turn signal YAMAHA TW125 2000 Owners Manual

Carburetor adjustment ..................................6-14
Idle speed adjustment ...................................6-14
Throttle cable free play inspection ...............6-15
Valve clearance adjustment ..........................6-15
Tires.................................................................6-16
Wheels ............................................................6-18
Clutch lever free play adjustment .................6-19
Front brake lever free play adjustment ........6-19
Rear brake pedal height and free play
adjustment ......................................................6-20
Brake light switch adjustment.......................6-21
Checking the front brake pads and
rear brake shoes .............................................6-22
Inspecting the brake fluid level .....................6-22
Brake fluid replacement.................................6-23
Drive chain slack check ..................................6-24
Drive chain slack adjustment ........................6-24
Drive chain lubrication...................................6-25
Cable inspection and lubrication ..................6-26
Throttle cable and grip lubrication ...............6-26
Brake and shift pedal lubrication ..................6-27
Brake and clutch lever lubrication ................6-27
Sidestand lubrication .....................................6-27
Rear suspension lubrication..........................6-28
Front fork inspection ......................................6-28
Steering inspection ........................................6-29
Wheel bearings ..............................................6-29Battery .............................................................6-30
Fuse replacement ...........................................6-31
Headlight bulb replacement ..........................6-32
Turn signal and taillight bulb
replacement ....................................................6-33
Supporting the motorcycle ...........................6-34
Front wheel removal ......................................6-35
Front wheel installation .................................6-36
Rear wheel removal .......................................6-36
Rear wheel installation ..................................6-37
Troubleshooting .............................................6-38
Troubleshooting chart ...................................6-39
MOTORCYCLE CARE AND STORAGE ..............7-1
Care ...................................................................7-1
Storage..............................................................7-4
SPECIFICATIONS................................................8-1
How to use the conversion table ....................8-5
CONSUMER INFORMATION .............................9-1
Identification numbers record.........................9-1
Key identification number ...............................9-1
Vehicle identification number .........................9-1
Model label .......................................................9-2
TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9
7
8
9
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 6

3-2
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
EAU01087Speedometer
The speedometer shows riding
speed. This speedometer is
equipped with an odometer and
trip odometer. The trip odometer
can be reset to “0” with the reset
knob. Use the trip odometer to
estimate how far you can ride on a
tank of fuel. This information will
enable you to plan fuel stops in the
future.
1. Reset knob
2. Speedometer
3. Odometer
4. Trip odometer
EAU00118Handlebar switchesEAU00121Dimmer switch
Turn the switch to “&” for the
high beam and to “%” for the low
beam.
1. Lights switch
2. Dimmer switch
3. Turn signal switch
4. Horn switch “*”
NOTE:
(for German model equipped with
speed limiter only)
This motorcycle is equipped with a
speed limiter which prevents it
from exceeding a top speed of 80
km/h.
1
2
3
4
4
1
2
3
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 12

3-3
INSTRUMENT AND CONTROL FUNCTIONS
1
2
3
4
5
6
7
8
9
EAU00127Turn signal switch
To signal a right-hand turn, push
the switch to “6”. To signal a left-
hand turn, push the switch to
“4”. Once the switch is released
it will return to the center position.
To cancel the signal, push the
switch in after it has returned to
the center position.
EAU00129
Horn switch “*”
Press the switch to sound the horn.
EAU00134Lights switch
Turning the light switch to “
'”,
turns on the auxiliary light, meter
lights and taillight. Turning the
light switch to “:” turns the head-
light on also.
EAU00143Start switch “,“
The starter motor cranks the
engine when pushing the start
switch.
EC000005
cC
See starting instructions prior to
starting the engine.
1
2
EAU00138Engine stop switch
The engine stop switch is a safety
device for use in an emergency
such as when the motorcycle over-
turns or if trouble occurs in the
throttle system. Turn the switch to
“#” to start the engine.
In case of emergency, turn the
switch to “$” to stop the engine.
1. Engine stop switch
2. Start switch “,”
5EK-9-E1 (TW125)<3.1> 4/6/0 11:50 PM Page 13

6-33
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9 4. Turn the bulb holder counter-
clockwise to remove it and
then remove the defective
bulb.EW000119
w
Keep flammable products and your
hands away from a bulb while it is
on, as it is hot. Do not touch a bulb
until it cools down.
5. Put a new bulb into position
and secure it in place with the
bulb holder.
1. Bulb holder
6. Install the bulb holder cover,
connector and headlight unit.
7. Install the cowling.
8. If the headlight beam adjust-
ment is necessary, ask a
Yamaha dealer to make that
adjustment.EAU00855Turn signal and taillight bulb
replacement
1. Remove the screws and the
lens.
1. Screw
11
