Instrument and control functions
4-5
4
Use gasoline with a research octane
number of 91 or higher.
Europe
Use gasoline with a research octane
number of 95 or higher.
TIP

If knocking (or pinging) occurs, try
gasoline of a different brand or use
premium unleaded gasoline.
 Gasohol containing ethanol can
be used if the ethanol content
does not exceed 10% (E10).
 Gasohol containing methanol is
not recommended by Yamaha be-
cause it can cause damage to the
fuel system or vehicle perfor-
mance problems.
For Europe
TIP
This mark identifies the recom-
mended fuel for this vehicle as
specified by European regulation
(EN228).
 Confirm the fuel dispenser nozzle
has the same mark.
EAU13414
Fuel tank breather hose
Before operating the motorcycle:
 Check the fuel tank breather hose
connection.
 Check the fuel tank breather hose
for cracks or damage, and replace
it if necessary.
 Make sure that the fuel tank
breather hose is not blocked, and
clean it if necessary.
E10
1. Fuel tank breather hose
1
UB5183E0.book Page 5 Friday, June 9, 2017 8:32 AM

Instrument and control functions
4-6
4
EAU13562
Fuel cock
The fuel cock supplies fuel from the
tank to the carburetor while filtering it
also.
The fuel cock has three positions:
OFF
With the lever in this position, fuel will
not flow. Always return the lever to this
position when the engine is not run-
ning.
ON
With the lever in this position, fuel flows
to the carburetor. Normal riding is done
with the lever in this position. RES
This indicates reserve. If you run out of
fuel while riding, move the lever to this
position. Fill the tank at the first oppor-
tunity. Be sure to set the lever back to
“ON” after refueling!
1. Arrow mark positioned over “OFF”
1. Arrow mark positioned over “ON”
1. Arrow mark positioned over “RES”
UB5183E0.book Page 6 Friday, June 9, 2017 8:32 AM

Instrument and control functions
4-7
4
EAU13591
Starter (choke) lever “ ”
Starting a cold engine requires a richer
air-fuel mixture, which is supplied by
the starter (choke).
Move the lever in direction (a) to turn on
the starter (choke).
Move the lever in direction (b) to turn
off the starter (choke).
EAU37652
Kickstarter
If the engine fails to start by pushing
the start switch, try to start it by using
the kickstarter. To start the engine, fold
out the kickstarter lever, move it down
lightly with your foot until the gears en-
gage, and then push it down smoothly
but forcefully.
1. Starter (choke) lever “ ”1. Kickstarter lever
1
UB5183E0.book Page 7 Friday, June 9, 2017 8:32 AM

Instrument and control functions
4-8
4
EAU46283
Seat
To remove the seat
Remove the bolts, and then slide the
seat to the rear and pull upward.
To install the seat
1. Fit the slot in the seat onto the pro- jection on the fuel tank, and insert
the projection on the seat into the
seat holder as shown.
2. Place the seat in the original posi- tion, and then tighten the bolts.
TIP
Make sure that the seat is properly se-
cured before riding.
EAU46023
Shock a bsorb er assem bly
WARNING
EWA10222
This shock a bsor ber assem bly con-
tains hi ghly pressurize d nitro gen
g as. Rea d an d un derstan d the fol-
lowin g information before han dlin g
the shock a bsor ber assem bly.
 Do not tamper with or attempt
to open the cylind er assembly.
 Do not su bject the shock a b-
sor ber assem bly to an open
flame or other hi gh heat source.
This may cause the unit to ex-
plo de due to excessive g as
pressure.
 Do not deform or damag e the
cylin der in any way. Cylin der
d amag e will result in poor
d ampin g performance.
 Do not d ispose of a damag ed or
worn-out shock a bsor ber as-
sem bl

y yourself. Take the shock
a b sor ber assem bly to a Yamaha
d ealer for any service.
1. Bolt
1. Slot
2. Projection
3. Seat holder
1
21
2 3
UB5183E0.book Page 8 Friday, June 9, 2017 8:32 AM

Instrument and control functions
4-9
4
EAU37491
Si destan d
The sidestand is located on the left
side of the frame. Raise the sidestand
or lower it with your foot while holding
the vehicle upright.
WARNING
EWA14191
The vehicle must not be ri dden with
the si destan d d own, or if the si de-
stan d cannot b e properly move d up
(or does not stay up), otherwise the
si destan d coul d contact the groun d
an d d istract the operator, resultin g
in a possi ble loss of control.
EAU68810
Startin g circuit cut-off system
The starting circuit cut-off system pre-
vents starting when the transmission is
in gear.
Periodically check the operation of the
starting circuit cut-off system accord-
ing to the following procedure.
TIP
This check is most reliable if performed
with a warmed-up engine.
UB5183E0.book Page 9 Friday, June 9, 2017 8:32 AM

Instrument and control functions
4-10
4
With the engine t urned off:
1. Make sure that the engine stop switch is set to “ ”.
2.
T urn the key to “ON”.
3. Shift the transmission into gear.
5. Push the start switch. 4. Keep the front or rear brake applied.
Does the engine start?
6. Shift the transmission into the ne utral
position.
7. Push the start switch.
Does the engine start?
The system is OK. The motorcycle can
be ridden.
The neutral switch may not be working
correctly.
The motorcycle should not be ridden
until checked b y a Yamaha dealer.
The neutral switch may not be working
correctly.
The motorcycle should not be ridden
until checked b y a Yamaha dealer.
WARNING
If a malfunction is noted, have a
Yamaha dealer check the system
before riding.
NO YES
YES NO
UB5183E0.book Page 10 Friday, June 9, 2017 8:32 AM

