Specifications
8-1
8
Dimensions:Overall length:2140 mm (84.3 in)
Overall width:
835 mm (32.9 in)
Overall height: 1290/1330 mm (50.8/52.4 in)
Seat height: 835 mm (32.9 in)
Wheelbase:
1460 mm (57.5 in)
Ground clearance: 140 mm (5.51 in)
Minimum turning radius: 2.7 m (8.86 ft)Wei ght:Curb weight:
196 kg (432 lb)Engine:Engine type:
Liquid cooled 4-stroke, DOHC
Cylinder arrangement: Inline 2-cylinder
Displacement: 689 cm³
Bore × stroke:
80.0 × 68.6 mm (3.15 × 2.70 in)
Starting system: Electric starter
Engine oil:Recommended brand:
SAE viscosity grades:
10W-40
Recommended engine oil grade: API service SG type or higher, JASO
standard MA
Engine oil quantity: Without oil filter cartridge replacement:2.30 L (2.43 US qt, 2.02 Imp.qt)
With oil filter cartridge replacement: 2.60 L (2.75 US qt, 2.29 Imp.qt)Coolant quantity:Coolant reservoir (up to the maximum level
mark):
0.25 L (0.26 US qt, 0.22 Imp.qt)
Radiator (including all routes): 1.60 L (1.69 US qt, 1.41 Imp.qt)
Fuel:Recommended fuel:Unleaded gasoline (E10 acceptable)
Octane number (RON):
90
Fuel tank capacity: 17.0 L (4.49 US gal, 3.74 Imp.gal)
Fuel reserve amount: 3.5 L (0.92 US gal, 0.77 Imp.gal)Fuel injection:Throttle body:ID mark:
1WS1 11Drivetrain:Gear ratio:
1st: 2.846 (37/13)
2nd: 2.125 (34/16)
3rd:
1.632 (31/19)
4th: 1.300 (26/20)
5th: 1.091 (24/22)
6th:
0.964 (27/28)Front tire:Type:Tubeless
Size:
120/70 ZR 17 M/C (58W)
Manufacturer/model: MICHELIN/PILOT ROAD 4
–20 –10 0 1020 30 40 50 C
10 30 50 70 90 110
0 130 F
SAE 10W-40
UB4TEAE0.book Page 1 Tues day, October 26, 2021 4:00 PM
Page 92 of 100
Specifications
8-2
8
Rear tire:Type:Tubeless
Size:
180/55 ZR 17 M/C (73W)
Manufacturer/model: MICHELIN/PILOT ROAD 4 R TLLoa din g:Maximum load:
181 kg (399 lb)
(Total weight of rider, passenger, cargo and
accessories)Front brake:Type:
Hydraulic dual disc brakeRear brake:Type:
Hydraulic single disc brakeFront suspension:Type:Telescopic forkRear suspension:Type:
Swingarm (link suspension)Electrical system:System voltage:12 VBattery:Model:YTZ7S
Voltage, capacity: 12 V, 6.3 Ah (20 HR)
Bul b watta ge:Headlight:
LED
Brake/tail light:
LED
Front turn signal light: LED
Rear turn signal light: LED
Auxiliary light:
LED
License plate light: 5.0 W × 1
UB4TEAE0.book Page 2 Tues day, October 26, 2021 4:00 PM
Page 93 of 100
Consumer information
9-1
9
EAU53562
Id entification num bersRecord the vehicle identification num-
ber, engine serial number, and the
model label information in the spaces
provided below. These identification
numbers are needed when registering
the vehicle with the authorities in your
area and when ordering spare parts
from a Yamaha dealer.
VEHICLE IDENTIFICATION NUMBER:
ENGINE SERIAL NUMBER:
MODEL LABEL INFORMATION:
EAU26401
Vehicle i dentification num ber
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26442
En gine serial num ber
The engine serial number is stamped
into the crankcase.
EAU26521
Mo del la bel
1. Vehicle identification number
1
1. Engine serial number
1. Model label
1
1
ZAUM1423
UB4TEAE0.book Page 1 Tues day, October 26, 2021 4:00 PM
Page 94 of 100
Consumer information
9-2
9The model label is affixed to the frame
under the passenger seat. Record the
information on this label in the space
provided. This information will be
needed when ordering spare parts
from a Yamaha dealer.
EAU69910
Dia
gnostic connectorThe diagnostic connector is located as
shown.
EAU85300
Vehicle data recor din gThis model’s ECU stores certain vehi-
cle data to assist in the diagnosis of
malfunctions and for research, statisti-
cal analysis and development purpos-
es.
Although the sensors and recorded
data will vary by model, the main data
points are:
Vehicle status and engine perfor-
mance data
Fuel-injection and emission-relat-
ed data
This data will be uploaded only when a
special Yamaha diagnostic tool is at-
tached to the vehicle, such as when
maintenance checks or service proce-
dures are performed.
Vehicle data uploaded will be handled
appropriately according to the follow-
ing Privacy Policy.
Privacy Policy
1. Diagnostic connector
1
https://www.yamaha-motor.eu/eu/
en/privacy/privacy-policy/
UB4TEAE0.book Page 2 Tues day, October 26, 2021 4:00 PM
Page 95 of 100
Consumer information
9-3
9
Yamaha will not disclose this data to a
third party except in the following cas-
es. In addition, Yamaha may provide
vehicle data to a contractor in order to
outsource services related to the han-
dling of vehicle data. Even in this case,
Yamaha will require the contractor to properly handle the vehicle data we
provided and Yamaha will appropriate-
ly manage the data. With the consent of the vehicle
owner
Where obligated by law
For use by Yamaha in litigation
When the data is not related to an
individual vehicle nor owner
