YAMAHA VX 2013 Owners Manual

Trouble recovery
85
(2) Remove any weeds or debris from
around the jet intake, drive shaft, impel-
ler, jet pump housing, and jet thrust noz-
zle.
If debris is difficult to remove, consult a
Yamaha dealer.
EJU34641Jumping the battery
If the watercraft battery has run down, the en-
gine can be started using a 12-volt booster
battery and jumper cables.
EJU34663Connecting the jumper cables
WARNING
EWJ01250
To avoid battery explosion and serious
damage to the electrical system:
●Do not reverse the polarity of the jumper
cables when connecting to the batteries.
●Do not connect the negative (–) jumper
cable to the negative (–) terminal of the
watercraft battery.
●Do not touch the positive (+) jumper ca-
ble to the negative (–) jumper cable.
(1) Connect the positive (+) jumper cable to
the positive (+) battery terminals of both
batteries.
(2) Connect one end of the negative (–)
jumper cable to the negative (–) battery
terminal of the booster battery.(3) Connect the other end of the negative (–)
jumper cable to an engine hanger.
(4) Start the engine, and then disconnect the
jumper cables by reversing the steps
above. (See page 27 for information on
starting the engine.)
EJU34695Replacing the fuses
If a fuse is blown, replace it with the proper
fuse.
To replace a fuse:
(1) Remove the seat. (See page 38 for seat
removal and installation procedures.)
1Negative (–) jumper cable
2Booster battery
3Positive (+) jumper cable
4Engine hanger
1Good fuse
2Blown fuse
1
43
2
2 1
UF2P70E0.book Page 85 Tuesday, July 31, 2012 1:48 PM

Trouble recovery
86
(2) Loosen the cap on the electrical box and
remove it.
(3) Replace the blown fuse with the spare
fuse of the correct amperage by using the
fuse puller on the reverse side of the cap.
WARNING! Do not use fuses of a dif-
ferent amperage than recommended.
Substitution with a fuse that has an
improper rating can cause extensiveelectrical system damage and possi-
ble fire.
[EWJ00802]
(4) Securely install the cap by tightening it
until it stops.
(5) Securely install the seat in its original po-
sition.
1Electrical box
2Cap
1
2
1Spare fuse
2Fuse
3Cap
1Fuse puller
Fuse amperage:
Battery fuse:
30 A
Main relay drive fuse:
10 A
Electronic throttle valve fuse:
10 A
Security system fuse:
VX Deluxe 3 A
VX Cruiser 3 A
Main fuse:
20 A
1
32
UF2P70E0.book Page 86 Tuesday, July 31, 2012 1:48 PM

Trouble recovery
87
If the fuse immediately blows again, the elec-
trical system may be defective. If this occurs,
have a Yamaha dealer service the watercraft.
EJU34715Towing the watercraft
WARNING
EWJ00811
●The operator of the towing boat must
keep speed to a minimum and avoid traf-
fic or obstacles which could be a hazard
to the operator on the watercraft.
●The towline should be long enough so
that the watercraft will not collide with
the towing boat when slowing down.
If the watercraft becomes inoperative in the
water, it can be towed to shore.
To tow the watercraft:
Use a towline that is three times the combined
length of the towing boat and the watercraft.
(1) Securely attach the towline to the bow
eye of the watercraft being towed.
(2) Sit astride the seat and hold on to the
handlebars in order to balance the water-
craft. NOTICE: The bow must be kept
up out of the water during towing, oth-
erwise water could flood the engine
compartment or water could flow back
into the engine, causing severe en-
gine damage.
[ECJ01330]
Tow the watercraft at 8 km/h (5 mph) or less.
NOTICE: Tow the watercraft at 8 km/h (5
mph) or less, otherwise water could flood
the engine compartment or water could
flow back into the engine, causing severe
engine damage.
[ECJ01321]
EJU36155
Submerged watercraft
If the watercraft is submerged or flooded with
water, drain the bilge water from the engine
compartment. Then, have a Yamaha dealer
service the watercraft as soon as possible.
If the watercraft was submerged:
(1) Remove the watercraft from the water
and drain the water from the storage
compartments. (See page 40 for informa-
tion on draining the storage compart-
ments.)
(2) Drain the bilge water from the engine
compartment. (See page 47 for informa-
tion on draining the bilge water.)
(3) Have the watercraft serviced by a
Yamaha dealer as soon as possible.
NOTICE: Be sure to have a Yamaha
dealer inspect the watercraft. Other-
wise, serious engine damage could re-
sult.
[ECJ00791]
1Bow eye
1
UF2P70E0.book Page 87 Tuesday, July 31, 2012 1:48 PM

