Instrument and control functions
3-27
3
EAUM4130
Front fen der To suit the riding conditions, the front
fender height can be adjusted.
To a djust the front fen der hei ght
1. Loosen the bolts on each side of the front fender.
2. Move the front fender to the de- sired height.
3. Tighten the bolts to the specified torque.
EAUM4201
DC power outletsThis vehicle is equiped with an auxiliary
DC jack, and auxiliary DC connector, a
grip warmer connector and a fog lamp
DC connector.NOTICE
ECA26810
Do not use any sin gle electrical ac-
cessory or com bination of accesso-
ries that require more than the
state d capacity at any one time. This
may overloa d the circuit an d cause
the fuse to blow.TIPTo prevent battery drain, do not use an
accessory with the engine off.
Auxiliary DC jack
A 12-V accessory with the proper con-
nector can be used when the main
switch is on.
To use the auxiliary DC jack
1. Turn the vehicle power off.
2. Remove the auxiliary DC jack cap.
3. Turn the accessory off.
4. Insert the accessory plug into the auxiliary DC jack.
1. BoltTightenin g torque:
Front fender bolt: 7.5 N·m (0.75 kgf·m, 5.6 lb·ft)
1
DC power outlet circuit capacities:
DC jack and DC connector circuit:24 W (2 A)
Grip warmer and Fog lamp circuit:
120 W (10 A)
1. Auxiliary DC jack cap
1
UBEHE1E0.book Page 27 Friday, October 1, 2021 10:36 AM

Specifications
8-2
8
Speed rating:240 km/h (149 mph)
Manufacturer/model: PIRELLI/SCORPION RALLY STR ARear tire:Type:With tube
Size: 150/70 R18 M/C 70V M+S
Speed rating:
240 km/h (149 mph)
Manufacturer/model: PIRELLI/SCORPION RALLY STROptional tire:Front tire:
Type:With tube
Size:
90/90 – 21 M/C 54R M+S
Speed rating: 170 km/h (105 mph)
Manufacturer/model: MICHELIN/ANAKEE WILD
Rear tire:
Type: With tube
Size:
150/70 R18 M/C 70R M+S
Speed rating: 170 km/h (105 mph)
Manufacturer/model: MICHELIN/ANAKEE WILD
Loa din g:Maximum load:
190 kg (419 lb)
(Total weight of rider, passenger, cargo and
accessories)Front brake:Type:
Hydraulic dual disc brakeRear brake:Type:
Hydraulic single disc brakeFront suspension:Type:
Telescopic forkRear suspension:Type:Swingarm (link suspension)Electrical system:System voltage:12 VBattery:Model:
YTZ10S
Voltage, capacity: 12 V, 8.6 Ah (10 HR)Bul b watta ge:Headlight:
LED
Brake/tail light: LED
Front turn signal light: 10.0 W × 2
Rear turn signal light:
10.0 W × 2 Auxiliary light:
LED
License plate light: 5.0 W × 1
