3LLicense plate light bulb, replacing........ 6-32 Luggage strap holders ..........................3-23
MMain switch/steering lock .......................3-2
Maintenance and lubrication, periodic....6-5
Maintenance, emission control
system ..................................................6-3
Malfunction indicator light (MIL)..............3-4
Matte color, caution ................................7-1
Model label .............................................9-1
Multi-function display .............................3-8
Multi-function meter unit .........................3-6NNeutral indicator light ..............................3-3OOil pressure warning light .......................3-3PParking ....................................................5-4
Part locations ..........................................2-1
Pass switch ...........................................3-12SSafety information ...................................1-1
Seats .....................................................3-19
Shifting ....................................................5-3
Shift pedal .............................................3-13
Shock absorber assembly, adjusting ....3-21
Sidestand ..............................................3-24
Sidestand, checking and lubricating.....6-27
Spark plugs, checking ............................6-9
Specifications .........................................8-1
Speedometer ..........................................3-6
Starting the engine ..................................5-2
Steering, checking ................................6-29
Stop/Run/Start switch ..........................3-12
Storage ...................................................7-3
