Safety information
2-3
2
ventilated areas. If you experience any
symptoms of carbon monoxide poi-
soning, leave the area immediately, get
fresh air, and SEEK MEDICAL TREAT-
MENT.
 Do not run engine indoors. Even if
you try to ventilate engine exhaust
with fans or open windows and
doors, carbon monoxide can rap-
idly reach dangerous levels.
 Do not run engine in poorly venti-
lated or partially enclosed areas
such as barns, garages, or car-
ports.
 Do not run engine outdoors where
engine exhaust can be drawn into
a building through openings such
as windows and doors.
Loa din g
Adding accessories to your motorcycle
can adversely affect stability and han-
dling if the weight distribution of the
motorcycle is changed. To avoid the
possibility of an accident, use extreme
caution when adding accessories to
your motorcycle. Use extra care when
riding a motorcycle that has added ac-
cessories. Here are some general
guidelines to follow if adding accesso-
ries to your motorcycle:
Operation of an overload ed vehicle
coul d cause an acci dent.
 The weight of the operator must
not exceed 60.0 kg (132 lb).
 Accessory weight should be kept
as low and close to the motorcy-
cle as possible. Securely pack
your heaviest items as close to the
center of the vehicle as possible
and make sure to distribute the weight as evenly as possible on
both sides of the motorcycle to
minimize imbalance or instability.
 Shifting weights can create a sud-
den imbalance. Make sure that
accessories are securely attached
to the motorcycle before riding.
Check accessory mounts fre-
quently.
• Properly adjust the suspension for your load (suspension-ad-
justable models only), and
check the condition and pres-
sure of your tires.
• Never attach any large or heavy items to the handlebar, front
fork, or front fender.
Genuine Yamaha Accessories
Choosing accessories for your vehicle
is an important decision. Genuine
Yamaha accessories, which are avail- able only from a Yamaha dealer, have
been designed, tested, and approved
by Yamaha for use on your vehicle.
Many companies with no connection
to Yamaha manufacture parts and ac-
cessories or offer other modifications
for Yamaha vehicles. Yamaha is not in
a position to test the products that
these aftermarket companies produce.
Therefore, Yamaha can neither en-
dorse nor recommend the use of ac-
cessories not sold by Yamaha or
modifications not specifically recom-
mended by Yamaha, even if sold and
installed by a Yamaha dealer.
UB5185E0.book Page 3 Monday, June 17, 2019 9:04 AM

For your safety – pre-operation checks
5-1
5
EAU63440
Inspect your vehicle each time you use it to make sure the vehicle is in safe oper-
ating condition. Always follow the inspection and maintenance procedures and
schedules described in the Owner’s Manual.
WARNING
EWA11152
Failure to inspect or maintain the vehicle properly increases the possibility
of an acci dent or equipment d amage. Do not operate the vehicle if you fin d
any prob lem. If a pro blem cannot be corrected b y the proce dures provi ded
in this manual, have the vehicle inspecte d b y a Yamaha d ealer.
Before using this vehicle, check the following points:
ITEM CHECKSPAGE
Fuel • Check fuel level in fuel tank.
• Refuel if necessary.
• Check fuel line for leakage.
• Check fuel tank breather hose for obstructions, cracks
or damage, and check hose connection. 4-4, 4-5
En gine oil • Check oil level in engine.
• If necessary, add recommended oil to specified level.
• Check vehicle for oil leakage. 7-8
Front brake • Check operation.
• Lubricate cable if necessary.
• Check lever free play.
• Adjust if necessary. 7-18,
7-20
Rear brake • Check operation.
• Check pedal free play.
• Adjust if necessary. 7-19,
7-20
Throttle g rip • Make sure that operation is smooth.
• Check throttle grip free play.
• If necessary, have Yamaha dealer adjust throttle grip
free play and lubricate cable and grip housing. 7-15,
7-23
Control ca bles • Make sure that operation is smooth.
• Lubricate if necessary. 7-23
Drive chain • Check chain slack.
• Adjust if necessary.
• Check chain condition.
• Lubricate if necessary. 7-21,
7-22
Wheels an d tires •Check for damage.
• Check tire condition and tread depth.
• Check air pressure.
• Correct if necessary. 7-16,
7-17
Shift pe dal • Make sure that operation is smooth.
• Correct if necessary. 7-20
Brake ped al • Make sure that operation is smooth.
• Lubricate pedal pivoting point if necessary.
7-24
UB5185E0.book Page 1 Monday, June 17, 2019 9:04 AM

Periodic maintenance an d a djustment
7-3
7
EAU69172
Perio dic maintenance chart for the emission control system
TIP
 From 7000 km (4200 mi) or 18 months, repeat the maintenance intervals
starting from 3000 km (1800 mi) or 6 months.
 Items marked with an asterisk should be performed by a Yamaha dealer as
they require special tools, data and technical skills.
No. ITEM 13 5
0.6 1.8 3 16 12
30 90 150
1 *Fuel line • Check fuel hoses for cracks or
damage.
• Replace if necessary. √√
2Spark plu g• Check condition.
• Adjust gap and clean.
√√
3 *Valve clearance • Check and adjust valve clear-
ance when engine is cold. √
4 Air filter element • Clean with solvent.
• Replace if necessary.
√√
5 *Crankcase
breather
system • Check ventilation hose for
cracks or damage and drain
any deposits.
• Replace if necessary. √√ √
6 *Car buretor • Check engine idling speed and
starter operation.
• Adjust if necessary. √√ √
7 Exhaust system • Check for leakage.
• Tighten if necessary.
• Replace gasket(s) if necessary. √√
8 *Spark arrester • Clean. √
9En gine oil • Change (warm engine before
draining). √√ √X 1000 km
X 1000 mi month
CHECKS AND
MAINTENANCE JOBS
hours
INITIALODOMETER READINGS
UB5185E0.book Page 3 Monday, June 17, 2019 9:04 AM

