3-2
INSTRUMENT AND CONTROL FUNCTIONS
3
EAU01087
Speedometer unit
The speedometer unit is equipped
with a speedometer, an odometer
and a tripmeter. The speedometer
shows riding speed. The odometer
shows the total distance traveled.
The tripmeter shows the distance
traveled since it was last set to zero
with the reset knob. The tripmeter
can be used to estimate the distance
that can be traveled with a full tank of
fuel. This information will enable you
to plan future fuel stops.
4
12
3
1. Speedometer
2. Odometer
3. Tripmeter
4. Reset knob
NOTE:
Only for the German model equipped
with a speed limiter:
The speed limiter prevents the motor-
cycle from exceeding a riding speed
of 80 km/h.
EAU00061
Neutral indicator light “N”
This indicator light comes on when
the transmission is in the neutral
position.
312
1. Turn signal indicator light “5”
2. High beam indicator light “&”
3. Neutral indicator light “N”
