PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
6-39
EAU03009Troubleshooting chartEW000125
w
Never check the fuel system while smoking or in the vicinity of an open flame.
1. Fuel
2. Compression
3. Ignition
4. Battery
Use the electric starter.
Remove spark
There is compression.
Go to ignition check.
No compression.
Ask a Yamaha dealer to inspect.
Wet.
Dry.Wipe clean with dry cloth and Open throttle half-way and start
Ask a Yamaha dealer to inspect.
Engine turns over
Engine turns overBattery good.
Check fluid, recharge,
Use the electric starter.
Check if there is fuel
Enough fuel.
No fuel.Go to compression check.
Supply fuel.
in the fuel tank.
electrodes. plug and check
quickly.
slowly. check connections.Engine doesn’t start, go to battery
check.the engine. correct spark gap or replace plug.
Engine doesn’t start, ask a Yamahadealer to inspect.
Engine doesn’t start, go to compression check.
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 69

7-1
EAU01518
MOTORCYCLE CARE AND STORAGE
1
2
3
4
5
6
7
8
9
Care
The exposure of its technology
makes a motorcycle charming but
also vulnerable. Although high-
quality components are used, they
are not all rust-resistant. While a
rusty exhaust pipe may remain
unnoticed on a car, it does look
unattractive on a motorcycle.
Frequent and proper care, howev-
er, will keep your motorcycle look-
ing good, extend its life and main-
tain its performance. Moreover, the
warranty states that the vehicle
must be properly taken care of. For
all these reasons, it is recommend-
ed that you observe the following
cleaning and storing precautions.Before cleaning
1. Cover up the muffler outlet
with a plastic bag.
2. Make sure that all caps and
covers as well as all electrical
couplers and connectors,
including the spark plug cap,
are tightly installed.
3. Remove extremely stubborn
dirt, like oil burnt onto the
crankcase, with a degreasing
agent and a brush, but never
apply such products onto
seals, gaskets, sprockets, the
drive chain and wheel axles.
Always rinse the dirt and
degreaser off with water.Cleaning
After normal use
Remove dirt with warm water, a
neutral detergent and a soft clean
sponge, then rinse with plenty of
clean water. Use a tooth or bottle
brush for hard-to-reach parts.
Tougher dirt and insects will come
off more easily if the area is cov-
ered with a wet cloth for a few
minutes before cleaning.
ECA00010
cC
8Avoid using strong acidic
wheel cleaners, especially on
spoked wheels. If you do use
such products for hard-to-
remove dirt, do not leave it on
any longer than instructed,
then thoroughly rinse it off
with water, immediately dry
the area and apply a corrosion
protection spray.
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 70

7-2
MOTORCYCLE CARE AND STORAGE
1
2
3
4
5
6
7
8
9 8Improper cleaning can damage
windshields, cowlings, panels
and other plastic parts. Use
only a soft, clean cloth or
sponge with mild detergent
and water to clean plastic.
8Do not use any harsh chemical
products on plastic parts. Be
sure to avoid using cloths or
sponges which have been in
contact with strong or abra-
sive cleaning products, solvent
or thinner, fuel (gasoline), rust
removers or inhibitors, brake
fluid, antifreeze or electrolyte.8Do not use high-pressure
washers or steam-jet cleaners
since they cause water seep-
age and deterioration in the
following areas: seals (of
wheel bearings, swingarm
bearings, forks and brakes),
electric components (couplers,
connectors, instruments,
switches and lights), breather
hoses and vents.
8For motorcycles equipped
with a windshield: Do not use
strong cleaners or hard
sponges as they will cause
dulling or scratching. Some
cleaning compounds for plas-
tic may leave scratches on the
windshield. Test the product
on a small hidden part of the
windshield to make sure they
do not leave any marks. If the
windshield is scratched, use a
quality plastic polishing com-
pound after washing.
After riding in the rain, near the
sea or on salt-sprayed roads
Since sea salt or salt sprayed on
the roads in the winter are
extremely corrosive in combina-
tion with water, carry out the fol-
lowing steps after each ride in the
rain, near the sea or on salt-
sprayed roads. (Salt sprayed in the
winter may remain on the roads
well into spring.)
1. Clean your motorcycle with
cold water and soap after the
engine has cooled down.
ECA00012
cC
Do not use warm water since it
increases the corrosive action of
the salt.
2. Be sure to apply a corrosion
protection spray on all (even
chrome- and nickel-plated)
metal surfaces to prevent cor-
rosion.
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 71

