battery YAMAHA TT-R110E 2022 Owners Manual

Table of contents
Location of important la bels ........... 1-1
Safety information ............................ 2-1
Description ....................................... 3-1
Left view ......................................... 3-1
Right view ....................................... 3-2
Controls and instruments ............... 3-3
Instrument an d control functions ... 4-1
Main switch .................................... 4-1
Handlebar switches ........................ 4-1
Shift pedal ...................................... 4-2
Brake lever...................................... 4-2
Brake pedal .................................... 4-3
Fuel tank cap .................................. 4-3
Fuel ................................................. 4-4
Fuel tank breather hose.................. 4-5
Fuel cock ........................................ 4-6
Starter (choke) lever ...................... 4-7
Kickstarter ..................................... 4-7
Seat ................................................ 4-8
Shock absorber assembly .............. 4-8
Sidestand ....................................... 4-9
Starting circuit cut-off system ........ 4-9
For your safety – pre-operation
checks ............................................... 5-1
Operation an d important ri din g
points ................................................ 6-1
Starting and warming up a cold
engine ......................................... 6-1
Starting a warm engine .................. 6-2
Shifting ........................................... 6-2
Engine break-in .............................. 6-4
Parking ........................................... 6-4
Perio dic maintenance an d
a d justment ........................................ 7-1
Owner’s tool kit .............................. 7-2
Periodic maintenance chart for the
emission control system ............. 7-3
General maintenance and lubrication chart .......................... 7-4
Removing and installing panels...... 7-6 Checking the spark plug ................. 7-7
Engine oil......................................... 7-8
Cleaning the air filter element ....... 7-10
Cleaning the spark arrester ........... 7-12
Adjusting the carburetor ............... 7-13
Adjusting the engine idling
speed ......................................... 7-14
Checking the throttle grip free
play ............................................ 7-15
Valve clearance ............................. 7-15
Tires .............................................. 7-16
Spoke wheels ................................ 7-17
Adjusting the clutch free play........ 7-18
Adjusting the brake lever free play ............................................ 7-18
Adjusting the brake pedal free play ............................................ 7-19
Checking the shift pedal ............... 7-20
Checking the front and rear brake shoes ......................................... 7-20
Drive chain slack ........................... 7-21
Cleaning and lubricating the drive chain ................................. 7-22
Checking and lubricating the cables ........................................ 7-23
Checking and lubricating the
throttle grip and cable ............... 7-23
Checking and lubricating the brake lever ................................. 7-24
Checking and lubricating the brake pedal ................................ 7-24
Checking and lubricating the
sidestand ................................... 7-25
Lubricating the swingarm pivots ... 7-25
Checking the front fork ................. 7-26
Checking the steering ................... 7-26
Checking the wheel bearings ........ 7-27
Battery........................................... 7-27
Replacing the fuse ........................ 7-29
Supporting the motorcycle ........... 7-29
Front wheel ................................... 7-30
Rear wheel .................................... 7-31
Troubleshooting ............................ 7-33
Troubleshooting chart ................... 7-34
UBMA80E0.book Page 1 Wednesday, October 20, 2021 8:57 AM

Location of important labels
1-7
1
**.* kPa
*.** kgf/cm²
*.* psi **.* kPa
*.** kgf/cm²
*.* psi
******
*** kW *** kg
1
23
YAMAHA MOTOR CO., LTD.
2500 SHINGAI, IWATA, JAPAN****
1
Use unleaded gasoline only.
Measure the tire pressure when the tires are
cold.
Adjust the tire pressure.
Improper tire pressure can cause loss of
control.
Loss of control can result in severe injury or
death.
1
2
3 Model Name
Max. Power
Mass In Running Order
1 Year of construction
Turn off the main switch after riding to avoid
draining the battery.
UBMA80E0.book Page 7 Wednesday, October 20, 2021 8:57 AM

Description
3-1
3
EAU63371
Left view
678
123 45
1. Fuel cock (page 4-6)
2. Starter (choke) lever (page 4-7)
3. Fuse (page 7-29)
4. Battery (page 7-27)
5. Clutch adjusting screw (page 7-18)
6. Engine oil drain bolt (page 7-8)
7. Shift pedal (page 4-2)
8. Throttle stop screw (page 7-14)
UBMA80E0.book Page 1 Wednesday, October 20, 2021 8:57 AM

