fuel YAMAHA TT-R50E 2019 Owners Manual

Table of contents
Location of important la bels ........... 1-1
Safety information ............................ 2-1
Description ....................................... 3-1
Left view ......................................... 3-1
Right view ....................................... 3-2
Controls and instruments ............... 3-3
Instrument an d control functions ... 4-1
Main switch .................................... 4-1
Handlebar switches ........................ 4-1
Speed limiter .................................. 4-2
Shift pedal ...................................... 4-3
Brake lever...................................... 4-3
Brake pedal .................................... 4-4
Fuel tank cap .................................. 4-4
Fuel ................................................. 4-5
Fuel tank breather hose.................. 4-6
Fuel cock ........................................ 4-7
Starter (choke) lever ...................... 4-8
Seat ................................................ 4-8
Sidestand ....................................... 4-9
Starting circuit cut-off system ........ 4-9
For your safety – pre-operation
checks ............................................... 5-1
Operation an d important ri din g
points ................................................ 6-1
Starting and warming up a cold engine ......................................... 6-1
Starting a warm engine .................. 6-2
Shifting ........................................... 6-2
Engine break-in .............................. 6-3
Parking ........................................... 6-4
Perio dic maintenance an d
a d justment ........................................ 7-1
Periodic maintenance chart for the emission control system ............. 7-3
General maintenance and lubrication chart .......................... 7-4
Checking the spark plug ................ 7-6
Engine oil ........................................ 7-7
Cleaning the air filter element ......... 7-9 Cleaning the spark arrester ........... 7-10
Adjusting the carburetor ............... 7-11
Adjusting the engine idling
speed ......................................... 7-12
Checking the throttle grip free
play ............................................ 7-13
Valve clearance ............................. 7-13
Tires .............................................. 7-14
Spoke wheels ................................ 7-15
Adjusting the clutch free play........ 7-16
Adjusting the brake lever free play ............................................ 7-17
Adjusting the brake pedal free play ............................................ 7-18
Checking the shift pedal ............... 7-19
Checking the front and rear brake shoes ......................................... 7-19
Drive chain slack ........................... 7-20
Cleaning and lubricating the drive chain ................................. 7-22
Checking and lubricating the cables ........................................ 7-22
Checking and lubricating the
throttle grip and cable ............... 7-23
Checking and lubricating the brake lever ................................. 7-23
Checking and lubricating the brake pedal ................................ 7-24
Checking and lubricating the
sidestand ................................... 7-24
Lubricating the swingarm pivots ... 7-25
Checking the front fork ................. 7-25
Checking the steering ................... 7-26
Checking the wheel bearings ........ 7-26
Battery........................................... 7-27
Replacing the fuse ........................ 7-28
Supporting the motorcycle ........... 7-29
Front wheel ................................... 7-30
Rear wheel .................................... 7-31
Troubleshooting ............................ 7-33
Troubleshooting chart ................... 7-34
Motorcycle care an d stora ge .......... 8-1
Matte color caution ......................... 8-1
Care................................................. 8-1
Storage............................................ 8-4
U2CJ86E0.book Page 1 Tuesday, June 26, 2018 10:28 AM

Safety information
2-4
2Aftermarket Parts, Accessories, an
d
Mo difications
While you may find aftermarket prod-
ucts similar in design and quality to
genuine Yamaha accessories, recog-
nize that some aftermarket accesso-
ries or modifications are not suitable
because of potential safety hazards to
you or others. Installing aftermarket
products or having other modifications
performed to your vehicle that change
any of the vehicle’s design or operation
characteristics can put you and others
at greater risk of serious injury or
death. You are responsible for injuries
related to changes in the vehicle.
Keep the following guidelines in mind,
as well as those provided under “Load-
ing” when mounting accessories.  Never install accessories that
would impair the performance of
your motorcycle. Carefully inspect
the accessory before using it to
make sure that it does not in any
way reduce ground clearance or
cornering clearance, limit suspen-
sion travel, steering travel or con-
trol operation.
• Accessories fitted to the han- dlebar or the front fork area can
create instability due to improp-
er weight distribution. If acces-
sories are added to the
handlebar or front fork area,
they must be as lightweight as
possible and should be kept to
a minimum.
• Bulky or large accessories may seriously affect the stability of
the motorcycle. Wind may at- tempt to lift the motorcycle, or
the motorcycle may become
unstable in cross winds.
• Certain accessories can dis- place the operator from his or
her normal riding position. This
improper position limits the
freedom of movement of the
operator and may limit control
ability, therefore, such accesso-
ries are not recommended.
 Use caution when adding electri-
cal accessories. If electrical ac-
cessories exceed the capacity of
the motorcycle’s electrical sys-
tem, an electric failure could re-
sult, which could cause a
dangerous loss of lights or engine
power.
Aftermarket Tires an d Rims
The tires and rims that came with your
motorcycle were designed to match
the performance capabilities and to
provide the best combination of han-
dling, braking, and comfort. Other
tires, rims, sizes, and combinations
may not be appropriate. Refer to page
7-14 for tire specifications and more in-
formation on replacing your tires.
Transportin g the Motorcycle
Be sure to observe following instruc-
tions before transporting the motorcy-
cle in another vehicle.  Remove all loose items from the
motorcycle.
 Check that the fuel cock (if
equipped) is in the “OFF” position
and that there are no fuel leaks.
U2CJ86E0.book Page 4 Tuesday, June 26, 2018 10:28 AM

