YAMAHA MT-10 2018 Owners Manual

Specifications
9-3
1
2
3
4
5
6
7
8910
11
12
Brake/tail light:LED
Front turn signal light:
LED
Rear turn signal light: LED
Auxiliary light: LED
License plate light:
LED
Meter lighting: LED
Neutral indicator light: LED
High beam indicator light:
LED
Oil pressure warning light: LED
Turn signal indicator light: LED
Coolant temperature warning light:
LED
Engine trouble warning light: LED
Steering damper warning light: LED
ABS warning light:
LED
Cruise control “SET” indicator light: LED
Cruise control “ON” indicator light: LED
Immobilizer system indicator light:
LED Shift timing indicator light:
LED
Traction control system indicator light:
LED
Fuse(s):Main fuse:50.0 A
Terminal fuse 1:
2.0 A
Headlight fuse: 10.0 A
Brake light fuse: 1.0 A
Signaling system fuse:
7.5 A
Ignition fuse: 15.0 A
Radiator fan motor fuse: 15.0 A
Sub radiator fan motor fuse:
10.0 A
Hazard fuse: 7.5 A
ABS ECU fuse: 7.5 A
Fuel injection system fuse:
15.0 A
ABS motor fuse: 30.0 A
ABS solenoid fuse: 10.0 A
Cruise control fuse:
1.0 A Backup fuse:
7.5 A
Electronic throttle valve fuse:
7.5 A
B67-9-E2.book 3 ページ ２０１８年６月５日　火曜日　午前９時７分

10-1
1
2
3
4
5
6
7
8
910
11
12
Consumer information
EAU53562
Identification numbersRecord the vehicle identification num-
ber, engine serial number, and the
model label information in the spaces
provided below. These identification
numbers are needed when registering
the vehicle with the authorities in your
area and when ordering spare parts
from a Yamaha dealer.
VEHICLE IDENTIFICATION NUM-
BER:
ENGINE SERIAL NUMBER:
MODEL LABEL INFORMATION:
EAU26401
Vehicle identification number
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in yourarea.
EAU26442
Engine serial number
The engine serial number is stamped
into the crankcase.
1. Vehicle identification number
1
1. Engine serial number
1
B67-9-E2.book 1 ページ ２０１８年６月５日　火曜日　午前９時７分

Consumer information
10-2
1
2
3
4
5
6
7
8
91011
12
EAU26481
Model label
The model label is affixed to the frame
under the seat. (See page 4-22.) Re-
cord the information on this label in the
space provided. This information will be
needed when ordering spare parts from
a Yamaha dealer.
EAU69910
Diagnostic connectorThe diagnostic connector is located as
shown.
EAU74702
Vehicle data recordingThis model’s ECU stores certain vehi-
cle data to assist in the diagnosis of
malfunctions and for research and de-
velopment purposes. This data will be
uploaded only when a special Yamaha
diagnostic tool is attached to the vehi-
cle, such as when maintenance checks
or service procedures are performed.
Although the sensors and recorded
data will vary by model, the main data
points are:
Vehicle status and engine perfor-
mance data

Fuel-injection and emission-relat-
ed data
Yamaha will not disclose this data to a
third party except:

With the consent of the vehicle
owner

Where obligated by law

For use by Yamaha in litigation

For general Yamaha-conducted
research purposes when the data
is not related to an individual vehi-
cle nor owner
1. Model label
1
1. Diagnostic connector
1
B67-9-E2.book 2 ページ ２０１８年６月５日　火曜日　午前９時７分

