Safety information
14
contact with the rotating parts of the jet
pump.
Stop the engine and remove the clip from
the engine shut-off switch before removing
any debris or weeds, which may have col-
lected around the jet intake.
Avoid forceful jet thrust and limited visibility
while reboarding. Get to a standing or
kneeling position quickly. This will improve
visibility and limit exposure to jet thrust.
EJU30971
Safe boating rules
Your Yamaha watercraft is legally considered
a powerboat. Operation of the watercraft
must be in accordance with the rules and
regulations governing the waterway on which
it is used.
1 Intake grate
2 Jet thrust nozzle
1 Clip
2 Engine shut-off switch
1
2
1 2
UF4R71E0.book Page 14 Monday, May 10, 2021 1:14 PM

Safety information
15
EJU30992
Enjoy your watercraft responsibly
You share the areas you enjoy when riding
your watercraft with others and with nature.
So your enjoyment includes a responsibility
to treat these other people, and the lands,
waters, and wildlife with respect and courte-
sy.
Whenever and wherever you ride, think of
yourself as the guest of those around you.
Remember, for example, that the sound of
your watercraft may be music to you, but it
could be just noise to others. And the exciting
splash of your wake can make waves others
won’t enjoy.
Avoid riding close to shoreline homes and
waterfowl nesting areas or other wildlife ar-
eas, and keep a respectful distance from fish-
ermen, other boats, swimmers, and
populated beaches. When travel in areas like
these is unavoidable, ride slowly and obey all
laws.
Proper maintenance is necessary to ensure
that the exhaust emission and sound levels of
your watercraft will continue to be within reg-
ulated limits. You have the responsibility to
make sure that the recommended mainte-
nance in this owner’s/operator’s manual is
carried out.
Remember, pollution can be harmful to the
environment. Do not refuel or add oil where a
spill could cause damage to nature. Remove
your watercraft from the water and move it
away from the shoreline before refueling. Dis-
pose of water and any fuel and oil residue in
the engine compartment according to local
regulations. And keep your surroundings
pleasant for the people and wildlife that share
the waterways: don’t litter. When you ride responsibly, with respect and
courtesy for others, you help ensure that our
waterways stay open for the enjoyment of a
variety of recreational opportunities.
UF4R71E0.book Page 15 Monday, May 10, 2021 1:14 PM

Description
16
EJU40654
Watercraft glossary
Trolling speed
“Trolling” is the lowest maneuvering speed. You are applying little or no throttle. The water-
craft is down in the water, and there is no wake.
Sub-planing speed
“Sub-planing” is a medium speed. The bow of the watercraft is slightly up from the water sur-
face, but you are still traveling through the water. There is a wake.
Planing speed
“Planing” is a faster speed. The watercraft is more level and is skimming on top of the water.
There is a wake.
Bow
The front end of the watercraft.
Stern
The rear end of the watercraft.
Starboard
The right side of the watercraft when facing forward.
Port
The left side of the watercraft when facing forward.
Bilge water
Water that has collected in the engine compartment.
UF4R71E0.book Page 16 Monday, May 10, 2021 1:14 PM

Description
17
EJU31012
Location of main components
Exterior
1
23
4
5
6
8
9
10
11
14
16
15
14
13
8
12
7
1Fuel filler cap (page 31)
2 Steering pole
3 Steering pole cover
4 Hood
5 Storage pouch
6 Cooling water pilot outlet (page 22)
7 Bow eye (page 28)
8 Handlebar
9 Hood latch
10 Reboarding holder (page 28) 11
Riding tray
12 Intake grate
13 Stern eye (page 28)
14 Stern drain plug (page 35)
15 Jet thrust nozzle
16 Ride plate
UF4R71E0.book Page 17 Monday, May 10, 2021 1:14 PM

Description
18
1
237
46
5
1Fire extinguisher holder (page 29)
2 Start switch
3 Throttle lever
4 Clip (page 20)
5 Engine stop/“L-MODE” switch (page 20)
6 Engine shut-off cord (lanyard) (page 20)
7 Engine shut-off switch (page 20)
UF4R71E0.book Page 18 Monday, May 10, 2021 1:14 PM

Description
19
Engine compartment
1
2
3
4
5
6
1Oil tank filler cap/Dipstick (page 33)
2 Fuel tank
3 Water separator (page 22)
4 Flushing hose connector (page 57)
5 Spark plug/Ignition coil
6 Battery (page 42)
UF4R71E0.book Page 19 Monday, May 10, 2021 1:14 PM

