length YAMAHA VIKING 2017 Owners Manual

7-6
7
To wear the seat belt properly, do the follow-
ing:1. Hold the latch plate as you pull the belt across your lap and chest. Make sure the
belt is not twisted and is not caught on
any portion of the vehicle, your clothing,
or any equipment you are carrying.
2. If the latch plate is not positioned in the
correct location along the seat belt,
squeeze the latch plate ends together
along its long edges in order to more eas-
ily adjust its location up or down along
the length of the belt. 3. Push the latch plate into the buckle until it
clicks. Pull up on the latch plate to make
sure it is secure.
4. Put the lap portion of the belt low on your hips. Pull up on the shoulder part so the
belt is snug across your hips. Be sure the
seat belt is not caught on the shoulder
bolster or other object.
1. Buckle
2. Latch plate
3. Release button
1
3
2
UB427BE0.book Page 6 Friday, February 5, 2016 2:14 PM

10-1
10
EBU32750
SPECIFICATIONS
Dimensions:Overall length:3100 mm (122.0 in)
Overall width: 1570 mm (61.8 in) (YXM70VPHH, YXM70VPXH)
1625 mm (64.0 in) (YXM70VPSH)
Overall height: 1925 mm (75.8 in)
Wheelbase:
2135 mm (84.1 in)
Ground clearance: 300 mm (11.8 in)
Minimum turning radius: 4500 mm (177 in)Weight:Curb weight:649.0 kg (1431 lb) (YXM70VPHH, YXM70VPXH)
654.0 kg (1442 lb) (YXM70VPSH)Noise and vibration level:Noise level (77/311/EEC):83.0 dB(A) (YXM70VPXH_EUR/FRA/GBR)
Uncertainty of measurement:
3.0 dB(A) (YXM70VPXH_EUR/FRA/GBR)
A-weighted sound power level: 93.0 dB(A) (YXM70VPXH_EUR/FRA/GBR)
Uncertainty of measurement: 3.0 dB(A) (YXM70VPXH_EUR/FRA/GBR) Vibration on seat (EN1032, ISO5008):
Will not exceed 0.5 m/s² (YXM70VPXH_EUR/FRA/GBR)
Uncertainty of measurement: 0.0 m/s² (YXM70VPXH_EUR/FRA/GBR)
Vibration on handle (EN1032, ISO5008): Will not exceed 2.5 m/s² (YXM70VPXH_EUR/FRA/GBR)
Uncertainty of measurement:
0.2 m/s² (YXM70VPXH_EUR/FRA/GBR)
Engine:Engine type:Liquid cooled 4-stroke, SOHC
Cylinder arrangement:
Single cylinder
Displacement: 686 cm³
Bore × stroke:
102.0 × 84.0 mm (4.02 × 3.31 in)
Compression ratio:
10.0 : 1
Starting system: Electric starter
Lubrication system: Wet sumpEngine oil:Recommended brand:YAMALUBE
UB427BE0.book Page 1 Friday, February 5, 2016 2:14 PM

10-5
10
Tail/brake light:12 V, 5.0/21.0 W × 2
Neutral indicator light: LED
Reverse indicator light:
LED
Coolant temperature warning light: LED
Engine trouble warning light: LED
Park indicator light:
LED
High-range indicator light: LED
Low-range indicator light: LED
Differential gear lock indicator light:
LED
EPS warning light: LED
Helmet/Seat belt indicator light: 14 V, 0.85 W × 2Fuses:Main fuse:
40.0 A
Fuel injection system fuse: 10.0 A
EPS fuse:
40.0 A
Headlight fuse: 15.0 A Signaling system fuse:
10.0 A
Ignition fuse: 10.0 A
Auxiliary DC jack fuse:
10.0 A
Backup fuse: 10.0 A
Four-wheel-drive motor fuse: 10.0 A
Radiator fan motor fuse:
25.0 A
EBU33221For Europe only
The figures quoted are emission levels and
are not necessarily safe working levels. Whilst
there is a correlation between the emission
and exposure levels, this cannot be used reli-
ably to determine whether or not further pre-
cautions are required. Factors that influence
the actual level of exposure of work-force in-
clude the characteristics of the work room,
the other sources of noise, etc. i.e. the num-
ber of machines and other adjacent process-
es, and the length of time for which an