11-1
1
2
3
4
5
6
7
8
9
1011
12
IndexAABS ....................................................... 4-18
ABS warning light.................................... 4-6
Air filter element .................................... 7-15
Auxiliary DC jack ................................... 4-28BBattery................................................... 7-29
Brake and clutch levers, checking and lubricating .................................... 7-26
Brake and shift pedals, checking
and lubricating .................................... 7-25
Brake fluid, changing ............................ 7-22
Brake fluid level, checking .................... 7-21
Brake lever ............................................ 4-17
Brake lever free play, checking ............. 7-20
Brake light switches .............................. 7-20
Brake pedal ........................................... 4-17CCables, checking and lubricating .......... 7-25
Canister................................................. 7-10
Care ........................................................ 8-1
Catalytic converter ................................ 4-21
Clutch lever ........................................... 4-16
Clutch lever free play, adjusting ............ 7-19
Coolant.................................................. 7-14
Coolant temperature warning light .......... 4-6
Cruise control indicator lights .................. 4-5
Cruise control switches ........................... 4-4
Cruise control system ............................. 3-1DData recording, vehicle ......................... 10-2
Diagnostic connector ............................ 10-2
Dimmer/Pass switch ............................... 4-4
D-mode (drive mode) .............................. 3-3 Drive chain, cleaning and lubricating .... 7-24
Drive chain slack .................................. 7-23
Drive mode switch .................................. 4-4
EEngine break-in ...................................... 6-3
Engine idling speed, checking .............. 7-15
Engine oil .............................................. 7-10
Engine serial number............................ 10-1
Engine trouble warning light ................... 4-6
EXUP system ....................................... 4-27FFront and rear brake
pads, checking .... 7-21
Front fork, adjusting .............................. 4-23
Front fork, checking .............................. 7-27
Fuel....................................................... 4-19
Fuel consumption, tips for reducing........ 6-3
Fuel tank cap ........................................ 4-19
Fuel tank overflow hose........................ 4-21
Fuses, replacing ................................... 7-30HHandlebar switches ................................ 4-3
Hazard switch ......................................... 4-4
High beam indicator light ........................ 4-5
Horn switch ............................................. 4-4IIdentification numbers .......................... 10-1
Ignition circuit cut-off system ................ 4-29
Immobilizer system ................................. 4-1
Immobilizer system indicator light........... 4-7
Indicator lights and warning lights .......... 4-5LLuggage strap holders .......................... 4-27MMain switch/steering lock........................ 4-2 Maintenance and lubrication, periodic..... 7-5
Maintenance, emission control
system .................................................. 7-3
Matte color, caution ................................. 8-1
Model label ............................................ 10-2
Multi-function meter unit .......................... 4-8
NNeutral indicator light .............................. 4-5OOil pressure warning light........................ 4-5PParking .................................................... 6-4
Part locations .......................................... 2-1QQuick shift system ................................... 3-6SSafety information ................................... 1-1
Seat ....................................................... 4-22
SELECT switch ....................................... 4-4
Shift indicator light ................................... 4-7
Shifting .................................................... 6-2
Shift pedal ............................................. 4-16
Shock absorber assembly, adjusting .... 4-24
Sidestand .............................................. 4-28
Sidestand, checking an d lubricating...... 7-27
Spark plugs, checking ............................. 7-9
Special features ...................................... 3-1
Specifications .......................................... 9-1
Starting the engine .................................. 6-1
Steering, checking................................. 7-28
Steering damper warning light ................ 4-7
Stop/Run/Start switch.............................. 4-4
Storage.................................................... 8-4
Supporting the motorcycle .................... 7-33
B67-9-E2.book 1 ページ ２０１８年６月５日　火曜日　午前９時７分

Index
11-2
1
2
3
4
5
6
7
8
9
101112
Swingarm pivots, lubricating ................. 7-27TThrottle grip and cable, checking and lubricating .................................... 7-25
Throttle grip free play, checking ........... 7-16
Tires...................................................... 7-16
Tool kit .................................................... 7-2
Traction control system .......................... 3-4
Traction control system indicator light .... 4-7
Traction control system switch ............... 4-4
Troubleshooting .................................... 7-34
Troubleshooting charts ......................... 7-35
Turn signal indicator lights ...................... 4-5
Turn signal switch ................................... 4-4VValve clearance .................................... 7-16
Vehicle identification number................ 10-1
Vehicle lights ........................................ 7-33WWheel bearings, c hecking .................... 7-28
Wheels.................................................. 7-19