Periodic maintenance an d a djustment
7-27
7
EAU23292
Checkin g the wheel b earings
The front and rear wheel bearings must
be checked at the intervals specified in
the periodic maintenance and lubrica-
tion chart. If there is play in the wheel
hub or if the wheel does not turn
smoothly, have a Yamaha dealer
check the wheel bearings.
EAU23397
Battery
The battery is located behind panel B.
(See page 7-6.)
This model is equipped with a VRLA
(Valve Regulated Lead Acid) battery.
There is no need to check the electro-
lyte or to add distilled water. However,
the battery coupler needs to be
checked and, if necessary, securely
fastened.
WARNING
EWA10761
 Electrolyte is poisonous an d
d an gerous since it contains sul-
furic aci d, which causes severe
b urns. Avoid any contact with
skin, eyes or clothin g an d al-
ways shiel d your eyes when
workin g near b atteries. In case
of contact, ad minister the fol-
lowin g FIRST AID.
EXTERNAL: Flush with plenty of water.
INTERNAL: Drink lar ge quan-
tities of water or milk an d im-
me diately call a physician.
EYES: Flush with water for 15 minutes and seek prompt
me dical attention.
1. Battery coupler
2. Battery band
3. Battery
2
3
1
UBMA80E0.book Page 27 Wednesday, October 20, 2021 8:57 AM

Periodic maintenance an d a djustment
7-28
7 
Batteries pro duce explosive hy-
d ro gen gas. Therefore, keep
sparks, flames, ci garettes, etc.,
away from the battery an d pro-
vi de sufficient ventilation when
char gin g it in an enclosed
space.
 KEEP THIS AND ALL BATTER-
IES OUT OF THE REACH OF
CHILDREN.
To char ge the battery
Have a Yamaha dealer charge the bat-
tery as soon as possible if it seems to
have discharged. Keep in mind that the
battery tends to discharge more quick-
ly if the vehicle is equipped with op-
tional electrical accessories.
NOTICE
ECA16522
To char ge a VRLA (Valve Re gulate d
Lea d Aci d) battery, a special (con-
stant-volta ge) battery char ger is re-
quired . Using a conventional battery
char ger will dama ge the b attery.
To store the battery
1. If the model will not be used for more than one month, remove the
battery, fully charge it, and then
place it in a cool, dry place.
NOTICE: When removin g the
b attery, be sure the key is
turne d to “OFF” before discon-
nectin g the coupler.
[ECA16323]
2. If the battery will be stored for
more than two months, check it at
least once a month and fully char-
ge it if necessary. 3. Fully charge the battery before
installation. NOTICE: When in-
stallin g the b attery, be sure the
key is turned to “OFF” before
connectin g the coupler.
[ECA16931]
NOTICE
ECA16531
Always keep the b attery charged .
Storin g a d ischar ged battery can
cause permanent b attery damag e.
UBMA80E0.book Page 28 Wednesday, October 20, 2021 8:57 AM

Periodic maintenance an d a djustment
7-29
7
EAU50432
Replacin g the fuse
The fuse is located inside the battery
coupler. (See page 7-27.)
If the fuse is blown, replace it as fol-
lows.
1. Turn the key to “OFF” and turn off all electrical circuits.
2. Disconnect the battery coupler.
3. Remove the blown fuse, and then install a new fuse of the specified
amperage. WARNING! Do not
use a fuse of a hi gher ampera ge
ratin g than recommen ded to
avoi d causin g extensive dam-
a g e to the electrical system an d
possi bly a fire.
[EWA15132]
4. Connect the battery coupler.
5. Turn the key to “ON”.
6. If the fuse immediately blows
again, have a Yamaha dealer
check the electrical system.
EAU24351
Supportin g the motorcycle
Since this model is not equipped with a
centerstand, follow these precautions
when removing the front and rear
wheel or performing other mainte-
nance requiring the motorcycle to
stand upright. Check that the motorcy-
cle is in a stable and level position be-
fore starting any maintenance. A
strong wooden box can be placed un-
der the engine for added stability.
To service the front wheel
1. Stabilize the rear of the motorcy- cle by using a motorcycle stand
or, if an additional motorcycle
stand is not available, by placing a
jack under the frame in front of the
rear wheel.
2. Raise the front wheel off the ground by using a motorcycle
stand.
To service the rear wheel
Raise the rear wheel off the ground by
using a motorcycle stand or, if a motor-
cycle stand is not available, by placing
a jack either under each side of the
frame in front of the rear wheel or under
each side of the swingarm.
1. Battery coupler
2. Fuse
3. Spare fuse
Specified fuse:
10.0 A
1 3
2
UBMA80E0.book Page 29 Wednesday, October 20, 2021 8:57 AM

Periodic maintenance an d a djustment
7-34
7
EAU67940
Trou bleshootin g chart
1. FuelThere is enough fuel.
There is no fuel.Supply fuel.
Check the battery.
The engine turns over
quickly.
The engine turns over
slowly.
The engine does not
start.
Check the battery.
The engine does not
start.
Check the ignition.
Wipe off with a dry
cloth and correct the
spark plug gap, or
replace the spark
plug.
Check the battery
lead connections,
and have a Yamaha
dealer charge the
battery if necessary.
2. BatteryThe battery is good.
3. IgnitionWet
Dry
There is compression.
There is no
compression.
The engine does not start.
Have a Yamaha dealer check the vehicle.
Have a Yamaha dealer check the vehicle.
The engine does not
start.
Check the
compression.Have a Yamaha
dealer check the
vehicle.
Open the throttle
halfway and operate
the electric starter.
Remove the spark
plug and check
the electrodes.
Operate the electric
starter.
Check the fuel level
in the fuel tank.
Operate the electric
starter.
4. Compression
UBMA80E0.book Page 34 Wednesday, October 20, 2021 8:57 AM

