stop start YAMAHA VX CRUISER 2017 Owner's Manual

Care and storage
84
wise, the fuel hose that is secured to
the air filter case cover could be dam-
aged.
[ECJ02620]
(3) Spray a rust inhibitor into the intake
opening for 3 seconds. WARNING! Do
not spray flammable rust inhibitor
products on engine surfaces while the
engine is hot. The sprayed substance
or propellants could catch fire.
[EWJ00262]
(4) Place the air filter case cover in its origi-
nal position, and then fit the hooks onto
the cover.
TIP:
Make sure that the air filter case cover is se-
curely installed.
(5) Make sure that the area around the wa-
tercraft is clear, and then start the engine
in a well-ventilated area and let it run atidle for 15 seconds. (See page 27 for in-
formation on starting the engine.)
(6) Stop the engine.
(7) Securely install the seats in their original
positions.
1Hook
2Air filter case cover
1Intake opening
2
1
1
UF4G71E0.book Page 84 Wednesday, July 27, 2016 9:32 AM

Trouble recovery
94
(2) Remove any weeds or debris from
around the jet intake, drive shaft, impel-
ler, jet pump housing, and jet thrust noz-
zle.
If debris is difficult to remove, consult a
Yamaha dealer.
EJU43472Raising the reverse gate
If the RiDE system malfunctions and the re-
verse gate remains in the lowered position,
the watercraft will not be able to move for-
ward.
After raising the reverse gate so that the wa-
tercraft can move forward, immediately re-
turn to shore and have a Yamaha dealer
service the watercraft.
To raise the reverse gate:
(1) Stop the engine and remove the clip from
the engine shut-off switch.
(2) Enter the water and move to the rear of
the watercraft.
(3) Slide the shift rod joint toward the bow,
and then disconnect the shift rod joint
from the ball joint.(4) Raise the reverse gate to the forward po-
sition.
TIP:
While the shift rod is disconnected, the re-
verse gate will not move to the neutral po-
sition or reverse position even if the RiDE
lever is squeezed.
If the RiDE lever is squeezed while the shift
rod is disconnected, the watercraft will
move forward.
EJU34642Jumping the battery
If the watercraft battery has run down, the en-
gine can be started using a 12-volt booster
battery and jumper cables.
EJU34664Connecting the jumper cables
WARNING
EWJ01251
To avoid battery explosion and serious
damage to the electrical system:
Do not reverse the polarity of the jumper
cables when connecting to the batter-
ies.
Do not connect the negative (–) jumper
cable to the negative (–) terminal of the
watercraft battery.
Do not touch the positive (+) jumper ca-
ble to the negative (–) jumper cable.
1Shift rod joint
2Ball joint
12
1Reverse gate
2Forward position
1
2
UF4G71E0.book Page 94 Wednesday, July 27, 2016 9:32 AM

97
Index
A
After removing the watercraft from the
water ..................................................... 78
B
Battery care.............................................. 80
Battery checks ......................................... 60
Battery, jumping ....................................... 94
Beaching and docking the watercraft ...... 77
Bilge water check..................................... 60
Bilge water, draining ................................ 54
Bilge water, draining on land ................... 54
Bilge water, draining on water ................. 54
Boarding alone ......................................... 73
Boarding and starting off from a dock ..... 76
Boarding the watercraft ........................... 73
Boarding with passenger(s) ..................... 74
Bow eye ................................................... 45
Bow storage compartment ...................... 46
Builder’s plate ............................................ 2
C
Capsized watercraft ................................. 76
Check engine warning ............................. 41
Cleaning ................................................... 83
Cleaning the watercraft ............................ 80
Cleat ......................................................... 45
Cooling water pilot outlet ......................... 29
Cooling water pilot outlet check .............. 65
Craft Identification Number (CIN)............... 1
Cruise assist
(VX Deluxe / VX Cruiser / VX Limited) ... 36
Cruising limitations................................... 11
E
Emergency procedures ............................ 93
Engine break-in ........................................ 56
Engine compartment check ..................... 59
Engine idling speed check ....................... 66
Engine oil ................................................. 52
Engine oil and oil filter .............................. 88
Engine oil level check............................... 60
Engine oil requirements ........................... 52
Engine overheat warning ......................... 41
Engine serial number ................................. 1
Engine shut-off cord (lanyard) check ....... 62
Engine shut-off switch ............................. 27
Engine stop switch................................... 27Engine unit check ..................................... 60
Enjoy your watercraft responsibly ............ 19
Equipment ................................................ 43
F
Fire extinguisher check ............................ 64
Fire extinguisher holder and cover........... 48
Fire extinguisher holder, cover, and
band checks ......................................... 63
Flushing the cooling water passages....... 79
Fuel .......................................................... 50
Fuel level check........................................ 59
Fuel level meter ........................................ 40
Fuel level warning..................................... 40
Fuel requirements .................................... 50
Fuel system checks ................................. 59
G
Getting to know your watercraft .............. 67
Glossary, watercraft ................................. 20
Glove compartment ................................. 47
H
Handgrip .................................................. 44
Hazard information................................... 15
Hood check .............................................. 65
Hour meter ............................................... 42
Hull and deck check ................................ 64
I
Identification numbers ............................... 1
Information display................................... 38
J
Jet intake and impeller, cleaning.............. 93
Jet intake checks ..................................... 64
Jet thrust nozzle and reverse gate
check .................................................... 64
Jumper cables, connecting ...................... 94
L
Labels, important ....................................... 4
Labels, other .............................................. 8
Labels, warning .......................................... 5
Launching the watercraft ......................... 68
Learning to operate your watercraft......... 67
Leaving the watercraft.............................. 69
Limitations on who may operate the
watercraft .............................................. 10
Long-term storage ................................... 83
UF4G71E0.book Page 97 Wednesday, July 27, 2016 9:32 AM

