check engine YAMAHA TW125 2000 Owners Manual

EAU00009
TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9
1
5
GIVE SAFETY THE RIGHT OF WAY ..................1-1
DESCRIPTION .....................................................2-1
Left view............................................................2-1
Right view .........................................................2-2
Controls/Instruments .......................................2-3
INSTRUMENT AND CONTROL
FUNCTIONS ........................................................3-1
Main switch ......................................................3-1
Indicator lights..................................................3-1
Speedometer ....................................................3-2
Handlebar switches..........................................3-2
Clutch lever .......................................................3-4
Shift pedal.........................................................3-4
Front brake lever ..............................................3-4
Rear brake pedal ..............................................3-5
Fuel tank cap.....................................................3-5
Fuel ....................................................................3-6
Fuel cock ...........................................................3-7
Starter (choke) “1” .........................................3-8
Steering lock .....................................................3-8
Seat ...................................................................3-9
Helmet holder ...................................................3-9
Rear shock absorber ......................................3-10
Rear carrier .....................................................3-10
Luggage strap holders ...................................3-10Sidestand ........................................................3-11
Sidestand/clutch switch operation check .....3-12
PRE-OPERATION CHECKS.................................4-1
Pre-operation check list ...................................4-1
OPERATION AND IMPORTANT RIDING
POINTS................................................................5-1
Starting the engine ..........................................5-1
Starting a warm engine ...................................5-4
Shifting..............................................................5-4
Tips for reducing fuel consumption ...............5-5
Engine break-in ................................................5-5
Parking ..............................................................5-6
PERIODIC MAINTENANCE AND MINOR
REPAIR ................................................................6-1
Tool kit ..............................................................6-1
Periodic maintenance and lubrication............6-3
Cowling and panel removal and
installation ........................................................6-6
Panel A ..............................................................6-6
Panel B ..............................................................6-7
Cowling C..........................................................6-8
Spark plug.........................................................6-8
Engine oil ..........................................................6-9
Air filter ...........................................................6-121
2
3
4
6
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 5

2-2
DESCRIPTION
1
2
3
4
5
6
7
8
9
8. Rear carrier (page 3-10)
9. Battery (page 6-30)
10. Fuse (page 6-31)11. Tool kit (page 6-1)
12. Rear brake pedal (page 3-5, 6-20)
13. Engine oil level check window (page 6-9)
89
10
1112 13Right view
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 9

3-8
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
EAU02976Starter (choke) “1”
Starting a cold engine requires a
richer air-fuel mixture. A separate
starter circuit supplies this mixture.
Move in direction ato turn on the
starter (choke).
Move in direction bto turn off the
starter (choke).
1. Starter (choke) “1”
EAU02934Steering lock
To lock the steering
Turn the handlebars all the way to
the right and open the steering
lock cover.
Insert the key and turn it 1/8 turn
counterclockwise. Then, push the
key in while turning the handlebars
slightly to the left and turn the key
1/8 turn clockwise.
Check that the steering is locked,
remove the key and close the lock
cover.
1. Steering lock
2. Cover
To unlock the steering
Insert the key, push it in and turn it
1/8 turn counterclockwise so that it
moves out. Then, release and
remove the key.
a
b
1
12
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 18

3-12
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
EAU00331Sidestand/clutch switch
operation check
Check the operation of the side-
stand switch and clutch switch
against the information below.
EW000045
w
If improper operation is noted,
consult a Yamaha dealer immedi-
ately.
SIDESTAND IS DOWN.
ENGINE WILL STALL.
SIDESTAND SWITCH IS OK.
TURN THE MAIN SWITCH TO “ON”
AND THE ENGINE STOP SWITCH TO
“#”.
TRANSMISSION IS IN GEAR AND
SIDESTAND IS UP.
PULL IN CLUTCH LEVER AND
PUSH THE START SWITCH.
ENGINE WILL START.
CLUTCH SWITCH IS OK.
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 22

4-1
EAU01114
PRE-OPERATION CHECKS
1
2
3
4
5
6
7
8
9 Owners are personally responsible for their vehicle’s condition. Your motorcycle’s vital functions can start to
deteriorate quickly and unexpectedly, even if it remains unused (for instance, if it is exposed to the elements).
Any damage, fluid leak or loss of tire pressure could have serious consequences. Therefore, it is very important
that, in addition to a thorough visual inspection, you check the following points before each ride.
EAU00340PRE-OPERATION CHECK LIST
ITEM CHECKS PAGE
Front
brake9Check operation, free play, fluid level and vehicle for fluid leakage.
3-4, 6-19 ~ 6-20, 6-22 ~ 6-23
9Fill with DOT 4 (or DOT 3) brake fluid if necessary.
Rear brake9Check operation, condition and free play.
3-5, 6-20 ~ 6-22
9Adjust if necessary.
Clutch9Check operation, condition and free play.
3-4, 6-19
9Adjust if necessary.
Throttle grip and housing9Check for smooth operation.
6-15, 6-26
9Lubricate if necessary.
Engine oil9Check oil level.
6-9 ~ 6-12
9Fill with oil if necessary.
Drive chain9Check chain slack and condition.
6-24 ~ 6-25
9Adjust if necessary.
Wheels and tires9Check tire pressure, wear, damage and spoke tightness.
6-16 ~ 6-18
9Tighten spokes if necessary.
Brake and shift pedal shafts9Check for smooth operation.
6-27
9Lubricate if necessary.
Brake and clutch lever pivots9Check for smooth operation.
6-27
9Lubricate if necessary.
Sidestand pivot9Check for smooth operation.
6-27
9Lubricate if necessary.
Chassis fasteners9Make sure that all nuts, bolts and screws are properly tightened.
—
9Tighten if necessary.
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 23