Control function operation
20
EJU31027
Watercraft control functionsEJU45552Engine stop/“L-MODE” switch “ ”
The engine stop/“L-MODE” switch (red but-
ton) stops the engine when the switch is
pushed. You can also activate L-MODE.
EJU31164Engine shut-off switch “ ”
The engine shut-off switch automatically
stops the engine when the clip, on the end of
the engine shut-off cord (lanyard), is removed
from the switch, such as if the operator falls
off the watercraft.
Insert the clip under the engine shut-off
switch before starting the engine.
When the engine is not running, remove the
clip from the engine shut-off switch to pre-vent accidental starting or unauthorized op-
eration by children or others.
EJU45561Start switch “ ”ECJ01361
Do not run the engine for more than 15
seconds on land without supplying water,
otherwise the engine could overheat.
The start switch (green button) starts the en-
gine when the switch is pushed.
Release the start switch as soon as the en-
gine starts to run. If the engine does not start
in 5 seconds, release the start switch, wait 15
seconds, and then try again.
NOTICE: Never
push the start switch while the engine is
running. Do not operate the start switch
for more than 5 seconds, otherwise the
battery will be discharged and the engine
1 Engine stop/“L-MODE” switch
1 Clip
2 Engine shut-off switch
3 Engine shut-off cord (lanyard)
1
1
2
3
UF4R71E0.book Page 20 Monday, May 10, 2021 1:14 PM

Control function operation
21
will not start. Also, the starter motor could
be damaged.
[ECJ01041]
The engine will not start under any of the fol-
lowing conditions:
Clip is removed from the engine shut-off
switch.
Throttle lever is squeezed.EJU31212Throttle lever
The throttle lever increases the engine speed
when the lever is squeezed.
The throttle lever returns automatically to its
fully closed (idle) position when released.
EJU35934Steering system
By turning the handlebars in the direction you
wish to travel, the angle of the jet thrust noz-zle is changed, and the direction of the water-
craft is changed accordingly.
Since the strength of the jet thrust determines
the speed and degree of a turn, throttle must
always be applied when attempting a turn,
except at trolling speed.
The angle of the jet thrust nozzle can be ad-
justed to suit operator preference. (See page
64 for information on adjusting the jet thrust
nozzle angle.)
1
Start switch
1 Throttle lever
1
1
1Handlebar
2 Jet thrust nozzle
1
2
UF4R71E0.book Page 21 Monday, May 10, 2021 1:14 PM

Control function operation
22
EJU31273Steering pole
The steering pole can be moved up or down
to change the height of the handlebars.
EJU35975Cooling water pilot outlet
When the engine is running, some of the
cooling water that is circulated in the engine
is discharged from the cooling water pilot
outlet.
There is a cooling water pilot outlet on the
port (left) side of the watercraft. To check for
proper operation of the cooling system, make
sure that water is being discharged from the
cooling water pilot outlet. If water is not being
discharged from the outlet, stop the engine
and check the jet intake for clogging. (See
page 72 for information on the jet intake.)
TIP:
It will take about 60 seconds for the water
to reach the outlet after the engine is start-
ed.
Water discharge may not be constant
when the engine is running at idling speed.
If this occurs, apply a little throttle to make
sure that water discharges properly.
EJU40323Water separator
The water separator prevents water from en-
tering the fuel tank by collecting any water
that has entered the fuel tank breather hose if
the watercraft was capsized.
If water has collected in the water separator,
drain it by loosening the drain screw.
To drain water from the water separator:
(1) Place a drain pan or dry cloth under thewater separator.
(2) Gradually loosen the drain screw to drain the water. Catch the draining water in the
drain pan or soak it up with the dry cloth
so that it does not spill into the engine
compartment. If any water spills into the
watercraft, be sure to wipe it up with a
dry cloth.
(3) Securely tighten the drain screw until it stops.1Cooling water pilot outlet
1
1Water separator
2 Drain screw
2
1
UF4R71E0.book Page 22 Monday, May 10, 2021 1:14 PM

Watercraft operation
23
EJU40003
Watercraft operation modes
EJU45572L-MODE
The L-MODE is a function that limits the max-
imum engine speed to approximately 85% of
the maximum engine speed in the normal
mode.
TIP:
The L-MODE can only be activated when the
engine is stopped.
Activating and deactivating the L-MODE
Activation of the L-MODE will be confirmed
by the “L-MODE” indicator light. (See page
24 for information on the indicator lights.)
To activate the L-MODE:
(1) Briefly push the start switch to turn the power on.
(2) Push the engine stop/“L-MODE” switch three times. (3) “L-MODE” indicator light comes on and
the L-MODE is activated.
To deactivate the L-MODE:
To deactivate the L-MODE, follow the same
procedure as for activating the L-MODE.
1 Engine stop/“L-MODE” switch
1
1“L-MODE” indicator light
1