Description
3-1
3
EAU63371
Left view
12 34 576
1. Fuel cock (page 4-7)
2. Throttle stop screw (page 7-12)
3. Air filter element (page 7-9)
4. Fuse (page 7-28)
5. Battery (page 7-27)
6. Engine oil drain bolt (page 7-7)
7. Shift pedal (page 4-3)
U2CJ86E0.book Page 1 Tuesday, June 26, 2018 10:28 AM

Description
3-2
3
EAU63391
Right view
4
65 3 2
1
1. Seat (page 4-8)
2. Fuel tank cap (page 4-4)
3. Spark plug cap (page 7-6)
4. Brake pedal (page 4-4)
5. Clutch adjusting screw (page 7-16)
6. Engine oil filler cap (page 7-7)
U2CJ86E0.book Page 2 Tuesday, June 26, 2018 10:28 AM

Instrument and control functions
4-4
4
EAU12944
Brake ped al
The brake pedal is located on the right
side of the motorcycle. To apply the
rear brake, press down on the brake
pedal.
EAU13183
Fuel tank cap
To remove the fuel tank cap, turn it
counterclockwise, and then pull it off.
To install the fuel tank cap, insert it into
the tank opening, and then turn it
clockwise.
WARNING
EWA11092
Make sure that the fuel tank cap is
properly close d after fillin g fuel.
Leakin g fuel is a fire hazar d.
1. Brake pedal
1
1. Fuel tank cap
1
U2CJ86E0.book Page 4 Tuesday, June 26, 2018 10:28 AM

Instrument and control functions
4-5
4
EAU13213
Fuel
Make sure there is sufficient gasoline in
the tank.
WARNING
EWA10882
Gasoline an d gasoline vapors are
extremely flamma ble. To avoi d fires
an d explosions an d to re duce the
risk of injury when refuelin g, follow
these instructions.
1. Before refueling, turn off the en- gine and be sure that no one is sit-
ting on the vehicle. Never refuel
while smoking, or while in the vi-
cinity of sparks, open flames, or
other sources of ignition such as
the pilot lights of water heaters
and clothes dryers.
2. Do not overfill the fuel tank. Stop filling when the fuel reaches the
bottom of the filler tube. Because
fuel expands when it heats up,
heat from the engine or the sun
can cause fuel to spill out of the
fuel tank.
3. Wipe up any spilled fuel immedi- ately. NOTICE: Immediately
wipe off spille d fuel with a clean, d
ry, soft cloth, since fuel may
d eteriorate painte d surfaces or
plastic parts.
[ECA10072]
4. Be sure to securely close the fuel tank cap.
WARNING
EWA15152
Gasoline is poisonous an d can cau-
se injury or death. Han dle gasoline
with care. Never siphon gasoline by
mouth. If you shoul d swallow some
g asoline or inhale a lot of gasoline
vapor, or get some g asoline in your
eyes, see your doctor imme diately. If
g asoline spills on your skin, wash
with soap an d water. If gasoline
spills on your clothin g, chan ge your
clothes.
EAU50255
NOTICE
ECA11401
Use only unlea ded g asoline. The use
of lead ed g asoline will cause severe
d amag e to internal en gine parts,
such as the valves an d piston rin gs,
as well as to the exhaust system.
Cana da
Use gasoline with a pump octane num-
ber [(R+M)/2] of 86 or higher (research
octane number of 91 or higher).1. Fuel tank filler tube
2. Maximum fuel level
12
Recommen ded fuel:
Regular unleaded gasoline
(Gasohol E10 acceptable)
Fuel tank capacity: 3.1 L (0.8 US gal, 0.7 Imp.gal)
Fuel reserve amount:
0.4 L (0.11 US gal, 0.09 Imp.gal)
U2CJ86E0.book Page 5 Tuesday, June 26, 2018 10:28 AM