For your safety – pre-operation checks
5-1
5
EAU63440
Inspect your vehicle each time you use it to make sure the vehicle is in safe oper-
ating condition. Always follow the inspection and maintenance procedures and
schedules described in the Owner’s Manual.
WARNING
EWA11152
Failure to inspect or maintain the vehicle properly increases the possibility
of an acci dent or equipment d amage. Do not operate the vehicle if you fin d
any prob lem. If a pro blem cannot be corrected b y the proce dures provi ded
in this manual, have the vehicle inspecte d b y a Yamaha d ealer.
Before using this vehicle, check the following points:
ITEM CHECKSPAGE
Fuel • Check fuel level in fuel tank.
• Refuel if necessary.
• Check fuel line for leakage.
• Check fuel tank breather hose for obstructions, cracks
or damage, and check hose connection. 4-4, 4-5
En gine oil • Check oil level in engine.
• If necessary, add recommended oil to specified level.
• Check vehicle for oil leakage. 7-8
Front brake • Check operation.
• Lubricate cable if necessary.
• Check lever free play.
• Adjust if necessary. 7-18,
7-20
Rear brake • Check operation.
• Check pedal free play.
• Adjust if necessary. 7-19,
7-20
Throttle g rip • Make sure that operation is smooth.
• Check throttle grip free play.
• If necessary, have Yamaha dealer adjust throttle grip
free play and lubricate cable and grip housing. 7-15,
7-23
Control ca bles • Make sure that operation is smooth.
• Lubricate if necessary. 7-23
Drive chain • Check chain slack.
• Adjust if necessary.
• Check chain condition.
• Lubricate if necessary. 7-21,
7-22
Wheels an d tires •Check for damage.
• Check tire condition and tread depth.
• Check air pressure.
• Correct if necessary. 7-16,
7-17
Shift pe dal • Make sure that operation is smooth.
• Correct if necessary. 7-20
Brake ped al • Make sure that operation is smooth.
• Lubricate pedal pivoting point if necessary.
7-24
UB5183E0.book Page 1 Friday, June 9, 2017 8:32 AM

For your safety – pre-operation checks
5-2
5
Brake lever• Make sure that operation is smooth.
• Lubricate lever pivoting point if necessary. 7-24
Si destan d • Make sure that operation is smooth.
• Lubricate pivot if necessary.
7-25
Chassis fasteners • Make sure that all nuts, bolts and screws are properly
tightened.
• Tighten if necessary. —
En gine stop switch • Check operation. 4-1
ITEM CHECKS PAGE
UB5183E0.book Page 2 Friday, June 9, 2017 8:32 AM

Operation and important ri din g points
6-1
6
EAU15952
Read the Owner’s Manual carefully to
become familiar with all controls. If
there is a control or function you do not
understand, ask your Yamaha dealer.
WARNING
EWA10272
Failure to familiarize yourself with
the controls can lead to loss of con-
trol, which coul d cause an acci dent
or injury.
EAU44815
Startin g an d warmin g up a
col d en gine
1. Turn the fuel cock lever to “ON”.
2. Turn the key to “ON” and make
sure that the engine stop switch is
set to “ ”.
3. Shift the transmission into the neutral position.
WARNING
EWA14411
Be sure to shift the transmission
into neutral b efore starting the
en gine.
 Never ri de with the si destan d
d own.
4. Turn the starter (choke) on and
completely close the throttle. (See
page 4-7.)
5. Start the engine by pushing the start switch or by pushing the
kickstarter lever down.
6. When the engine is warm, turn the starter (choke) off.
TIP
The engine is warm when it responds
quickly to the throttle with the starter
(choke) turned off.
NOTICE
ECA11043
For maximum en gine life, never ac-
celerate har d when the en gine is
col d!
UB5183E0.book Page 1 Friday, June 9, 2017 8:32 AM

Operation and important rid ing points
6-2
6
EAU16641
Startin g a warm en gine
Follow the same procedure as for
starting a cold engine with the excep-
tion that the starter (choke) is not re-
quired when the engine is warm.
EAU39902
Shiftin g
This motorcycle has a 4-speed trans-
mission with a centrifugal, automatic
clutch. Shifting gears lets you control
the amount of engine power available
for starting off, accelerating, climbing
hills, etc.
The gear positions are shown in the il-
lustration.
TIP
To shift the transmission into the neu-
tral position, press the shift pedal down
repeatedly until it reaches the end of its
travel.
NOTICE
ECA15442
Even with the transmission in
the neutral position, d o not
coast for lon g period s of time
with the en gine off, an d d o not
tow the motorcycle for lon g d is-
tances. The transmission is
properly lu bricated only when
the en gine is runnin g. Ina de-
quate lu brication may damag e
the transmission.
 Always release the throttle grip
b efore chan gin g g ears to avoi d
d amag ing the en gine, transmis-
1. Shift pedal
2. Neutral position
1
2
1 2
3
4