Motorcycle care and stora ge
8-5
8
9. Remove the battery and fully char-
ge it. Store it in a cool, dry place
and charge it once a month. Do
not store the battery in an exces-
sively cold or warm place [less
than 0 °C (30 °F) or more than 30
°C (90 °F)]. For more information
on storing the battery, see page
7-27.
TIP
Make any necessary repairs before
storing the motorcycle.
UBMA80E0.book Page 5 Wednesday, October 20, 2021 8:57 AM

Specifications
9-3
9
Battery:
Model:GT4B-5
Voltage, capacity:
12 V, 2.5 Ah (10 HR)
Fuse(s):
Main fuse:10.0 A
EAU51132
For Europe only
The figures quoted are emission levels
and are not necessarily safe working
levels. Whilst there is a correlation be-
tween the emission and exposure lev-
els, this cannot be used reliably to
determine whether or not further pre-
cautions are required. Factors that in-
fluence the actual level of exposure of
work-force include the characteristics
of the work room, the other sources of
noise, etc. i.e. the number of machines
and other adjacent processes, and the
length of time for which an operator is
exposed to the noise. Also the permis-
sible exposure level can vary from
country. This information, however, will
enable the user of the machine to make
a better evaluation of the hazard and
risk.
UBMA80E0.book Page 3 Wednesday, October 20, 2021 8:57 AM

11-1
11
Index
A
Air filter element, cleaning .................... 7-10
B
Battery .................................................. 7-27
Brake lever .............................................. 4-2
Brake lever, checking and
lubricating ........................................... 7-24
Brake lever free play, adjusting ............ 7-18
Brake pedal............................................. 4-3
Brake pedal, checking and lubricating ........................................... 7-24
Brake pedal free play, adjusting ........... 7-19
Brake shoes, checking ......................... 7-20
C
Cables, checking and lubricating ......... 7-23
Carburetor, adjusting ............................ 7-13
Care ........................................................ 8-1
Clutch free play, adjusting .................... 7-18
D
Drive chain, cleaning and lubricating .... 7-22
Drive chain slack................................... 7-21
E
Engine break-in....................................... 6-4
Engine idling speed .............................. 7-14
Engine oil ................................................ 7-8
Engine serial number ............................ 10-1
Engine, starting a warm .......................... 6-2
Engine stop switch ................................. 4-1
F
Front fork, checking .............................. 7-26
Fuel ......................................................... 4-4
Fuel cock ................................................ 4-6
Fuel tank breather hose .......................... 4-5
Fuel tank cap .......................................... 4-3
Fuse, replacing ..................................... 7-29
H
Handlebar switches ................................ 4-1
I
Identification numbers .......................... 10-1
K
Kickstarter............................................... 4-7
L
Labels, location....................................... 1-1
M
Main switch ............................................. 4-1
Maintenance and lubrication, periodic ... 7-4
Maintenance, emission control
system .................................................. 7-3
Matte color, caution ................................ 8-1
Model label ........................................... 10-1
P
Panels, removing and installing.............. 7-6
Parking ................................................... 6-4
Part locations ......................................... 3-1
S
Safety defects, reporting
(For CANADA customers) .................. 10-3
Safety information .................................. 2-1
Seat ........................................................ 4-8
Shifting ................................................... 6-2
Shift pedal .............................................. 4-2
Shift pedal, checking ............................ 7-20
Shock absorber assembly ...................... 4-8
Sidestand ............................................... 4-9
Sidestand, checking and lubricating .... 7-25
Spark arrester, cleaning ....................... 7-12
Spark plug, checking ............................. 7-7
Specifications ......................................... 9-1
Starter (choke) lever ............................... 4-7
Starting and warming up a cold
engine .................................................. 6-1
Starting circuit cut-off system ................ 4-9
Start switch ............................................ 4-1
Steering, checking................................ 7-26
Storage ................................................... 8-4
Supporting the motorcycle................... 7-29
Swingarm pivots, lubricating ................ 7-25
T
Throttle grip and cable, checking and lubricating .......................................... 7-23
Throttle grip free play, checking........... 7-15
Tires ...................................................... 7-16
Tool kit.................................................... 7-2
Troubleshooting ................................... 7-33
Troubleshooting chart .......................... 7-34
V
Valve clearance .................................... 7-15
Vehicle Emission Control Information label (For Canada) .............................. 10-2
Vehicle identification number ............... 10-1
W
Wheel bearings, checking .................... 7-27
Wheel (front) ......................................... 7-30
Wheel (rear) .......................................... 7-31
Wheels .................................................. 7-17
UBMA80E0.book Page 1 Wednesday, October 20, 2021 8:57 AM
