Specifications
8-3
8
Neutral indicator light:LED
High beam indicator light: LED
Oil level warning light:
LED
Turn signal indicator light: LED
Fuel level warning light: LED
Engine trouble warning light:
LED
ABS warning light: LED
Immobilizer system indicator light: LEDFuse(s):Main fuse:40.0 A
Headlight fuse: 20.0 A
Signaling system fuse:
7.5 A
Ignition fuse: 15.0 A
Parking lighting fuse: 15.0 A
Fuel injection system fuse:
10.0 A
ABS control unit fuse: 7.5 A
ABS motor fuse: 30.0 A ABS solenoid fuse:
15.0 A
Backup fuse: 7.5 A
UBL3E0E0.book Page 3 Tuesday, November 15, 2016 2:38 PM

Consumer information
9-1
9
EAU53562
Id entification num bersRecord the vehicle identification num-
ber, engine serial number, and the
model label information in the spaces
provided below. These identification
numbers are needed when registering
the vehicle with the authorities in your
area and when ordering spare parts
from a Yamaha dealer.
VEHICLE IDENTIFICATION NUMBER:
ENGINE SERIAL NUMBER:
MODEL LABEL INFORMATION:
EAU26401
Vehicle i dentification num ber
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26442
En gine serial num ber
The engine serial number is stamped
into the crankcase.
EAU36981
Mo del la bel
1. Vehicle identification number
1
1. Engine serial number
1. Model label
1
1
UBL3E0E0.book Page 1 Tuesday, November 15, 2016 2:38 PM

Consumer information
9-2
9
The model label is affixed to the frame
behind panel B. (See page 6-9.) Re-
cord the information on this label in the
space provided. This information will
be needed when ordering spare parts
from a Yamaha dealer.
EAU69910
Dia
gnostic connectorThe diagnostic connector is located as
shown.
EAU74701
Vehicle data recor din gThis model’s ECU stores certain vehi-
cle data to assist in the diagnosis of
malfunctions and for research and de-
velopment purposes. This data will be
uploaded only when a special Yamaha
diagnostic tool is attached to the vehi-
cle, such as when maintenance checks
or service procedures are performed.
Although the sensors and recorded
data will vary by model, the main data
points are:
 Vehicle status and engine perfor-
mance data
 Fuel-injection and emission-relat-
ed data
Yamaha will not disclose this data to a
third party except:  With the consent of the vehicle
owner
 Where obligated by law
 For use by Yamaha in litigation
 For general Yamaha-conducted
research purposes when the data
is not related to an individual vehi-
cle nor owner
1. Diagnostic connector
1
UBL3E0E0.book Page 2 Tuesday, November 15, 2016 2:38 PM

10-1
10
IndexAABS ....................................................... 3-10
ABS warning light ................................... 3-4
Air filter element, replacing ................... 6-15
Auxiliary light bulb, replacing ................ 6-31BBattery .................................................. 6-27
Brake and clutch levers, checking and
lubricating ........................................... 6-25
Brake and shift pedals, checking and lubricating ........................................... 6-24
Brake fluid, changing ............................ 6-22
Brake fluid level, checking .................... 6-21
Brake lever .............................................. 3-9
Brake lever free play, checking............. 6-19
Brake light switches.............................. 6-20
Brake pedal............................................. 3-9
Brake/tail light ....................................... 6-32CCables, checking and lubricating ......... 6-23
Canister................................................. 6-12
Care ........................................................ 7-1
Catalytic converter ................................ 3-13
Clutch lever ............................................. 3-8
Clutch lever free play, adjusting ........... 6-19DData recording, vehicle ........................... 9-2
Diagnostic connector.............................. 9-2
Dimmer switch ........................................ 3-7
Drive belt slack ..................................... 6-23EEngine break-in....................................... 5-3
Engine oil and oil filter cartridge ........... 6-12
Engine serial number .............................. 9-1 Engine trouble warning light ................... 3-4
FFront and rear brake pads, checking ... 6-20
Front fork, checking ............................. 6-26
Fuel ....................................................... 3-11
Fuel consumption, tips for reducing ...... 5-3
Fuel level warning light ........................... 3-4
Fuel tank breather/overflow hose ......... 3-13
Fuel tank cap ........................................ 3-11
Fuses, replacing ................................... 6-28HHandlebar switches ................................ 3-7
Hazard switch......................................... 3-8
Headlight bulb, replacing ..................... 6-30
High beam indicator light ....................... 3-3
Horn switch ............................................ 3-8IIdentification numbers ............................ 9-1
Ignition circuit cut-off system ............... 3-16
Immobilizer system ................................ 3-1
Immobilizer system indicator light .......... 3-5
Indicator lights and warning lights ......... 3-3LLicense plate light bulb, replacing........ 6-33MMain switch ............................................ 3-2
Maintenance and lubrication, periodic ... 6-5
Maintenance, emission control
system.................................................. 6-3
Matte color, caution ............................... 7-1
Model label ............................................. 9-1
Multi-function meter unit ........................ 3-5NNeutral indicator light ............................. 3-3
OOil level warning light ..............................3-3PPanels, removing and installing ..............6-9
Parking ....................................................5-4
Part locations ..........................................2-1
Pass switch .............................................3-7SSafety information ...................................1-1
SELECT switch .......................................3-8
Shifting ....................................................5-2
Shift pedal ...............................................3-9
Shock absorber assemblies, adjusting .............................................3-15
Sidestand ..............................................3-16
Sidestand, checking and lubricating.....6-25
Spark plugs, checking ..........................6-11
Specifications .........................................8-1
Start/Engine stop switch .........................3-8
Starting the engine ..................................5-1
Steering, checking ................................6-26
Steering lock .........................................3-14
Storage ...................................................7-3
Supporting the motorcycle ...................6-33TThrottle grip and cable, checking and lubricating ...........................................6-24
Throttle grip free play, checking ...........6-16
Tires ......................................................6-16
Tool kit ....................................................6-2
Troubleshooting ....................................6-34
Troubleshooting chart ...........................6-35
Turn signal indicator light........................3-3
Turn signal light bulb, replacing ............6-32
UBL3E0E0.book Page 1 Tuesday, November 15, 2016 2:38 PM

Index
10-2
10
Turn signal switch................................... 3-8VValve clearance .................................... 6-16
Vehicle identification number ................. 9-1WWheel bearings, checking .................... 6-27
Wheels .................................................. 6-18
UBL3E0E0.book Page 2 Tuesday, November 15, 2016 2:38 PM
