YAMAHA VX CRUISER 2021 Repair Manual

Instrument operation
52
EJU46300
Audio system (equipped models)
This model is equipped with an audio system
that can be connected via Bluetooth.
EJU46312Audio control
This model is equipped with an audio control
to operate the audio system.
Power button
Press this button to turn the audio system on.
Play/Pause button
Press this button to play or pause.
Cursor button “ / ”
Press these buttons to skip to the previous or
next track. Cursor button “ / ”
Press these buttons to adjust the volume.
To connect an external device:
(1) Turn on the Bluetooth function of the ex-
ternal device, and then search for this
audio system.
(2) Turn the audio system on by pushing the power button on the audio control.
(3) Select this audio system to connect to it.
To disconnect an external device:
Turn the Bluetooth function of the external
device off.
EJU46320Accessory outlet
There is a 12 V DC outlet located inside the
glove compartment. NOTICE: Do not use an
automotive cigarette lighter or other ac-
cessories that get hot because the outlet
can be damaged.
[ECJ02880]
1 Speaker
1 12V DC outlet
2 USB charger
3 Audio control
4 Cursor button
5 Play/Pause button
6 Power button
11
1
3
65
4
2
112V DC outlet
1
UF4N70E0.book Page 52 Tuesday, October 6, 2020 5:13 PM

Instrument operation
53
EJU46330USB charger
There is a USB charger located inside the
glove compartment. The USB charger can be
used to charge external devices.
1USB charger
1
UF4N70E0.book Page 53 Tuesday, October 6, 2020 5:13 PM

Equipment operation
54
EJU40335
EquipmentEJU42203Seats
The front and rear seats are removable.
Remove the seats to access the engine com-
partment and removable watertight storage
compartment.
To remove the rear seat:
(1) Pull the rear seat latch up, and then lift upthe rear of the seat.
(2) Pull the seat rearward and remove it. To install the rear seat:
(1) Insert the projections on the front of the
seat into the stays on the deck.
(2) Push the rear of the seat down to secure- ly lock it in place.
To remove the front seat:
(1) Remove the rear seat.
(2) Pull the front seat latch up, and then lift up the rear of the seat.
1Seat latch
1
1Seat latch
1
UF4N70E0.book Page 54 Tuesday, October 6, 2020 5:13 PM

Equipment operation
55
(3) Pull the seat rearward and remove it.
To install the front seat:
(1) Insert the projection on the front of theseat into the stay on the deck.
(2) Push the rear of the seat down to secure- ly lock it in place.
(3) Securely install the rear seat in its original position.
EJU31364Handgrip
The handgrip is used when boarding the wa-
tercraft from the water and when the spotter
is facing rearward. WARNING! Do not use
the handgrip to lift the watercraft. The
handgrip is not designed to support the
watercraft’s weight. If the handgrip
breaks, the watercraft could fall, which
could result in severe injury.
[EWJ00022]
EJU37382
Reboarding grip
The reboarding grip is used when boarding
the watercraft from the water.
EJU34866Reboarding step (VX / VX DELUXE /
VX CRUISER / VX LIMITED)
The reboarding step is used to assist in re-
boarding the watercraft from the water.
When boarding the watercraft, push the re-
boarding step down until it stops. The step
1Handgrip
1 Reboarding grip
1
1
UF4N70E0.book Page 55 Tuesday, October 6, 2020 5:13 PM

Equipment operation
56
returns automatically to its original position
when released. WARNING! Do not use the
reboarding step to lift the watercraft. The
reboarding step is not designed to support
the watercraft’s weight. If the reboarding
step breaks, the watercraft could fall,
which could result in severe injury.
[EWJ01212]
VX / VX DELUXE
VX CRUISER / VX LIMITED
ECJ00743
Use the reboarding step only to board the
watercraft in the water. Do not use the re-
boarding step for any other purpose. The
watercraft can be damaged.
EJU34873Bow eye
The bow eye is used to attach a rope to the
watercraft when transporting, mooring, or
towing it in an emergency. (See page 109 for
information on towing the watercraft.)
EJU34882Stern eyes
The stern eyes are used to attach a rope to
the watercraft when transporting or mooring
it.
1 Reboarding step
1 Reboarding step
1
11Bow eye
1 Stern eye
1
1
UF4N70E0.book Page 56 Tuesday, October 6, 2020 5:13 PM