7-3
MOTORCYCLE CARE AND STORAGE
1
2
3
4
5
6
7
8
9After cleaning
1. Dry the motorcycle with a
chamois or an absorbing cloth.
2. Immediately dry the drive
chain and lubricate it to pre-
vent it from rusting.
3. Use a chrome polish to shine
chrome, aluminum and stain-
less-steel parts, including the
exhaust system. (Even the
thermally induced discoloring
of stainless-steel exhaust sys-
tems can be removed through
polishing.)
4. To prevent corrosion, it is rec-
ommended to apply a corro-
sion protection spray on all
(even chrome- and nickel-plat-
ed) metal surfaces.
5. Use spray oil as a universal
cleaner to remove any remain-
ing dirt.
6. Touch up minor paint damage
caused by stones, etc.
7. Wax all painted surfaces.8. Let the motorcycle dry com-
pletely before storing it or cov-
ering it.
EWA00001
w
Make sure that there is no oil or
wax on the brakes and tires. If nec-
essary, clean the brake discs and
linings with a regular brake disc
cleaner or acetone, and wash the
tires with warm water and mild
soap. Then, carefully test the
motorcycle for its braking perfor-
mance and cornering behavior.
ECA00013
cC
8Apply spray oil and wax spar-
ingly and wipe off any excess.
8Never apply oil or wax on rub-
ber and plastic parts, but treat
them with a suitable care
product.
8Avoid using abrasive polishing
compounds as they wear
away the paint.
NOTE:
Consult a Yamaha dealer for
advice on what products to use.
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 72

7-4
MOTORCYCLE CARE AND STORAGE
1
2
3
4
5
6
7
8
9
Storage
Short-term
Always store your motorcycle in a
cool, dry place and, if necessary,
protect it against dust with a
porous cover.
ECA00014
cC
8Storing the motorcycle in a
poorly ventilated room or cov-
ering it with a tarp while it is
still wet will allow water and
humidity to seep in and cause
rust.
8To prevent corrosion, avoid
damp cellars, stables (because
of the presence of ammonia)
and areas where strong chem-
icals are stored.
Long-term
Before storing your motorcycle for
several months:
1. Follow all the instructions in
the “Care” section of this
chapter.
2. Drain the carburetor float
chamber by loosening the
drain bolt; this will prevent fuel
deposits from building up.
Pour the drained fuel into the
fuel tank.
3. Only for motorcycles equipped
with a fuel cock which has an
“OFF” position: Turn the fuel
cock to “OFF”.
4. Fill up the fuel tank and add
fuel stabilizer (if available) to
prevent the fuel tank from rust-
ing and the fuel from deterio-
rating.
5. Perform the following steps to
protect the cylinder, piston
rings, etc. from corrosion.
a. Remove the spark plug cap
and spark plug.b. Pour a teaspoonful of engine
oil into the spark plug bore.
c. Install the spark plug cap onto
the spark plug and place the
spark plug on the cylinder
head so that the electrodes are
grounded. (This will limit
sparking during the next step.)
d. Turn the engine over several
times with the starter. (This
will coat the cylinder wall with
oil.)
e. Remove the spark plug cap
from the spark plug, install the
spark plug and then the spark
plug cap.
EWA00003
w
When turning the engine over, be
sure to ground the spark plug elec-
trodes to prevent damage or injury
from sparking.
6. Lubricate all control cables and
the pivoting points of all levers
and pedals as well as of the
sidestand/centerstand.
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 73

7-5
MOTORCYCLE CARE AND STORAGE
1
2
3
4
5
6
7
8
97. Check and, if necessary, cor-
rect the tire air pressure, then
raise the motorcycle so that
both of its wheels are off the
ground. Alternatively, turn the
wheels a little every month in
order to prevent the tires from
becoming degraded in one
spot.
8. Cover up the muffler outlet
with a plastic bag to prevent
moisture from entering.
9. Remove the battery and fully
charge it. Store it in a cool, dry
place and recharge it once a
month. Do not store the bat-
tery in an excessively cold or
warm place (less than 0°C or
more than 30°C). For more
information, see “Battery stor-
age” in the chapter “PERIODIC
MAINTENANCE AND MINOR
REPAIRS”.
NOTE:
Make any necessary repairs before
storing the motorcycle.
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 74