5-1
EAU00372
OPERATION AND IMPORTANT RIDING POINTS
1
2
3
4
5
6
7
8
9
EAU00373
w
8Before riding this motorcycle,
become thoroughly familiar
with all operating controls and
their functions. Consult a
Yamaha dealer regarding any
control or function that you do
not thoroughly understand.
8Never start your engine or let
it run for any length of time in
a closed area. The exhaust
fumes are poisonous and can
cause loss of consciousness
and death within a short time.
Always operate your motorcy-
cle in an area with adequate
ventilation.
8Before starting out, always be
sure the sidestand is up.
Failure to retract the sidestand
completely can result in a seri-
ous accident when you try to
turn a corner.
EAU03011Starting the engine
NOTE:
This motorcycle is equipped with
an ignition circuit cut-off system.
The engine can be started only
under one of the following condi-
tions:
8The transmission is in neutral.
8The sidestand is up, the trans-
mission is in gear and the
clutch is disengaged.
The motorcycle must not be ridden
when the sidestand is down.
EW000054
w
Before going through the follow-
ing steps, check the function of the
sidestand switch and clutch
switch. (Refer to page 3-12.)
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 25

6-5
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
*: Since these items require special tools, data and technical skills, they should be serviced by a Yamaha dealer.
EAU02970
NOTE:
8The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
8Hydraulic brake system
8When disassembling the master cylinder or caliper, always replace the brake fluid. Check the brake fluid
level regularly and fill as required.
8Replace the oil seals on the inner parts of the master cylinder and caliper every two years.
8Replace the brake hoses every four years or if cracked or damaged.
Every Every
6,000 km 12,000 km
No. ITEM CHECKS AND MAINTENANCE JOBSINITIAL or or
1,000 km 6 months 12 months
(Whichever (Whichever
comes first) comes first)
21 * Carburetor9Check engine idling speed and starter operation.
ÖÖÖ
9Adjust if necessary.
9Check oil level and vehicle for oil leakage.
22 Engine oil9Correct if necessary.ÖÖÖ
9Change. (Warm engine before draining.)
23Engine oil filter element9Clean or replace if necessary.ÖÖ
24 * Engine oil strainer9Clean or replace if necessary.ÖÖ
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 35

6-9
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
1
Installation
1. Measure the electrode gap
with a wire thickness gauge
and, if necessary, adjust the
gap to specification.
2. Clean the gasket surface. Wipe
off any grime from the
threads.
3. Install the spark plug and tight-
en it to the specified torque.
1. Spark plug gap
NOTE:
If a torque wrench is not available
when you are installing a spark
plug, a good estimate of the cor-
rect torque is 1/4 to 1/2 turn past
finger tight. Have the spark plug
tightened to the specified torque as
soon as possible.
4. Install the spark plug cap.
EAU00517*
Engine oil
Oil level measurement
1. Place the motorcycle on a level
place and hold it in an upright
position. Warm up the engine
for several minutes.
NOTE:
Be sure the motorcycle is posi-
tioned straight up when checking
the oil level. A slight tilt toward the
side can result in false readings.
Spark plug gap:
0.6 ~ 0.7 mm
Tightening torque:
Spark plug:
17.5 Nm (1.75 m·kg)
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 39

6-10
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
92. With the engine stopped,
check the oil level through the
level window located at the
lower part of the right side
crankcase cover.
NOTE:
Wait a few minutes until the oil
level settles before checking.
3. The oil level should be
between the maximum and
minimum marks. If the level is
low, add sufficient oil to raise
it to the proper level.
1. Maximum level mark
2. Minimum level mark
Engine oil replacement
1. Warm up the engine for a few
minutes.
2. Stop the engine. Place an oil
pan under the engine and
remove the oil filler cap.
1. Engine oil filler cap
3. Remove the drain bolts.
1. Engine oil drain bolt
1
1
1
2
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 40

6-11
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
EC000070
cC
When removing the oil drain bolt,
the O-ring, compression spring,
and oil strainer will fall out. Take
care not to lose these parts.
1. Strainer
2. Compression spring
3. O-ring
NOTE:
The oil filter cover is secured by
two screws and a drain bolt.
Remove the drain bolt to drain the
filter cavity.
1. Bolts (´3)
2. Engine oil drain bolt
4. Remove the filter cover screws
and the oil filter cover.
5. Remove the oil filter element
and O-ring.
6. Clean the oil filter and strainer
with solvent. Replace if neces-
sary.
7. Check the O-rings. If damaged,
replace.
8. Install the filter cover, screws
and drain bolts. Tighten the
drain bolts to the specified
tightening torques.
NOTE:
Make sure the O-ring is seated
properly.
1. Oil filter element
2. O-ring
12 3
1 21
2
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 41
