technical specifications YAMAHA TTR50 2013 Owners Manual

EAU46226
Read this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.
EC Declaration of Conformityconforming to Directive 2006/42/EC
We, YAMAHA MOTOR CO., LTD. 2500 Shingai, Iwata, Japan, declare in sole responsibility, that the product
TT-R50E (LBPCA01W000402301– )
(Make, model)2004/108/EC
(Title and/or number and date of issue of the other Directives of EEC)
to which this declaration applies, conforms to the essential health
and safety requirements of Directive 2006/42/EC(If applicable)and to the other relevant Directives of EEC
(If applicable)To effect correct application of the essential health and safety requirements
stated in the Directives of EEC, the following-standards and/or technical
specifications were consulted:
(Title and/or number and date of issue of standards and/or specifications)
Manufacturer
CHONGQING JIANSHE YAMAHA MOTOR CO.,LTD.
No.1 Huacheng Road B Zone Jiulongpo Park Jiulongpo District Chongqing, China
Authorized Representative
YAMAHA MOTOR EUROPE N.V.
Koolhovenlaan 101, 1119 NC Schiphol-Rijk, The Netherlands
Signature
Hiromi Yamamoto
Date of Issue
16 May , 2012
EN16029General Manager.
Development Division
3rd Business Unit
Motorcycle Business Operations
YAMAHA MOTOR CO., LTD.
U2CJ80E0.book Page 1 Tuesday, June 12, 2012 11:15 AM

SPECIFICATIONS
9-1
9
Dimensions:Overall length:1305 mm (51.4 in)
Overall width:
595 mm (23.4 in)
Overall height: 795 mm (31.3 in)
Seat height: 555 mm (21.9 in)
Wheelbase:
925 mm (36.4 in)
Ground clearance: 135 mm (5.31 in)Weight:Curb weight:
57 kg (126 lb)
Technical permissible mass (Maximum load +
curb weight):
97 kg (214 lb)Noise and vibration level:Noise level (77/311/EEC):TT-R50E 76.7 dB(A)@4250 r/min
Vibration on seat (EN1032, ISO5008):
TT-R50E Will not exceed 0.5 m/s²
Vibration on handlebar (EN1032, ISO5008): TT-R50E Will not exceed 2.5 m/s²Engine:Engine type:
Air cooled 4-stroke, SOHC
Cylinder arrangement: Single cylinder
Displacement: 49 cm³ Bore
× stroke:
36.0 × 48.6 mm (1.42 × 1.91 in)
Compression ratio: 9.50 : 1
Starting system:
Electric starter
Lubrication system: Wet sump
Engine oil:Recommended brand:
YAMALUBE
Type: SAE 10W-30, 10W-40, 10W-50, 15W-40,
20W-40 or 20W-50
Recommended engine oil grade: API service SG type or higher, JASO
standard MA
Engine oil quantity: Periodic oil change:
0.80 L (0.85 US qt, 0.70 Imp.qt)Air filter:Air filter element:Wet element
Fuel:Recommended fuel:TT-R50E Regular unleaded gasoline
(Gasohol (E10) acceptable)
TT-R50ED Regular unleaded gasoline
(Gasohol (E10) acceptable) (CAN)
TT-R50ED Unleaded gasoline (Gasohol
(E10) acceptable) (AUS)(NZL)
Fuel tank capacity: 3.1 L (0.82 US gal, 0.68 Imp.gal)
Fuel reserve amount: 0.4 L (0.11 US gal, 0.09 Imp.gal)Carburetor:Type × quantity:
VM11 x 1Spark plug(s):Manufacturer/model:
NGK/CR7HSA
Spark plug gap: 0.6–0.7 mm (0.024–0.028 in)Clutch:Clutch type:
Wet, multiple-disc and centrifugal
automaticTransmission:Primary reduction ratio:3.722 (67/18)
Final drive: Chain
Secondary reduction ratio:
2.846 (37/13)
Transmission type: Constant mesh 3-speed
–20 –10 0 1020 30 40 50 C
10 30 50 70 90 110
0 130 F
SAE 10W-30
SAE 15W-40SAE 20W-40SAE 20W-50
SAE 10W-40SAE 10W-50
