fuel filter YAMAHA TW200 2002 Owners Manual

EAU00009
TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9 GIVE SAFETY THE RIGHT OF WAY ..................1-1
DESCRIPTION .....................................................2-1
Left view............................................................2-1
Right view .........................................................2-2
Controls/Instruments .......................................2-3
INSTRUMENT AND CONTROL
FUNCTIONS ........................................................3-1
Main switch/Steering lock ...............................3-1
Indicator lights..................................................3-2
Speedometer ....................................................3-2
Handlebar switches..........................................3-3
Clutch lever .......................................................3-4
Shift pedal.........................................................3-4
Front brake lever ..............................................3-5
Rear brake pedal ..............................................3-5
Fuel tank cap.....................................................3-5
Fuel ....................................................................3-6
Fuel cock ...........................................................3-7
Starter (choke) “1” .........................................3-8
Kick starter ........................................................3-8
Seat ...................................................................3-9
Helmet holder ...................................................3-9
Rear shock absorber ......................................3-10
Rear carrier .....................................................3-10Sidestand ........................................................3-10
Sidestand/clutch switch operation check .....3-11
PRE-OPERATION CHECKS.................................4-1
Pre-operation check list ...................................4-1
OPERATION AND IMPORTANT RIDING
POINTS................................................................5-1
Starting and warming up a cold engine.........5-1
Starting a warm engine ...................................5-4
Shifting..............................................................5-4
Engine break-in ................................................5-5
Parking ..............................................................5-6
PERIODIC MAINTENANCE AND MINOR
REPAIR ................................................................6-1
Tool kit ..............................................................6-1
Periodic maintenance and lubrication............6-3
Cowling and panel removal and
installation ........................................................6-6
Cowling A .........................................................6-6
Panel A ..............................................................6-7
Panel B ..............................................................6-7
Spark plug inspection ......................................6-7
Engine oil ..........................................................6-8
Air filter ...........................................................6-12
1
2
3
4
5
6
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 5

EAU00026
DESCRIPTION
1
2
3
4
5
6
7
8
9
2-1
1. Headlight (page 6-30)
2. Fuel cock (page 3-7)
3. Starter(choke) “1“ (page 3-8)
4. Air filter (page 6-12)
5. Battery (page 6-27)6. Helmet holder (page 3-9)
7. Rear carrier (page 3-10)
8. Shift pedal (page 3-4)
123456 7
8
Left view
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 8

6-3
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
EAU00473
PERIODIC MAINTENANCE AND LUBRICATION
EVERY
6,000 km 12,000 km
No. ITEM CHECKS AND MAINTENANCE JOBSInitial or or
(1,000 km) 6 months 12 months
(Whichever (Whichever
comes first) comes first)
1 * Fuel line 9Check fuel hoses for cracks or damage.
√√
9Replace if necessary.
2 Spark plug9Check condition.
√√√
9Clean, regap or replace if necessary.
3 * Valves9Check valve clearance.
√√√
9Adjust if necessary.
4 * Cam chain9Check chain tension.
√√√
9Adjust if necessary.
5 Air filter9Clean or replace if necessary.√√
9Check electrolyte level and specific gravity.
6 * Battery9Correct or recharge if necessary. √√
9Make sure that the breather hose is properly routed.
7 Clutch9Check operation.
√√√
9Adjust or replace cable.
8 * Front brake9Check operation.
√√√
9Adjust cable and replace brake shoes if necessary.
9 * Rear brake9Check operation.
√√√
9Adjust cable and replace brake shoes if necessary.
10 * Wheels9Check balance, runout, spoke tightness and for damage.
√√
9Tighten spokes and rebalance, replace if necessary.
9Check tread depth and for damage.
11 * Tires9Replace if necessary.
√√
9Check air pressure.
9Correct if necessary.
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 32

8-1
EAU01038
SPECIFICATIONS
1
2
3
4
5
6
7
8
9
Specifications
Model TW200E
Dimensions:
Overall length 2,090 mm
Overall width 815 mm
Overall height 1,115 mm
Seat height 790 mm
Wheel base 1,325 mm
Ground clearance 250 mm
Minimum turning radius 1,900 mm
Basic weight (With oil and full
fuel tank):126 kg
Engine:
Engine type Air-cooled 4-stroke, SOHC,
gasoline
Cylinder arrangement Forward inclined
single cylinder
Displacement 196 cm
3
Bore ×Stroke 67.0 ×55.7 mm
Compression ratio 9.5:1
Starting system Electric and kick starter
Lubrication system Wet sumpEngine oil:
Type:
Classification API Service “SE”, “SF” type
or equivalent
(e.g. “SF-SE”, “SF-SE-CC”,
“SF-SE-SD” etc.)
Capacity:
Periodic oil change 1.0 L
With oil filter replacement 1.1 L
Total amount 1.3 L
Air filter:Wet type element
Fuel:
Type Regular gasoline
Fuel tank capacity 7.0 L
Reserve amount 1.7 L
Carburetor:
Type / quantity Y29P-5C / 1
Manufacturer TEIKEI
–10° 0° 10° 20° 30° 40°
SAE 10W/30
SAE 10W/40
SAE 20W/40
SAE 20W/50C
