MOTORCYCLE CARE AND STORAGE
7-2
1
2
3
4
5
6
7
8
9any marks. If the windshield is
scratched, use a quality plastic
polishing compound after

washing.
After normal use
Remove dirt with warm water, a mild
detergent, and a soft, clean sponge,
and then rinse thoroughly with clean
water. Use a toothbrush or bottlebrush
for hard-to-reach areas. Stubborn dirt
and insects will come off more easily if
the area is covered with a wet cloth for
a few minutes before cleaning.
After riding in the rain, near the sea oron salt-sprayed roadsSince sea salt or salt sprayed on roads
during winter are extremely corrosive in
combination with water, carry out the
following steps after each ride in the
rain, near the sea or on salt-sprayed
roads.NOTE:

Salt sprayed on roads in the winter may
remain well into spring.
1. Clean the motorcycle with cold wa-ter and a mild detergent, after the
engine has cooled down.
CAUTION:

ECA10790
Do not use warm water since it in-
creases the corrosive action of the
salt.
2. Apply a corrosion protection spray
on all metal, including chrome- and
nickel-plated, surfaces to prevent
corrosion.
After cleaning
1. Dry the motorcycle with a chamois
or an absorbing cloth.
2. Immediately dry the drive chain
and lubricate it to prevent it from
rusting.
3. Use a chrome polish to shine
chrome, aluminum and stain-
less-steel parts, including the ex-
haust system. (Even the thermally
induced discoloring of stain-
less-steel exhaust systems can be
removed through polishing.)
4. To prevent corrosion, it is recom-
mended to apply a corrosion pro-tection spray on all metal,
including chrome- and nickel-plat-
ed, surfaces.
5. Use spray oil as a universal clean-
er to remove any remaining dirt.
6. Touch up minor paint damage
caused by stones, etc.
7. Wax all painted surfaces.
8. Let the motorcycle dry completely
before storing or covering it.
WARNING

EWA10930

Make sure that there is no oil or
wax on the brakes or tires. If
necessary, clean the brake
discs and brake linings with a
regular brake disc cleaner or ac-
etone, and wash the tires with
warm water and a mild deter-
gent.

Before operating the motorcy-
cle test its braking performance
and cornering behavior.
CAUTION:

ECA10800

Apply spray oil and wax spar-

MOTORCYCLE CARE AND STORAGE
7-3
2
3
4
5
6
78
9 ingly and make sure to wipe off
any excess.


Never apply oil or wax to any
rubber and plastic parts, but
treat them with a suitable care
product.

Avoid using abrasive polishing
compounds as they will wear
away the paint.
NOTE:

Consult a Yamaha dealer for advice on
what products to use.
EAU26150
Storage
Short-term
Always store your motorcycle in a cool,
dry place and, if necessary, protect it
against dust with a porous cover.
CAUTION:

ECA10810

Storing the motorcycle in a
poorly ventilated room or cover-
ing it with a tarp, while it is still
wet, will allow water and humid-
ity to seep in and cause rust.

To prevent corrosion, avoid
damp cellars, stables (because
of the presence of ammonia)
and areas where strong chemi-
cals are stored.
Long-term
Before storing your motorcycle for sev-
eral months:
1. Follow all the instructions in the
“Care” section of this chapter.
2. For motorcycles equipped with a
fuel cock that has an “OFF” posi-
tion: Turn the fuel cock lever to
“OFF”.3. Drain the carburetor float chamber
by loosening the drain bolt; this will
prevent fuel deposits from building
up. Pour the drained fuel into the
fuel tank.
4. Fill up the fuel tank and add fuel
stabilizer (if available) to prevent
the fuel tank from rusting and the
fuel from deteriorating.
5. Perform the following steps to pro-
tect the cylinder, piston rings, etc.
from corrosion.
a. Remove the spark plug cap
and spark plug.
b. Pour a teaspoonful of engine oil
into the spark plug bore.
c. Install the spark plug cap onto
the spark plug, and then place
the spark plug on the cylinder
head so that the electrodes are
grounded. (This will limit spark-
ing during the next step.)
d. Turn the engine over several
times with the starter. (This will
coat the cylinder wall with oil.)
e. Remove the spark plug cap