8-1
EAU01038
SPECIFICATIONS
1
2
3
4
5
6
7
8
9
Specifications
Model TW125
Dimensions
Overall length 2,140 mm
Overall width 810 mm
Overall height 1,120 mm
Seat height 805 mm
Wheelbase 1,330 mm
Ground clearance 260 mm
Minimum turning radius 2,100 mm
Basic weight (with oil and full
fuel tank)125 kg
Engine
Engine type Air-cooled 4-stroke, SOHC
Cylinder arrangement Forward inclined
single cylinder
Displacement 124 cm
3
Bore ´Stroke 57.0 ´48.8 mm
Compression ratio 10:1
Starting system Electric starter
Lubrication system Wet sumpEngine oil
Type
Recommended engine oil
classification API Service SE, SF, SG type
or higher
cC
Be sure to use motor oils that do not contain anti-friction
modifiers. Passenger car motor oils (often labeled “Energy
Conserving”) contain anti-friction additives which will cause
clutch and/or starter clutch slippage, resulting in reduced
component life and poor engine performance.
Capacity
Periodic oil change 1.0 L
With oil filter replacement 1.1 L
Total amount 1.3 L
Air filterWet type element
–10° 0° 10° 20° 30°
40°
SAE 10W/30
SAE 10W/40
SAE 20W/40
SAE 20W/50
–20°
SAE 15W/40 50°C
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 75

Fuel
Type Regular unleaded gasoline
Fuel tank capacity 7.0 L
Reserve amount 1.0 L
Carburetor
Type/quantity Y24P/1
Manufacturer TEIKEI
Spark plug
Manufacturer / Type NGK / DR8EA
Spark plug gap 0.6 ~ 0.7 mm
Clutch typeWet, multiple-disc
Transmission
Primary reduction system Spur gear
Primary reduction ratio 74/20 (3.700)
Secondary reduction system Chain drive
Secondary reduction ratio 50/14 (3.571)
Transmission type Constant mesh 5-speed
Operation Left foot operationGear ratio 1st 2.250
2nd 1.476
3rd 1.125
4th 0.926
5th 0.793
Chassis
Frame type Diamond
Frame type Pressed and steel tube frame
Caster angle 26°
Trail 95 mm
Tires
Type With tube
Front
Size 130/80-18 66P
Manufacturer/ BRIDGESTONE / TW31
model
Rear
Size 180/80-14M/C 78P
Manufacturer/ BRIDGESTONE / TW34
model
Maximum load* 180 kg
Air pressure (cold tire)
up to 80 kg load*
SPECIFICATIONS
1
2
3
4
5
6
7
8
9
8-2
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 76

8-3
SPECIFICATIONS
1
2
3
4
5
6
7
8
9
Front150 kPa (1.50 kg/cm2, 1.50 bar)
Rear150 kPa (1.50 kg/cm2, 1.50 bar)
80 kg load ~ Maximum
load*
Front
150 kPa (1.50 kg/cm2, 1.50 bar)
Rear175 kPa (1.75 kg/cm2, 1.75 bar)
Off-road riding
Front
125 kPa (1.25 kg/cm2, 1.25 bar)
Rear125 kPa (1.25 kg/cm2, 1.25 bar)
*Load is total weight of cargo, rider, passenger and accessories.
Wheels
Front
Type Spoke wheel
Size 2.50 ´18
Rear
Type Spoke wheel
Size 14M/C ´MT4.50
Brakes
Front
Type Single disc brake
Operation Right hand operation
Fluid DOT 3 or DOT 4Rear
Type Drum brake
Operation Right foot operation
Suspension
Front
Type Telescopic fork
Rear
Type Swingarm (Monocross
suspension)
Shock absorber
Front Coil spring/oil damper
Rear Coil-gas spring/oil damper
Wheel travel
Front 160 mm
Rear 150 mm
Electrical
Ignition system C.D.I.
Charging system
Type C.D.I. magneto
Standard output 12 V, 11 A @ 5,000 rpm
Battery
Type GM7CZ-3D
Voltage, capacity 12 V, 7 AH
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 77

Headlight bulb typeIncandescence
Bulb voltage, wattage ´quantity
Headlight 12 V, 45 W/40 W ´1
Stop/tail light 12 V, 21 W/5 W ´1
Front flasher light 12 V, 21 W ´2
Rear flasher light 12 V, 21 W ´2
Marker light 12 V, 4 W ´1
Meter light 12 V, 3.4 W ´1
Neutral indicator light 12 V, 3.4 W ´1
High beam indicator light 12 V, 3.4 W ´1
Turn indicator light 12 V, 3.4 W ´1
Fuse
Main 20 A
SPECIFICATIONS
1
2
3
4
5
6
7
8
9
8-4
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 78
