Motorcycle care and storage
7-3
7 2. Apply a corrosion protection spray
on all metal, including chrome-
and nickel-plated, surfaces to pre-
vent corrosion.
After cleaning
1. Dry the motorcycle with a chamois
or an absorbing cloth.
2. Immediately dry the drive chain
and lubricate it to prevent it from
rusting.
3. Use a chrome polish to shine
chrome, aluminum and stainless-
steel parts, including the exhaust
system. (Even the thermally in-
duced discoloring of stainless-
steel exhaust systems can be re-
moved through polishing.)
4. To prevent corrosion, it is recom-
mended to apply a corrosion pro-
tection spray on all metal,
including chrome- and nickel-plat-
ed, surfaces.
5. Use spray oil as a universal clean-
er to remove any remaining dirt.
6. Touch up minor paint damage
caused by stones, etc.
7. Wax all painted surfaces.
8. Let the motorcycle dry completely
before storing or covering it.
WARNING
EWA11132
Contaminants on the brakes or tires
can cause loss of control.
Make sure that there is no oil or
wax on the brakes or tires.
If necessary, clean the brake
discs and brake linings with a
regular brake disc cleaner or
acetone, and wash the tires with
warm water and a mild deter-
gent. Before riding at higherspeeds, test the motorcycle’s
braking performance and cor-
nering behavior.
NOTICE
ECA10801
Apply spray oil and wax spar-
ingly and make sure to wipe off
any excess.
Never apply oil or wax to any
rubber and plastic parts, but
treat them with a suitable care
product.
Avoid using abrasive polishing
compounds as they will wear
away the paint.
TIP
Consult a Yamaha dealer for ad-
vice on what products to use.
Washing, rainy weather or humid
climates can cause the headlight
lens to fog. Turning the headlight
on for a short period of time will
help remove the moisture from the
lens.
UBC6E2E0.book Page 3 Tuesday, July 10, 2018 6:26 PM
Page 92 of 102
Motorcycle care and storage
7-4
7
EAU26183
Storage
Short-term
Always store your motorcycle in a cool,
dry place and, if necessary, protect it
against dust with a porous cover. Be
sure the engine and the exhaust sys-
tem are cool before covering the mo-
torcycle.
NOTICE
ECA10811
Storing the motorcycle in a
poorly ventilated room or cover-
ing it with a tarp, while it is still
wet, will allow water and humid-
ity to seep in and cause rust.
To prevent corrosion, avoid
damp cellars, stables (because
of the presence of ammonia)
and areas where strong chemi-
cals are stored.
Long-term
Before storing your motorcycle for sev-
eral months:
1. Follow all the instructions in the
“Care” section of this chapter.
2. Fill up the fuel tank and add fuel
stabilizer (if available) to prevent
the fuel tank from rusting and the
fuel from deteriorating.
3. Perform the following steps to
protect the cylinders, piston rings,
etc. from corrosion.
a. Remove the spark plug caps
and spark plugs.
b. Pour a teaspoonful of engine
oil into each spark plug bore.
c. Install the spark plug caps onto
the spark plugs, and then
place the spark plugs on thecylinder head so that the elec-
trodes are grounded. (This will
limit sparking during the next
step.)
d. Turn the engine over several
times with the starter. (This will
coat the cylinder walls with oil.)
WARNING! To prevent dam-
age or injury from sparking,
make sure to ground the
spark plug electrodes while
turning the engine over.
[EWA10952]
e. Remove the spark plug caps
from the spark plugs, and then
install the spark plugs and the
spark plug caps.
4. Lubricate all control cables and
the pivoting points of all levers and
pedals as well as of the side-
stand/centerstand.
5. Check and, if necessary, correct
the tire air pressure, and then lift
the motorcycle so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
6. Cover the muffler outlet with a
plastic bag to prevent moisture
from entering it.
7. Remove the battery and fully
charge it. Store it in a cool, dry
place and charge it once a month.
Do not store the battery in an ex-
cessively cold or warm place [less
than 0 °C (30 °F) or more than 30
°C (90 °F)]. For more information
on storing the battery, see page
6-31.
UBC6E2E0.book Page 4 Tuesday, July 10, 2018 6:26 PM
Page 93 of 102
Motorcycle care and storage
7-5
7
TIP
Make any necessary repairs before
storing the motorcycle.