MOTORCYCLE CARE AND STORAGE
7-4
1
2
3
4
5
6
7
8
9
from the spark plug, and then
install the spark plug and the
spark plug cap.
WARNING

EWA10950
To prevent damage or injury from
sparking, make sure to ground the
spark plug electrodes while turning
the engine over.
6. Lubricate all control cables and the
pivoting points of all levers and
pedals as well as of the sidestand/
centerstand.
7. Check and, if necessary, correct
the tire air pressure, and then lift
the motorcycle so that both of its
wheels are off the ground. Alterna-
tively, turn the wheels a little every
month in order to prevent the tires
from becoming degraded in one
spot.
8. Cover the muffler outlet with a
plastic bag to prevent moisture
from entering it.
9. Remove the battery and fully
charge it. Store it in a cool, dryplace and charge it once a month.
Do not store the battery in an ex-
cessively cold or warm place
(less than 0 °C [30 °F]) or more
than 30 °C [90 °F]). For more in-
formation on storing the battery,
see page 6-27.
NOTE:

Make any necessary repairs before
storing the motorcycle.

SPECIFICATIONS
8-1
2
3
4
5
6
7
89

EAU26332
Dimensions:
Overall length:
2090 mm (82.3 in)
Overall width:
820 mm (32.3 in)
Overall height:
1120 mm (44.1 in)
Seat height:
790 mm (31.1 in)
Wheelbase:
1325 mm (52.2 in)
Ground clearance:
265 mm (10.43 in)
Minimum turning radius:
1900 mm (74.8 in)
Weight:
With oil and fuel:
126.0 kg (278 lb)
Engine:
Engine type:
Air cooled 4-stroke, SOHC
Cylinder arrangement:
Forward inclined single cylinder
Displacement:
196.0 cm
3

(11.96 cu.in)
Bore
×
stroke:
67.0
×
55.7 mm (2.64
×
2.19 in)
Compression ratio:
9.50 :1
Starting system:
Electric and kick starter
Lubrication system:
Wet sump

Engine oil:
Type:
YAMALUBE 4, SAE10W30 or SAE20W40
Recommended engine oil grade:
API service SE, SF, SG type or higher
Engine oil quantity:
Without oil filter element removal:
1.00 L (1.06 US qt) (0.88 Imp.qt)
With oil filter element removal:
1.10 L (1.16 US qt) (0.97 Imp.qt)
Air filter:
Air filter element:
Wet element
Fuel:
Recommended fuel:
Regular unleaded gasoline only
Fuel tank capacity:
7.0 L (1.85 US gal) (1.54 Imp.gal)
Fuel reserve amount:
1.7 L (0.45 US gal) (0.37 Imp.gal)
Carburetor:
Manufacturer:
TEIKEI
Type x quantity:
MV28 x 1
Spark plug(s):
Manufacturer/model:
NGK/DR8EA
Manufacturer/model:
DENSO/X24ESR-U
Spark plug gap:
0.6–0.7 mm (0.024–0.028 in)
Clutch:
Clutch type:
Wet, multiple-disc
Transmission:
Primary reduction system:
Spur gear
Primary reduction ratio:
73/22 (3.318)
Secondary reduction system:
Chain drive
Secondary reduction ratio:
50/14 (3.571)
Transmission type:
Constant mesh 5-speed
Operation:
Left foot operation
Gear ratio:
1st:
34/12 (2.833)
2nd:
34/19 (1.789)
-20 -10 0
10 20 30
40
50 ˚C
SAE 10W-30
SAE 15W-40SAE 20W-40SAE 20W-50
SAE 10W-40