Periodic maintenance an d a djustment
7-4
7
EAU69192
General maintenance an d lu brication chart
TIP
 From 7000 km (4200 mi) or 18 months, repeat the maintenance intervals
starting from 3000 km (1800 mi) or 6 months.
 Items marked with an asterisk should be performed by a Yamaha dealer as
they require special tools, data and technical skills.
No. ITEM 13 5
0.6 1.8 3 16 12
30 90 150
1 *Clutch • Check operation.
• Adjust if necessary.
√√ √
2 *Front brake • Check operation.
• Adjust brake lever free play and
replace brake shoes if neces-
sary. √√ √
3 *Rear brake • Check operation.
• Adjust brake pedal free play
and replace brake shoes if nec-
essary. √√ √
4 *Wheels • Check runout, spoke tightness
and for damage.
• Tighten spokes if necessary. √√ √
5 *Tires • Check tread depth and for
damage.
• Replace if necessary.
• Check air pressure.
• Correct if necessary. √√
6 *Wheel bearin gs • Check bearings for smooth op-
eration.
• Replace if necessary. √√
7 *Swin
garm pivot
b ushes • Check bush assemblies for
looseness.
• Lubricate with molybdenum di- sulfide grease. √√
8 Drive chain • Check chain slack/alignment
and condition.
• Adjust and lubricate chain with Yamaha chain lubricant or other
suitable chain lubricant thor-
oughly. Every rideX 1000 km
X 1000 mi month
CHECKS AND
MAINTENANCE JOBS
hours
INITIALODOMETER READINGS
UB5185E0.book Page 4 Monday, June 17, 2019 9:04 AM

Periodic maintenance an d a djustment
7-16
7
EAUW3500
Tires
Tires are the only contact between the
vehicle and the road. Safety in all con-
ditions of riding depends on a relatively
small area of road contact. Therefore, it
is essential to maintain the tires in good
condition at all times and replace them
at the appropriate time with the speci-
fied tires.
Tire air pressure
The tire air pressure should be
checked and, if necessary, adjusted
before each ride.
WARNING
EWA10442
Operation of this vehicle with im-
proper tire pressure may cause se-
vere injury or death from loss of
control.  The tire air pressure must be
checked and a djuste d on col d
tires (i.e., when the temperature
of the tires equals the am bient
temperature).
 The tire air pressure must be
a d juste d in accor dance with the
ri din g speed and with the total
wei ght of ri der, car go, an d ac-
cessories approved for this
mo del.
WARNING
EWA10512
Never overloa d your vehicle. Opera-
tion of an overloa ded vehicle coul d
cause an acci dent.
Tire inspection
The tires must be checked before each
ride. If the center tread depth reaches
the specified limit (minimum tire tread
depth), if the tire has a nail or glass
fragments in it, or if the sidewall is
cracked, have a Yamaha dealer re-
place the tire immediately.
Tire information
This model is equipped with tube tires.
Tires age, even if they have not been
used or have only been used occasion-
ally. Cracking of the tread and sidewall
rubber, sometimes accompanied by
carcass deformation, is an evidence of
ageing. Old and aged tires shall be
checked by tire specialists to ascertain
their suitability for further use.
Stan dar d tire pressure:
Front: 100 kPa (1.00 kgf/cm², 15 psi)
Rear:
100 kPa (1.00 kgf/cm², 15 psi)
1. Tire sidewall
2. Tire tread depth
Minimum tire trea d d epth (front an d
rear): 4.0 mm (0.16 in)
1
2
UB5185E0.book Page 16 Monday, June 17, 2019 9:04 AM

Periodic maintenance an d a djustment
7-26
7
EAU23273
Checkin g the front fork
The condition and operation of the
front fork must be checked as follows
at the intervals specified in the periodic
maintenance and lubrication chart.
To check the con dition
Check the inner tubes for scratches,
damage and excessive oil leakage.
To check the operation 1. Place the vehicle on a level surfa- ce and hold it in an upright posi-
tion. WARNING! To avoi d injury,
securely support the vehicle so
there is no dan ger of it fallin g
over.
[EWA10752]
2. While applying the front brake, push down hard on the handle-
bars several times to check if the
front fork compresses and re-
bounds smoothly.
NOTICE
ECA10591
If any d amage is foun d or the front
fork does not operate smoothly,
have a Yamaha dealer check or re-
pair it.
EAU23285
Checkin g the steerin g
Worn or loose steering bearings may
cause danger. Therefore, the operation
of the steering must be checked as fol-
lows at the intervals specified in the
periodic maintenance and lubrication
chart.
1. Raise the front wheel off the ground. (See page 7-29.)
WARNING! To avoi d injury, se-
curely support the vehicle so
there is no dan ger of it fallin g
over.
[EWA10752]
2. Hold the lower ends of the front fork legs and try to move them for-
ward and backward. If any free
play can be felt, have a Yamaha
dealer check or repair the steer-
ing.
UB5185E0.book Page 26 Monday, June 17, 2019 9:04 AM