UBC6E2E0.book Page 5 Tuesday, July 10, 2018 6:26 PM
Page 94 of 102
Specifications
8-1
8
Dimensions:
Overall length:
2138 mm (84.2 in)
Overall width:
806 mm (31.7 in)
Overall height:
1270 mm (50.0 in)
Seat height:
835 mm (32.9 in)
Wheelbase:
1450 mm (57.1 in)
Ground clearance:
140 mm (5.51 in)
Minimum turning radius:
2.7 m (8.86 ft)
Weight:
Curb weight:
196 kg (432 lb)
Engine:
Engine type:
Liquid cooled 4-stroke, DOHC
Cylinder arrangement:
Inline 2-cylinder
Displacement:
689 cm³
Bore × stroke:
80.0 × 68.6 mm (3.15 × 2.70 in)
Compression ratio:
11.5 : 1
Starting system:
Electric starter
Lubrication system:
Wet sump
Engine oil:
Recommended brand:
YAMALUBE
SAE viscosity grades:
10W-40
Recommended engine oil grade:
API service SG type or higher, JASO
standard MA
Engine oil quantity:
Without oil filter cartridge replacement:
2.30 L (2.43 US qt, 2.02 Imp.qt)
With oil filter cartridge replacement:
2.60 L (2.75 US qt, 2.29 Imp.qt)
Coolant quantity:
Coolant reservoir (up to the maximum level
mark):
0.25 L (0.26 US qt, 0.22 Imp.qt)Radiator (including all routes):
1.60 L (1.69 US qt, 1.41 Imp.qt)
Air filter:
Air filter element:
Oil-coated paper element
Fuel:
Recommended fuel:
Premium unleaded gasoline (Gasohol [E10]
acceptable)
Fuel tank capacity:
17.0 L (4.49 US gal, 3.74 Imp.gal)
Fuel reserve amount:
3.5 L (0.92 US gal, 0.77 Imp.gal)
Fuel injection:
Throttle body:
ID mark:
1WS1 10
Spark plug(s):
Manufacturer/model:
NGK/LMAR8A-9
Spark plug gap:
0.8–0.9 mm (0.031–0.035 in)
Clutch:
Clutch type:
Wet, multiple-disc
Drivetrain:
Primary reduction ratio:
1.925 (77/40)
Final drive:
Chain
Secondary reduction ratio:
2.688 (43/16)
Transmission type:
Constant mesh 6-speed
Operation:
Left foot operation
Gear ratio:
1st:
2.846 (37/13)
2nd:
2.125 (34/16)
3rd:
1.632 (31/19)
4th:
1.300 (26/20)
5th:
1.091 (24/22)
6th:
0.964 (27/28)
UBC6E2E0.book Page 1 Tuesday, July 10, 2018 6:26 PM
Page 95 of 102
Specifications
8-2
8
Chassis:
Frame type:
Diamond
Caster angle:
25.0 °
Trail:
90 mm (3.5 in)
Front tire:
Type:
Tubeless
Size:
120/70 ZR 17 M/C (58W)
Manufacturer/model:
MICHELIN/PILOT ROAD 4
Rear tire:
Type:
Tubeless
Size:
180/55 ZR 17 M/C (73W)
Manufacturer/model:
MICHELIN/PILOT ROAD 4 R TL
Loading:
Maximum load:
180 kg (397 lb)
(Total weight of rider, passenger, cargo
and accessories)
Tire air pressure (measured on cold
tires):
Loading condition:
0–180 kg (0–397 lb)
Front:
225 kPa (2.25 kgf/cm², 33 psi)
Rear:
250 kPa (2.50 kgf/cm², 36 psi)
High-speed riding:
Front:
225 kPa (2.25 kgf/cm², 33 psi)
Rear:
250 kPa (2.50 kgf/cm², 36 psi)
Front wheel:
Wheel type:
Cast wheel
Rim size:
17M/C x MT3.50
Rear wheel:
Wheel type:
Cast wheel
Rim size:
17M/C x MT5.50
Front brake:
Type:
Hydraulic dual disc brake
Operation:
Right hand operation
Specified brake fluid:
DOT 4
Rear brake:
Type:
Hydraulic single disc brake
Operation:
Right foot operation
Specified brake fluid:
DOT 4
Front suspension:
Type:
Telescopic fork
Spring:
Coil spring
Shock absorber:
Hydraulic damper
Wheel travel:
130 mm (5.1 in)
Rear suspension:
Type:
Swingarm (link suspension)
Spring:
Coil spring
Shock absorber:
Gas-hydraulic damper
Wheel travel:
142 mm (5.6 in)
Electrical system:
System voltage:
12 V
Ignition system:
TCI
Charging system:
AC magneto
Battery:
Model:
YTZ10S
Voltage, capacity:
12 V, 8.6 Ah (10 HR)
Headlight:
Bulb type:
Halogen bulb
Bulb wattage × quantity:
Headlight:
H7, 55.0 W x 2
UBC6E2E0.book Page 2 Tuesday, July 10, 2018 6:26 PM
Page 96 of 102
Specifications
8-3
8
Brake/tail light:
LED
Front turn signal light:
10.0 W × 2
Rear turn signal light:
10.0 W × 2
Auxiliary light:
LED
License plate light:
5.0 W × 1
Meter lighting:
LED
Neutral indicator light:
LED
High beam indicator light:
LED
Oil pressure warning light:
LED
Turn signal indicator light:
LED
Coolant temperature warning light:
LED
Engine trouble warning light:
LED
ABS warning light:
LED
Immobilizer system indicator light:
LED
Fuse(s):
Main fuse:
30.0 A
Accessory fuse:
10.0 A
Auxiliary fuse:
2.0 A
Headlight fuse:
15.0 A
Signaling system fuse:
10.0 A
Ignition fuse:
10.0 A
Parking lighting fuse:
7.5 A
Radiator fan motor fuse:
10.0 A
Fuel injection system fuse:
10.0 A
ABS control unit fuse:
7.5 A
ABS motor fuse:
30.0 AABS solenoid fuse:
20.0 A
Backup fuse:
7.5 A
UBC6E2E0.book Page 3 Tuesday, July 10, 2018 6:26 PM
Page 97 of 102
Consumer information
9-1
9
EAU53562
Identification numbers
Record the vehicle identification num-
ber, engine serial number, and the
model label information in the spaces
provided below. These identification
numbers are needed when registering
the vehicle with the authorities in your
area and when ordering spare parts
from a Yamaha dealer.
VEHICLE IDENTIFICATION NUMBER:
ENGINE SERIAL NUMBER:
MODEL LABEL INFORMATION:
EAU26401Vehicle identification numberThe vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.
TIP
The vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26442Engine serial number
The engine serial number is stamped
into the crankcase.
EAU26521Model label
The model label is affixed to the frame
under the passenger seat. Record the
information on this label in the space
1. Vehicle identification number
ZAUM1422
1
1. Engine serial number
1. Model label
1
1
ZAUM1423
UBC6E2E0.book Page 1 Tuesday, July 10, 2018 6:26 PM
Page 98 of 102
Consumer information
9-2
9provided. This information will be
needed when ordering spare parts
from a Yamaha dealer.
EAU69910
Diagnostic connector
The diagnostic connector is located as
shown.
EAU85300
Vehicle data recording
This model’s ECU stores certain vehi-
cle data to assist in the diagnosis of
malfunctions and for research, statisti-
cal analysis and development purpos-
es.
Although the sensors and recorded
data will vary by model, the main data
points are:
Vehicle status and engine perfor-
mance data
Fuel-injection and emission-relat-
ed data
This data will be uploaded only when a
special Yamaha diagnostic tool is at-
tached to the vehicle, such as when
maintenance checks or service proce-
dures are performed.
Vehicle data uploaded will be handled
appropriately according to the follow-
ing Privacy Policy.
Privacy Policy
Yamaha will not disclose this data to a
third party except in the following cas-
es. In addition, Yamaha may provide
vehicle data to a contractor in order to
outsource services related to the han-
dling of vehicle data. Even in this case,
Yamaha will require the contractor to
properly handle the vehicle data we
provided and Yamaha will appropriate-
ly manage the data.