Index
98
Low RPM Mode
(VX Deluxe / VX Cruiser / VX Limited) ... 33
Lubrication ............................................... 83
M
Main components, location of ................. 21
Maintenance ............................................ 85
Manufactured date label ............................ 2
Model information ...................................... 2
Multifunction information center .............. 38
Multifunction information center check ... 65
N
No-wake mode
(VX Deluxe / VX Cruiser / VX Limited) ... 34
O
Oil pressure warning ................................ 41
Operating in weeded areas ...................... 77
Operating the watercraft .......................... 69
Operating the watercraft in reverse or
neutral ................................................... 72
Operating your watercraft ........................ 67
Operation requirements ........................... 12
P
Periodic maintenance chart ..................... 86
Post-launch checks ................................. 65
Post-operation care ................................. 79
Pre-launch checks ................................... 59
Pre-operation check points ..................... 59
Pre-operation checklist ............................ 57
Primary Identification (PRI-ID) number ...... 1
Pull-up cleats (VX Limited) ....................... 46
R
Raising the reverse gate .......................... 94
Reboarding step ...................................... 44
Recommended equipment ...................... 14
Remote control transmitter check
(VX Deluxe / VX Cruiser / VX Limited) ... 62
Remote control transmitter
(VX Deluxe / VX Cruiser / VX Limited) ... 25
Removable watertight storage
compartment ........................................ 48
RiDE lever................................................. 28
RiDE lever checks .................................... 62
Riding position ......................................... 68
Rustproofing ............................................ 83S
Safe boating rules .................................... 18
Safety equipment check .......................... 64
Seats ........................................................ 43
Shift indicator ........................................... 40
Shift system ............................................. 31
Shift system check ................................... 65
Speedometer ........................................... 38
Start switch .............................................. 27
Starting off ............................................... 75
Starting off from a trailer .......................... 76
Starting the engine on water .................... 68
Steering system ....................................... 28
Steering system checks ........................... 61
Stern drain plug checks ........................... 64
Stern eyes ................................................ 45
Stopping the engine ................................. 69
Stopping the watercraft ........................... 71
Storage compartment checks.................. 63
Storage compartments ............................ 46
Submerged watercraft ............................. 95
Switch checks .......................................... 63
T
Tachometer .............................................. 39
Throttle lever ............................................ 28
Throttle lever checks ................................ 62
Tool kit ..................................................... 85
Towing the watercraft .............................. 95
Transporting on a trailer ........................... 55
Troubleshooting ....................................... 90
Troubleshooting chart .............................. 90
Turning the watercraft .............................. 70
V
Voltmeter .................................................. 42
W
Wakeboarding and water-skiing .............. 17
Water separator ....................................... 29
Water separator check ............................. 59
Watercraft characteristics ........................ 15
Watercraft control functions..................... 25
Watercraft operation functions ................ 31
Watercraft operation modes .................... 33
Y
Yamaha Security System settings ........... 26
UF4G71E0.book Page 98 Wednesday, July 27, 2016 9:32 AM
