Periodic maintenance and adjustment
6-33
6
EAUN2261
Vehicle lightsThis model is equipped with LED lights
for headlights, auxiliary lights and
brake/tail light. If a light does not come
on, check the fuse and then have a
Yamaha dealer check the vehicle.NOTICE
ECA16581
Do not affix any type of tinted film or
stickers to the headlight lens.
EAU24182
Tail/brake lightThis model is equipped with an LED-
type tail/brake light.
If the tail/brake light does not come on,
have a Yamaha dealer check it.
EAU24205
Replacing a turn signal light
bulb1. Remove the turn signal light lens
by removing the screw.
2. Remove the burnt-out bulb by
pushing it in and turning it coun-
terclockwise.1. Turn signal light lens
2. Screw
1
2
UBW3E0E0.book Page 33 Friday, May 24, 2019 11:01 AM

Periodic maintenance and adjustment
6-34
6 3. Insert a new bulb into the socket,
push it in, and then turn it clock-
wise until it stops.
4. Install the lens by installing the
screw. NOTICE: Do not over-
tighten the screw, otherwise the
lens may break.
[ECA11192]EAU24331
License plate lightIf the license plate light does not come
on, have a Yamaha dealer check the
electrical circuit or replace the bulb.
EAUM4210
Supporting the motorcycleSince this model is not equipped with a
centerstand, use a motorcycle jack
when removing the front or rear wheel
or when performing other maintenance
that requires the motorcycle to stand
upright.
To elevate the vehicle
1. Remove cowling A. (See page
6-9.)
2. If necessary, insert a piece of
wood between the motorcycle
jack and the engine crankcase.
Then lift the vehicle just enough to
raise the wheels from the ground.
NOTICE: Do not lift the motorcy-
1. Turn signal light bulb
1
1. Motorcycle jack
1
UBW3E0E0.book Page 34 Friday, May 24, 2019 11:01 AM

Specifications
8-2
8
Manufacturer/model:
PIRELLI/SCORPION RALLY STR ARear tire:Type:
With tube
Size:
150/70 R18 M/C 70V M+S
Manufacturer/model:
PIRELLI/SCORPION RALLY STRLoading:Maximum load:
190 kg (419 lb)
(Total weight of rider, passenger, cargo and
accessories)Front brake:Type:
Hydraulic dual disc brakeRear brake:Type:
Hydraulic single disc brakeFront suspension:Type:
Telescopic forkRear suspension:Type:
Swingarm (link suspension)Electrical system:System voltage:
12 VBattery:Model:
YTZ10S
Voltage, capacity:
12 V, 8.6 Ah (10 HR)
Bulb wattage:Headlight:
LED
Brake/tail light:
LED
Front turn signal light:
10.0 W × 2
Rear turn signal light:
10.0 W × 2
Auxiliary light:
LED
License plate light:
5.0 W × 1