Equipment operation
57
EJU40423Cleat
The cleat is used to attach a ski rope to the
watercraft when pulling a wakeboarder or
water-skier. WARNING! Do not use the
cleat to lift the watercraft. The cleat is not
designed to support the watercraft’s
weight. If the cleat breaks, the watercraft
could fall, which could result in severe in-
jury.
[EWJ01511]
EJU34894
Pull-up cleats (VX CRUISER / VX
LIMITED)
The pull-up cleats are used to attach a rope
to the watercraft when mooring it.
To use a pull-up cleat, pull it up. The pull-up
cleat returns automatically to its original posi-
tion when released. WARNING! Do not use
the pull-up cleats to lift the watercraft. The
pull-up cleats are not designed to support
the watercraft’s weight. If the pull-up cleats break, the watercraft could fall,
which could result in severe injury.
[EWJ00822]
EJU31685
Storage compartments
This watercraft is equipped with the following
storage compartments.
The storage compartments are not designed
to be waterproof. If you carry objects that
must be kept dry, put them in a waterproof
bag.
Make sure that the storage compartments
are closed securely before operating the wa-
tercraft.
EJU45250Bow storage compartment
The bow storage compartment is located un-
der the hood.
1 Cleat
11Pull-up cleat (VX CRUISER / VX LIMITED)
2 Pull-up cleat (VX LIMITED)
2
1
UF4N70E0.book Page 57 Tuesday, October 6, 2020 5:13 PM

Equipment operation
58
To open the bow storage compartment:
Pull the hood latch rearward, and then lift up
the rear of the hood.To close the bow storage compartment:Push the rear of the hood down to securely
lock it in place.
EJU46211Glove compartment
The glove compartment is located in front of
the seat.
TIP:
Make sure the seal of lid is intact, clear and
properly positioned before using.
Make sure the seals around the USB char-
ger and 12V DC outlet are intact and prop-
erly positioned before using.
Completely dry inside of the glove com-
partment and its contents before and after
using.
Make sure nothing is pinches between the
glove compartment and the lid when clos-
ing the glove compartment.
When not in use, the rubber caps for the
USB charger and 12V DC outlet should be
installed to cover the connectors.
1
Hood latch
1 Bow storage compartment
Bow storage compartment:
Capacity:
92.0 L (24.3 US gal, 20.2 Imp.gal)
Load limit: 5.0 kg (11 lb)
1
1
UF4N70E0.book Page 58 Tuesday, October 6, 2020 5:13 PM

Equipment operation
59
To open the glove compartment:
Pull the glove compartment latch up, and
then lift up the lid.To close the glove compartment:Push the lid down to securely lock it in place.
To drain water from the glove compartment:
(1) Remove the drain plug on the bottom of
the glove compartment to drain the wa-
ter.
(2) Securely install the drain plug in it original position.
EJU46011Seat storage compartment
The seat storage compartment is located un-
der the rear seat.
The storage compartment is removable.
To open the seat storage compartment:
(1) Remove the rear seat. (See page 54 forseat removal and installation proce-
dures.)
1Glove compartment latch
1 Glove compartment
Glove compartment:
Capacity:16.5 L (4.4 US gal, 3.6 Imp.gal)
Load limit: 1.5 kg (3 lb)
1
1
1Drain plug
1
UF4N70E0.book Page 59 Tuesday, October 6, 2020 5:13 PM

Equipment operation
60
(2) Push the latch forward, and then lift upthe lid and remove it. To close the seat storage compartment:
(1) Insert the projections on the lid into the
slots on the seat storage compartment.
(2) Push the rear of the lid down.
(3) Securely install the rear seat in its original position.
EJU46030Fire extinguisher holder and cover
The fire extinguisher holder and cover are lo-
cated in the bow storage compartment.
1Lid
2 Latch
1 Seat storage compartment
Seat storage compartment:
Capacity:5.4 L (1.4 US gal, 1.2 Imp.gal)
Load limit:
3.0 kg (7 lb)
2
1
1
UF4N70E0.book Page 60 Tuesday, October 6, 2020 5:13 PM

Equipment operation
61
To use the fire extinguisher holder and cover:
(1) Pull the hood latch rearward, and then liftup the rear of the hood.
(2) Unhook the band and remove the fire ex- tinguisher from the fire extinguisher cov-
er.
(3) Place the fire extinguisher in the fire ex- tinguisher cover, and then securely fas-
ten the fire extinguisher with the band.
(4) Push the rear of the hood down to se- curely lock it in place. Make sure that the hood is securely closed before using the
watercraft.
1
Hood latch
1 Fire extinguisher holder and cover
2 Band
1
2
1
