EAU54020
Replacing the fuses The main fuse box and the fuse box,
which contains the fuses for the individ-
ual circuits, are located under panel A.
(See page 6-8.)
If a fuse is blown, replace it as follows.1. Turn the key to “OFF” and turn off the electrical circuit in question.
2. Remove the blown fuse, and then install a new fuse of the specified
amperage. WARNING! Do not
use a fuse of a higher amperage
rating than recommended to
avoid causing extensive dam-
age to the electrical system and
possibly a fire.
[EWA15131]
For XP500 For XP500A
1. Main fuse
2. Spare main fuse
3. Main fuse box cover
1
2
3
1. Main fuse
2. ABS motor fuse
3. ABS solenoid fuse
4. Spare main fuse
5. Main fuse box cover
1
4
5
2
3