Index
A
After removing the watercraft from the
water ..................................................... 70
B
Battery care .............................................. 72
Battery checks.......................................... 53
Battery, jumping ....................................... 85
Beaching and docking the watercraft ....... 69
Beverage holder ....................................... 42
Bilge water check ..................................... 53
Bilge water, draining................................. 47
Bilge water, draining on land .................... 47
Bilge water, draining on water .................. 47
Boarding alone ......................................... 65
Boarding and starting off from a dock ...... 68
Boarding the watercraft ............................ 64
Boarding with passenger(s) ..................... 65
Bow eye ................................................... 39
Bow storage compartment ....................... 40
Builder’s plate............................................. 2
C
Capsized watercraft ................................. 68
Check engine warning.............................. 37
Cleaning ................................................... 75
Cleaning the watercraft ............................ 72
Cleat ......................................................... 40
Cooling water pilot outlet .......................... 29
Cooling water pilot outlet check ............... 58
Craft Identification Number (CIN) ............... 1
Cruising limitations ................................... 11
E
Emergency procedures ............................ 84
Engine break-in ........................................ 49
Engine compartment check...................... 52
Engine idling speed check ....................... 58
Engine oil ................................................. 45
Engine oil and oil filter .............................. 79
Engine oil level check............................... 52
Engine oil requirements ........................... 45
Engine overheat warning ......................... 36
Engine serial number ................................. 1
Engine shut-off cord (lanyard) check ....... 55
Engine shut-off switch .............................. 27
Engine stop switch ................................... 27
Engine unit check ..................................... 52Enjoy your watercraft responsibly ............ 19
Equipment ................................................ 38
F
Fire extinguisher check ............................ 57
Fire extinguisher holder and cover ........... 42
Fire extinguisher holder, cover,
and band checks................................... 56
Flushing the cooling water passages ....... 71
Fuel .......................................................... 44
Fuel level check ....................................... 52
Fuel level meter ........................................ 35
Fuel level warning .................................... 35
Fuel requirements .................................... 44
Fuel system checks .................................. 52
Fuses, replacing ....................................... 85
G
Getting to know your watercraft ............... 59
Glossary, watercraft ................................. 20
Glove compartment .................................. 41
H
Handgrip ................................................... 39
Hazard information ................................... 15
Hood check .............................................. 58
Hour meter/voltmeter ............................... 34
Hull and deck check ................................. 57
I
Identification numbers ................................ 1
Information display ................................... 33
J
Jet intake and impeller, cleaning .............. 84
Jet intake checks ...................................... 57
Jumper cables, connecting ...................... 85
L
Labels, important ........................................ 4
Labels, other .............................................. 8
Labels, warning .......................................... 5
Launching the watercraft .......................... 60
Learning to operate your watercraft ......... 59
Leaving the watercraft .............................. 61
Limitations on who may operate the
watercraft .............................................. 10
Long-term storage .................................... 75
Low RPM Mode
(VX Deluxe / VX Cruiser) ...................... 31
Lubrication................................................ 75
UF2P70E0.book Page 1 Tuesday, July 31, 2012 1:48 PM

Index
M
Main components, location of .................. 21
Maintenance............................................. 77
Manufactured date label............................. 2
Model information....................................... 2
Multifunction information center ............... 33
Multifunction information center check ..... 58
O
Oil pressure warning ................................ 36
Operating in weeded areas ...................... 70
Operating the watercraft........................... 61
Operating the watercraft in reverse
(VX Deluxe / VX Cruiser) ...................... 64
Operating your watercraft......................... 59
Operation requirements ........................... 12
P
Periodic maintenance chart...................... 78
Post-launch checks .................................. 58
Post-operation care .................................. 71
Pre-launch checks.................................... 52
Pre-operation check points ...................... 52
Pre-operation checklist............................. 50
Primary Identification (PRI-ID) number ...... 1
R
Reboarding step
(VX Deluxe / VX Cruiser) ...................... 39
Recommended equipment ....................... 14
Remote control transmitter check
(VX Deluxe / VX Cruiser) ...................... 55
Remote control transmitter
(VX Deluxe / VX Cruiser) ...................... 25
Reverse system checks
(VX Deluxe / VX Cruiser) ...................... 54
Reverse system
(VX Deluxe / VX Cruiser) ...................... 30
Riding position.......................................... 60
Rustproofing ............................................. 76
S
Safe boating rules .................................... 18
Safety equipment check ........................... 57
Seat .......................................................... 38
Speedometer............................................ 33
Start switch............................................... 27
Starting off ................................................ 67
Starting off from a trailer........................... 68Starting the engine on water .................... 60
Steering system ....................................... 28
Steering system checks ........................... 53
Stern drain plug checks ............................ 57
Stern eyes ................................................ 40
Stopping the engine ................................. 61
Stopping the watercraft ............................ 63
Storage compartment checks .................. 56
Storage compartments ............................. 40
Submerged watercraft .............................. 87
Switch checks .......................................... 56
T
Tachometer .............................................. 34
Throttle lever ............................................ 28
Throttle lever checks ................................ 55
Tool kit...................................................... 77
Towing the watercraft ............................... 87
Transporting on a trailer ........................... 48
Troubleshooting ....................................... 81
Troubleshooting chart .............................. 81
Turning the watercraft .............................. 62
W
Water separator ....................................... 29
Water separator check ............................. 52
Watercraft characteristics ......................... 15
Watercraft control functions ..................... 25
Watercraft operation functions ................. 30
Watercraft operation modes ..................... 31
Water-skiing ............................................. 17
Y
Yamaha Security System settings ........... 26
Yamaha Security System
(VX Deluxe / VX Cruiser) ...................... 26
UF2P70E0.book Page 2 Tuesday, July 31, 2012 1:48 PM

Printed in U.S.A.
August 2012–0.5 × 1 CR
UF2P70E0.book Page 1 Tuesday, July 31, 2012 1:48 PM