With the consent of the vehicle
owner
Where obligated by law
For use by Yamaha in litigation
When the data is not related to an
individual vehicle nor owner
1. Diagnostic connector
1
ZAUM1424
https://www.yamaha-motor.eu/eu/
privacy/privacy-policy.aspx
UBC6E2E0.book Page 2 Tuesday, July 10, 2018 6:26 PM
Page 99 of 102
10-1
10
Index
A
ABS ...................................................... 3-16
ABS warning light ................................... 3-5
Air filter element and check hose,
replacing and cleaning ....................... 6-15
Auxiliary DC connector ........................ 3-27
Auxiliary lights ...................................... 6-35
B
Battery .................................................. 6-31
Brake and clutch levers, checking and
lubricating .......................................... 6-27
Brake and shift pedals, checking and
lubricating .......................................... 6-27
Brake fluid, changing ........................... 6-23
Brake fluid level, checking ................... 6-22
Brake lever ........................................... 3-15
Brake lever free play, checking ............ 6-20
Brake light switches ............................. 6-21
Brake pedal .......................................... 3-15
Brake/tail light ...................................... 6-36
C
Cables, checking and lubricating ......... 6-26
Canister .................................................. 6-9
Care ........................................................ 7-1
Catalytic converter ............................... 3-19
Clutch lever .......................................... 3-14
Clutch lever free play, adjusting ........... 6-19
Coolant ................................................. 6-12
Coolant temperature warning light ......... 3-4
Cowlings, removing and installing ......... 6-7
D
Data recording, vehicle .......................... 9-2
Diagnostic connector ............................. 9-2
Dimmer switch ..................................... 3-13
Drive chain, cleaning and lubricating ... 6-25
Drive chain slack .................................. 6-24
E
Engine break-in ...................................... 5-5
Engine oil and oil filter cartridge ............. 6-9
Engine serial number.............................. 9-1
Engine trouble warning light................... 3-5
F
Front and rear brake pads, checking ... 6-21
Front fork, checking ............................. 6-29
Fuel....................................................... 3-17
Fuel consumption, tips for reducing ...... 5-4
Fuel tank breather hose and overflow
hose ................................................... 3-19
Fuel tank cap........................................ 3-17
Fuses, replacing ................................... 6-32
H
Handlebar switches .............................. 3-13
Hazard switch ....................................... 3-13
Headlight bulb, replacing ...................... 6-34
Helmet holding cable ............................ 3-21
High beam indicator light........................ 3-4
Horn switch........................................... 3-13
I
Identification numbers ............................ 9-1
Ignition circuit cut-off system ............... 3-25
Immobilizer system ................................. 3-1
Immobilizer system indicator light .......... 3-6
Indicator lights and warning lights .......... 3-4
L
License plate light bulb, replacing ........ 6-37
Luggage strap holders .......................... 3-24
M
Main switch/steering lock ....................... 3-2
Maintenance and lubrication, periodic ... 6-4
Maintenance, emission control
system .................................................. 6-3
Matte color, caution ................................ 7-1
Model label ............................................. 9-1
Multi-function meter unit ........................ 3-7
N
Neutral indicator light.............................. 3-4
O
Oil pressure warning light ....................... 3-4
P
Parking .................................................... 5-5
Part locations .......................................... 2-1
Pass switch........................................... 3-13
R
Rear suspension, lubricating ................ 6-28
S
Safety information................................... 1-1
Seat....................................................... 3-20
Shifting .................................................... 5-3
Shift pedal............................................. 3-14
Shock absorber assembly, adjusting ... 3-23
Sidestand .............................................. 3-24
Sidestand, checking and lubricating .... 6-28
Spark plugs, checking ............................ 6-8
Specifications ......................................... 8-1
Start/Engine stop switch ...................... 3-13
Starting the engine.................................. 5-2
Steering, checking ................................ 6-30
Storage ................................................... 7-4
Storage compartment ........................... 3-22
Supporting the motorcycle ................... 6-37
UBC6E2E0.book Page 1 Tuesday, July 10, 2018 6:26 PM
Page 100 of 102
Index
10-2
10
Swingarm pivots, lubricating ................ 6-29
T
Throttle grip and cable, checking and
lubricating ........................................... 6-26
Throttle grip free play, checking ........... 6-15
Tires ...................................................... 6-16
Tool kit .................................................... 6-2
Troubleshooting .................................... 6-38
Troubleshooting charts ......................... 6-39
Turn signal indicator lights ...................... 3-4
Turn signal light bulb, replacing............ 6-36
Turn signal switch ................................. 3-13
V
Valve clearance..................................... 6-16
Vehicle identification number ................. 9-1
W
Wheel bearings, checking..................... 6-30
Wheels .................................................. 6-19
Windshield ............................................ 3-22
UBC6E2E0.book Page 2 Tuesday, July 10, 2018 6:26 PM
