5-8
A crash can damage the restraint systems in
your vehicle. A damaged restraint system
may not properly protect the person using it,
resulting in serious injury or death in a crash.
To help make sure your restraint systems are
working properly after a crash, have them in-
spected and any necessary replacements
made as soon as possible.EVU01230Steering
Park on level ground. Turn the steering wheel
right and left. Check for excessive free play,
abnormal noises, or a rough feeling. Have a
Yamaha dealer repair as necessary for proper
operation.EVU00470Fittings and fasteners
Always check the tightness of chassis fittings
and fasteners before a ride. Take the vehicle
to a Yamaha dealer or refer to the Service
Manual for correct tightening torque.Instruments, lights and switches
Check that all instruments, lights and switches
are working properly. Correct if necessary.
Control cables
When riding in cold weather, always make
sure all control cables work smoothly before
you begin riding.
WARNING! Control cables
can freeze in cold weather and you could
be unable to control the vehicle.1RB7A_EE.book Page 8 Tuesday, April 24, 2012 9:07 AM

8-45
The tires listed below have been approved by
Yamaha Motor Manufacturing Corporation of America for this model.
EVU00940Wheel installation
1. Install the wheel and the nuts.
●
The arrow mark on the tire must
point toward the rotating direction of
the wheel.
●
Tapered nuts are used for both the
front and rear wheels. Install the nuts
with their tapered side towards the
wheel.
2. Lower the vehicle so that the wheel is on the ground.
3. Tighten the wheel nuts in crisscross pat-
tern to the specified torque.
WARNING
Do not reverse the rims on the Rhino to
widen the track width. Installing wheels
improperly increases the risk of wheel fail-
ure and accidents.
Manufacturer SizeType
Front MAXXIS 25 × 8-12NHS M951Y
Rear MAXXIS 25 × 10-12NHS M952Y
1RB7A_EE.book Page 45 Tuesday, April 24, 2012 9:07 AM

8-46
1. Arrow mark
1. Tapered nut
1
Wheel nut torque:
Front: 55 Nm (5.5 m·kgf, 40 ft·lbf)
Rear: 55 Nm (5.5 m·kgf, 40 ft·lbf)
