Motorcycle care and stora ge
8-5
8
9. Remove the battery and fully char-
ge it. Store it in a cool, dry place
and charge it once a month. Do
not store the battery in an exces-
sively cold or warm place [less
than 0 °C (30 °F) or more than 30
°C (90 °F)]. For more information
on storing the battery, see page
7-27.
TIP
Make any necessary repairs before
storing the motorcycle.
U2CJ86E0.book Page 5 Tuesday, June 26, 2018 10:28 AM

Specifications
9-1
9
Dimensions:
Overall length:1305 mm (51.4 in)
Overall width:
595 mm (23.4 in)
Overall height: 795 mm (31.3 in)
Seat height: 555 mm (21.9 in)
Wheelbase:
925 mm (36.4 in)
Ground clearance: 135 mm (5.31 in)
Wei ght:
Curb weight:
58 kg (128 lb)
Maximum rider weight:
40.0 kg (88 lb)
Technical permissible mass (Maximum load +
Curb weight):
98 kg (216 lb)
Noise an d vi bration level:
Noise level (77/311/EEC):
76.7 dB(A) at 4250 r/min (TT-R50E)
Uncertainty of measurement:
3.0 dB(A) (TT-R50E)
Vibration on seat (EN1032, ISO5008): Will not exceed 0.5 m/s² (TT-R50E)
Uncertainty of measurement: 0.0 m/s² (TT-R50E)
Vibration on handlebar (EN1032, ISO5008):
Will not exceed 2.5 m/s² (TT-R50E)
Uncertainty of measurement: 0.6 m/s² (TT-R50E)
Engine:
Combustion cycle:
4-stroke
Cooling system: Air cooled
Valve train: SOHC
Number of cylinders:
Single cylinder
Displacement: 49 cm³
Bore × stroke:
36.0 × 48.6 mm (1.42 × 1.91 in)
Starting system:
Electric starter
Engine oil:
Recommended brand:
YAMALUBE
SAE viscosity grades:
10W-40
Recommended engine oil grade: API service SG type or higher, JASO
standard MA
Engine oil quantity: Oil change:
0.80 L (0.85 US qt, 0.70 Imp.qt)
Fuel:
Recommended fuel:Regular unleaded gasoline (Gasohol [E10]
acceptable)
Fuel tank capacity: 3.1 L (0.8 US gal, 0.7 Imp.gal)
Fuel reserve amount: 0.4 L (0.11 US gal, 0.09 Imp.gal)
Car buretor:
Type × quantity:
VM11 × 1
Drivetrain:
Gear ratio:
1st:
3.250 (39/12)
2nd:
1.737 (33/19)
3rd: 1.217 (28/23)
Front tire:
Type:
With tube
Size: 2.50-10 4PR
Manufacturer/model: CHENG SHIN/C183A
Speed rating:
100 km/h (62 mph)
Rear tire:
Type:With tube
Size:
2.50-10 4PR
Manufacturer/model: CHENG SHIN/C183A
Speed rating: 100 km/h (62 mph)
U2CJ86E0.book Page 1 Tuesday, June 26, 2018 10:28 AM

Specifications
9-2
9
Front brake:
Type:
Mechanical leading trailing drum brake
Rear brake:
Type:
Mechanical leading trailing drum brake
Front suspension:
Type:
Telescopic fork
Rear suspension:
Type:Swingarm
Electrical system:
System voltage:
12 V
Battery:
Model:GT4B-5
Voltage, capacity:
12 V, 2.5 Ah (10 HR)
EAU51132
For Europe only
The figures quoted are emission levels
and are not necessarily safe working
levels. Whilst there is a correlation be-
tween the emission and exposure lev-
els, this cannot be used reliably to
determine whether or not further pre-
cautions are required. Factors that in-
fluence the actual level of exposure of
work-force include the characteristics
of the work room, the other sources of
noise, etc. i.e. the number of machines
and other adjacent processes, and the
length of time for which an operator is
exposed to the noise. Also the permis-
sible exposure level can vary from
country. This information, however, will
enable the user of the machine to make
a better evaluation of the hazard and
risk.
U2CJ86E0.book Page 2 Tuesday, June 26, 2018 10:28 AM

