oil level YAMAHA TW200 2003 Owners Manual

4-1
EAU01114
PRE-OPERATION CHECKS
1
2
3
4
5
6
7
8
9Owners are personally responsible for their vehicle’s condition. Your motorcycle’s vital functions can start to
deteriorate quickly and unexpectedly, even if it remains unused (for instance, if it is exposed to the elements).
Any damage, fluid leak or loss of tire pressure could have serious consequences. Therefore, it is very important
that, in addition to a thorough visual inspection, you check the following points before each ride.
EAU00340PRE-OPERATION CHECK LIST
ITEM CHECKS PAGE
Brakes9Check operation, condition and free play.
3-5, 6-18 ~ 6-21
9Adjust if necessary.
Clutch9Check operation and free play.
3-4, 6-18
9Adjust if necessary.
9Check for smooth operation.
Throttle grip and housing9Lubricate.6-14, 6-24
9Adjust throttle cable free play if necessary.
Engine oil9Check oil level.
6-8 ~ 6-11
9Fill with oil if necessary.
Drive chain9Check chain slack and condition.
6-21 ~ 6-23
9Adjust if necessary.
Wheels and tires9Check tire pressure, wear, damage and spoke tightness.
6-15 ~ 6-17
9Tighten spokes if necessary.
Brake and shift pedal shafts9Check for smooth operation.
6-24
9Lubricate if necessary.
Brake and clutch lever pivots9Check for smooth operation.
6-25
9Lubricate if necessary.
Sidestand pivot9Check for smooth operation.
6-25
9Lubricate if necessary.
Chassis fasteners9Make sure that all nuts, bolts, and screws are properly tightened.
—
9Tighten if necessary.
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 22

6-5
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
*: Since these items require special tools, data and technical skills, they should be serviced by a Yamaha dealer.EAU00479
NOTE:
The air filter needs more frequent service if you are riding in unusually wet or dusty areas.
EVERY
6,000 km 12,000 km
No. ITEM CHECKS AND MAINTENANCE JOBSInitial or or
(1,000 km) 6 months 12 months
(Whichever (Whichever
comes first) comes first)
9Check oil level and vehicle for oil leakage.
23 Engine oil9Correct if necessary.√√√
9Change. (Warm engine before draining.)
24Engine oil filter element9Clean or replace if necessary.√√
25
*
Engine oil strainer9Clean or replace if necessary.√√
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 34

6-8
PERIODIC MAINTENANCE AND MINOR REPAIR
6 break down and erode. If electrode
erosion becomes excessive, or if
carbon and other deposits are
excessive, you should replace the
spark plug with the specified plug.
Before installing the spark plug,
measure the electrode gap with a
wire thickness gauge; adjust the
gap to specification as necessary.
When installing the plug, always
clean the gasket surface and use a
new gasket. Wipe off any grime
from the threads and tighten the
spark plug to the specified torque.Specified spark plug:
DR8EA (NGK) or
X24ESR-U (DENSO)Spark plug gap:
0.6 ~ 0.7 mm
Tightening torque:
Spark plug:
17.5 Nm (1.75 m0kg)
NOTE:
If a torque wrench is not available
when you are installing a spark
plug, a good estimate of the cor-
rect torque is 1/4 to 1/2 turn past
finger tight. Have the spark plug
tightened to the specified torque as
soon as possible.EAU00517Engine oil
1. Oil level measurement
a. Place the motorcycle on a level
place and hold it in an upright
position. Warm up the engine
for several minutes.
NOTE:
Be sure the motorcycle is posi-
tioned straight up when checking
the oil level. A slight tilt toward the
side can result in false readings.
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 37

6-9
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
1
2. Engine oil replacement
a. Warm up the engine for a few
minutes.
b. Stop the engine. Place an oil
pan under the engine and
remove the oil filler cap.
1. Oil filler cap
2
3 1
b. With the engine stopped,
check the oil level through the
level window located at the
lower part of the right side
crankcase cover.
NOTE:
Wait a few minutes until the oil
level settles before checking.
c. The oil level should be
between the maximum and
minimum marks. If the level is
low, add sufficient oil to raise
it to the proper level.
1. Level window
2. Maximum level mark
3. Minimum level mark
1
c. Remove the drain plug and
drain bolt.
1. Drain plug
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 38

6-26
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
EAU00793Front fork inspection
EW000115
w
Securely support the motorcycle
so there is no danger of it falling
over.
1. Visual check
Check for scratches or damage
on the inner tube and exces-
sive oil leakage from the front
fork.2. Operation check
Place the motorcycle on a level
place.
a. Hold the motorcycle in an
upright position and apply the
front brake.
b. Push down hard on the han-
dlebars several times and
check if the fork rebounds
smoothly.
EC000098
cC
If any damage or unsmooth move-
ment is found with the front fork,
consult a Yamaha dealer.
EAU00794Steering inspection
Periodically inspect the condition
of the steering. Worn out or loose
steering bearings may be danger-
ous. Place a stand under the
engine to raise the front wheel off
the ground. Hold the lower end of
the front forks and try to move
them forward and backward. If any
free play can be felt, ask a Yamaha
dealer to inspect and adjust the
steering. Inspection is easier if the
front wheel is removed.
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 55

6-28
PERIODIC MAINTENANCE AND MINOR REPAIR
1
2
3
4
5
6
7
8
9
EW000116
w
Battery electrolyte is poisonous
and dangerous, causing severe
burns, etc. It contains sulfuric acid.
Avoid contact with skin, eyes or
clothing.
Antidote:
EXTERNAL: Flush with water.
INTERNAL: Drink large quantities
of water or milk. Follow with milk
of magnesia, beaten egg, or veg-
etable oil. Call a physician immedi-
ately.
EYES: Flush with water for 15 min-
utes and get prompt medical
attention. Batteries produce explo-
sive gases. Keep sparks, flame, cig-
arettes etc., away. Ventilate when
charging or using in an enclosed
space. Always shield your eyes
when working near batteries.
KEEP OUT OF REACH OF CHIL-
DREN.
EW000117
w
Take care not to spill battery fluid
on the chain.
Battery fluid may weaken the
chain causing shorter chain life
and possibly result in an accident
Battery storage
1. When the motorcycle will not
be used for a month or longer,
remove the battery, fully
charge it and store it in a cool,
dry place. Completely recharge
the battery before reinstalla-
tion.
2. If the battery will be stored for
longer than two months, check
the specific gravity of the fluid
at least once a month and fully
recharge the battery when it is
too low. Replenishing the battery fluid
A poorly maintained battery will
corrode and discharge quickly. The
battery fluid should be checked at
least once a month. The level
should be between the minimum
level and maximum level marks.
Use only distilled water if refilling
is necessary.
EC000100
cC
Normal tap water contains miner-
als which are harmful to a battery;
therefore, refill only with distilled
water.
1
2
1. Maximum level mark
2. Minimum level mark
5FY-9-E0 (TW200) 7/29/02 10:54 AM Page 57