Instrument and control functions
4-6
4 Australia, New Zealan
d, South Africa
Use gasoline with a research octane
number of 91 or higher.
Europe
Use gasoline with a research octane
number of 95 or higher.
TIP
 If knocking (or pinging) occurs, try
gasoline of a different brand or use
premium unleaded gasoline.
 Gasohol containing ethanol can
be used if the ethanol content
does not exceed 10% (E10).
 Gasohol containing methanol is
not recommended by Yamaha be-
cause it can cause damage to the
fuel system or vehicle perfor-
mance problems.
For Europe
TIP
This mark identifies the recom-
mended fuel for this vehicle as
specified by European regulation
(EN228).
 Confirm the fuel dispenser nozzle
has the same mark.
EAU13414
Fuel tank breather hose
Before operating the motorcycle:
 Check the fuel tank breather hose
connection.
 Check the fuel tank breather hose
for cracks or damage, and replace
it if necessary.
 Make sure that the fuel tank
breather hose is not blocked, and
clean it if necessary.
E5E10
1. Fuel tank breather hose
1
U2CJ86E0.book Page 6 Tuesday, June 26, 2018 10:28 AM

Instrument and control functions
4-7
4
EAU13562
Fuel cock
The fuel cock supplies fuel from the
tank to the carburetor while filtering it
also.
The fuel cock has three positions:
OFF
With the lever in this position, fuel will
not flow. Always return the lever to this
position when the engine is not run-
ning.
ON
With the lever in this position, fuel flows
to the carburetor. Normal riding is done
with the lever in this position. RES
This indicates reserve. If you run out of
fuel while riding, move the lever to this
position. Fill the tank at the first oppor-
tunity. Be sure to set the lever back to
“ON” after refueling!
1. Arrow mark positioned over “OFF”
1. Arrow mark positioned over “ON”
1. Arrow mark positioned over “RES”
U2CJ86E0.book Page 7 Tuesday, June 26, 2018 10:28 AM

Instrument and control functions
4-8
4
EAU13591
Starter (choke) lever “ ”
Starting a cold engine requires a richer
air-fuel mixture, which is supplied by
the starter (choke).
Move the lever in direction (a) to turn on
the starter (choke).
Move the lever in direction (b) to turn
off the starter (choke).
EAU13962
Seat
To remove the seat
Remove the bolts, and then pull the
seat off.
To install the seat
1. Insert the projections on the front of the seat into the seat holders as
shown.
2. Place the seat in the original posi- tion, and then tighten the bolts.
TIP
Make sure that the seat is properly se-
cured before riding.
1. Starter (choke) lever “ ”
1
(a)
(b)
1. Bolt
1. Projection
2. Seat holder
U2CJ86E0.book Page 8 Tuesday, June 26, 2018 10:28 AM

For your safety – pre-operation checks
5-1
5
EAU63441
Inspect your vehicle each time you use it to make sure the vehicle is in safe oper-
ating condition. Always follow the inspection and maintenance procedures and
schedules described in the Owner’s Manual.
WARNING
EWA11152
Failure to inspect or maintain the vehicle properly increases the possibility
of an acci dent or equipment d amage. Do not operate the vehicle if you fin d
any prob lem. If a pro blem cannot be corrected b y the proce dures provi ded
in this manual, have the vehicle inspecte d b y a Yamaha d ealer.
Before using this vehicle, check the following points:
ITEM CHECKSPAGE
Fuel • Check fuel level in fuel tank.
• Refuel if necessary.
• Check fuel line for leakage.
• Check fuel tank breather hose for obstructions, cracks
or damage, and check hose connection. 4-5, 4-6
En gine oil • Check oil level in engine.
• If necessary, add recommended oil to specified level.
• Check vehicle for oil leakage. 7-7
Front brake • Check operation.
• Lubricate cable if necessary.
• Check lever free play.
• Adjust if necessary. 7-17,
7-19
Rear brake • Check operation.
• Check pedal free play.
• Adjust if necessary. 7-18,
7-19
Throttle g rip • Make sure that operation is smooth.
• Check throttle grip free play.
• If necessary, have Yamaha dealer adjust throttle grip
free play and lubricate cable and grip housing. 7-13,
7-23
Control ca bles • Make sure that operation is smooth.
• Lubricate if necessary. 7-22
Drive chain • Check chain slack.
• Adjust if necessary.
• Check chain condition.
• Lubricate if necessary. 7-20,
7-22
Wheels an d tires •Check for damage.
• Check tire condition and tread depth.
• Check air pressure.
• Correct if necessary. 7-14,
7-15
Shift pe dal • Make sure that operation is smooth.
• Correct if necessary. 7-19
Brake ped al • Make sure that operation is smooth.
• Lubricate pedal pivoting point if necessary.
7-24
U2CJ86E0.book Page 1 Tuesday, June 26, 2018 10:28 AM