SPECIFICATIONS
8-2
1
2
3
4
5
6
7
8
9

3rd:
29/22 (1.318)
4th:
26/25 (1.040)
5th:
23/28 (0.821)
Chassis:
Frame type:
Diamond
Caster angle:
26.0 °
Trail:
95.0 mm (3.74 in)
Front tire:
Type:
With tube
Size:
130/80-18M/C 66P
Manufacturer/model:
BRIDGESTONE/TW31
Rear tire:
Type:
With tube
Size:
180/80-14M/C 78P
Manufacturer/model:
BRIDGESTONE/TW34
Loading:
Maximum load:
180 kg (397 lb)
(Total weight of rider, passenger, cargo
and accessories)
Tire air pressure (measured on cold
tires):
Loading condition:
0–90 kg (0–198 lb)
Front:
125 kPa (18 psi) (1.25 kgf/cm
2

)
Rear:
125 kPa (18 psi) (1.25 kgf/cm
2

)
Loading condition:
90–180 kg (198–397 lb)
Front:
150 kPa (22 psi) (1.50 kgf/cm
2

)
Rear:
175 kPa (25 psi) (1.75 kgf/cm
2

)
Off-road riding:
Front:
125 kPa (18 psi) (1.25 kgf/cm
2

)
Rear:
125 kPa (18 psi) (1.25 kgf/cm
2

)
Front wheel:
Wheel type:
Spoke wheel
Rim size:
18x2.50
Rear wheel:
Wheel type:
Spoke wheel
Rim size:
14M/C x MT4.50
Front brake:
Type:
Single disc brake Operation:
Right hand operation
Recommended fluid:
Dot 4
Rear brake:
Type:
Drum brake
Operation:
Right foot operation
Front suspension:
Type:
Telescopic fork
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
160.0 mm (6.30 in)
Rear suspension:
Type:
Swingarm (monocross)
Spring/shock absorber type:
Coil spring/gas-oil damper
Wheel travel:
150.0 mm (5.91 in)
Electrical system:
Ignition system:
C.D.I.
Charging system:
A.C. magneto
Battery:
Model:
GM7CZ-3D
Voltage, capacity:
12 V, 7.0 Ah

SPECIFICATIONS
8-3
2
3
4
5
6
7
89 Headlight:

Bulb type:
Halogen bulb
Bulb voltage, wattage x quantity:
Headlight:
12 V, 60 W/55.0 W
×
1
Tail/brake light:
12 V, 8 W/27.0 W
×
1
Front turn signal/position light:
12 V, 27 W/8.0 W
×
2
Rear turn signal light:
12 V, 27.0 W
×
2
Meter lighting:
12 V, 3.4 W
×
1
Neutral indicator light:
12 V, 3.4 W
×
1
High beam indicator light:
12 V, 3.4 W
×
1
Turn signal indicator light:
12 V, 3.4 W
×
1

Fuse:
Fuse:
20.0 A

CONSUMER INFORMATION
9-1
1
2
3
4
5
6
7
8
9

EAU26351
Identification numbers
Record the key identification number,
vehicle identification number and mod-
el label information in the spaces pro-
vided below for assistance when
ordering spare parts from a Yamaha
dealer or for reference in case the vehi-
cle is stolen.
KEY IDENTIFICATION NUMBER:
VEHICLE IDENTIFICATION NUM-
BER:
MODEL LABEL INFORMATION:
EAU26390
Key identification number
The key identification number is
stamped into the key. Record this num-
ber in the space provided and use it for
reference when ordering a new key.
EAU26400
Vehicle identification number
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.
NOTE:

The vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in your
area.
1. Key identification number
1

1. Vehicle identification number
1

CONSUMER INFORMATION
9-2
2
3
4
5
6
7
8
9

EAU26460
Model label
The model label is affixed to the loca-
tion shown. Record the information on
this label in the space provided. This in-
formation will be needed when ordering
spare parts from a Yamaha dealer.
1. Model label
1

5FY-28199-E1
TW200E
PRINTED ON RECYCLED PAPER
YAMAHA MOTOR CO., LTD.
PRINTED IN JAPAN
2003.6–0.1×1 !
(E)
OWNER’S MANUAL
5FY-9-E1_hyoushi 6/4/03 9:28 AM Page 1