Consumer information
10-1
10
EAU26366
Id entification num bers
Record the vehicle identification num-
ber and the engine serial number in the
spaces provided below for assistance
when ordering spare parts from a
Yamaha dealer or for reference in case the vehicle is stolen.
VEHICLE IDENTIFICATION NUMBER:
ENGINE SERIAL NUMBER:
EAU26401Vehicle i dentification num ber
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.
TIP
The vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
EAU26442En gine serial num ber
The engine serial number is stamped
into the crankcase.
EAU48121Vehicle Emission Control Informa-
tion la bel (For Canad a)
The Vehicle Emission Control Informa-
tion label is affixed at the location in the
illustration. This label shows specifica-
tions related to exhaust emissions as
required by federal law, state law and
Environment Canada.
1. Vehicle identification number
1
1. Engine serial number
1. Vehicle Emission Control Information label
1
1
U2CJ86E0.book Page 1 Tuesday, June 26, 2018 10:28 AM

11-1
11
Index
A
Air filter element, cleaning ...................... 7-9
B
Battery .................................................. 7-27
Brake lever ............................................. 4-3
Brake lever, checking and
lubricating .......................................... 7-23
Brake lever free play, adjusting ............ 7-17
Brake pedal ............................................ 4-4
Brake pedal, checking and lubricating .......................................... 7-24
Brake pedal free play, adjusting........... 7-18
Brake shoes, checking ......................... 7-19
C
Cables, checking and lubricating ......... 7-22
Carburetor, adjusting ........................... 7-11
Care ........................................................ 8-1
Clutch free play, adjusting ................... 7-16
D
Drive chain, cleaning and lubricating ... 7-22
Drive chain slack .................................. 7-20
E
Engine break-in ...................................... 6-3
Engine idling speed .............................. 7-12
Engine oil ................................................ 7-7
Engine serial number............................ 10-1
Engine, starting a warm ......................... 6-2
Engine stop switch ................................. 4-1
F
Front fork, checking ............................. 7-25
Fuel......................................................... 4-5
Fuel cock ................................................ 4-7
Fuel tank breather hose ......................... 4-6
Fuel tank cap.......................................... 4-4
Fuse, replacing ..................................... 7-28
H
Handlebar switches................................ 4-1
I
Identification numbers.......................... 10-1
L
Labels, location ...................................... 1-1
M
Main switch ............................................ 4-1
Maintenance and lubrication, periodic ... 7-4
Maintenance, emission control
system.................................................. 7-3
Matte color, caution ............................... 8-1
P
Parking ................................................... 6-4
Part locations ......................................... 3-1
S
Safety information................................... 2-1
Seat......................................................... 4-8
Shifting .................................................... 6-2
Shift pedal............................................... 4-3
Shift pedal, checking ............................ 7-19
Sidestand ................................................ 4-9
Sidestand, checking and lubricating .... 7-24
Spark arrester, cleaning ........................ 7-10
Spark plug, checking .............................. 7-6
Specifications ......................................... 9-1
Speed limiter ........................................... 4-2
Starter (choke) lever ................................ 4-8
Starting and warming up a cold engine ................................................... 6-1
Starting circuit cut-off system ................ 4-9
Start switch ............................................. 4-1
Steering, checking ................................ 7-26
Storage ................................................... 8-4
Supporting the motorcycle ................... 7-29
Swingarm pivots, lubricating ................ 7-25
T
Throttle grip and cable, checking and lubricating ........................................... 7-23
Throttle grip free play, checking ........... 7-13
Tires ...................................................... 7-14
Troubleshooting .................................... 7-33
Troubleshooting chart........................... 7-34
V
Valve clearance..................................... 7-13
Vehicle Emission Control Information
label (For Canada) .............................. 10-1
Vehicle identification number ............... 10-1
W
Wheel bearings, checking..................... 7-26
Wheel (front).......................................... 7-30
Wheel (rear) ........................................... 7-31
Wheels .................................................. 7-15
U2CJ86E0.book Page 1 Tuesday, June 26, 2018 10:28 AM

WARNING
NEVER operate:
Improper motorcycle use can result in SEVERE INJURY or DEATH.
LOCATE AND READ OWNER’S MANUAL. FOLLOW ALL
INSTRUCTIONS AND WARNINGS.



without proper training or instruction.
at speeds too fast for your skills or the conditions.
on public roads—a collision can occur with another vehicle.
with a passenger—passengers affect balance and steering and
increase risk of losing control.
ALWAYS:


use proper riding techniques to avoid vehicle overturns on hills and
rough terrain and in turns.
avoid paved surfaces—pavement may seriously affect handling and
control.
ALWAYS USE
AN APPROVED HELMET AND
PROTECTIVE GEAR NEVER USE
ON PAVED ROADS NEVER CARRY
PASSENGERS
PRINTED IN CHINA 2018.06
