General and important labels
9
The following CE marking is located on the back of the remote control transmitter.
UF2W70E0.book Page 9 Tuesday, December 8, 2015 9:03 AM

Description
23
13 12 4
35 9 10 9
7
6 8
1112
1RiDE lever (page 31)
2Start switch (page 27)
3Electric trim up switch (page 33)
4Engine shut-off switch (page 27)
5Clip (page 27)
6Engine shut-off cord (lanyard) (page 27)
7Engine stop switch (page 27)
8Electric trim down switch (page 33)
9Rearview mirror
10Multifunction information center (page 37)
11Throttle lever (page 28)
12Glove compartment (page 47)
13Remote control transmitter (page 25)
UF2W70E0.book Page 23 Tuesday, December 8, 2015 9:03 AM

Control function operation
25
EJU31026
Watercraft control functionsEJU43690Remote control transmitter
The Yamaha Security System and Low RPM
Mode settings can be selected by operating
the remote control transmitter. (See page 26
for Yamaha Security System setting proce-
dures and page 35 for Low RPM Mode acti-
vation procedures.)
Since the watercraft is programmed to rec-
ognize the internal code from this transmitter
only, the settings can only be selected with
this transmitter.
If you accidentally lose your remote control
transmitter or if it is not operating properly,
contact a Yamaha dealer.
When operating the watercraft, always keep
the transmitter with you, such as by storing itin the transmitter holder in the glove compart-
ment, so that it is not lost.
NOTICE
ECJ00753
The remote control transmitter is not
completely waterproof. Do not sub-
merge the transmitter or operate it un-
derwater. If the transmitter is
submerged, dry it with a soft, dry cloth,
and then check that it is operating prop-
erly. If the transmitter is not operating
properly, contact a Yamaha dealer.
Keep the remote control transmitter
away from high temperatures and do
not place it in direct sunlight.
Do not drop the remote control trans-
mitter, subject it to strong shocks, or
place any heavy items on it.
Use a soft, dry cloth to clean the remote
control transmitter. Do not use deter-
gent, alcohol, or other chemicals.
Do not attempt to disassemble the re-
mote control transmitter yourself. Oth-
erwise, the transmitter may not operate
properly. If the transmitter needs a new
battery, contact a Yamaha dealer. Refer
to local hazardous waste regulations
when disposing of transmitter batteries.
1Remote control transmitter
1Transmitter holder
1
UF2W70E0.book Page 25 Tuesday, December 8, 2015 9:03 AM

Control function operation
26
EJU31385Yamaha Security System
The Yamaha Security System functions to
help prevent unauthorized use or theft of the
watercraft. The lock and unlock modes of the
security system can be selected by operating
the remote control transmitter that is included
with this watercraft. The engine cannot be
started if the lock mode of the security sys-
tem is selected. The engine can only be start-
ed if the unlock mode is selected. (See page
25 for information on the remote control
transmitter.)
TIP:
The Yamaha Security System settings can
only be selected while the engine is stopped.
EJU36776Yamaha Security System settings
The Yamaha Security System settings will be
confirmed by the number of beeps when the
remote control transmitter is operated, and
by the “UNLOCK” indicator light of the multi-
function information center. (See page 37 for
information on the multifunction information
center.)
TIP:
The beeper sounds two times for the nor-
mal operation mode or three times for the
Low RPM Mode. (See page 35 for Low
RPM Mode activation procedures.)
If the remote control transmitter is operated
while the multifunction information centeris in the standby state, the center will per-
form the initial operation, and then the set-
ting is selected.
To select the lock mode:
Push the lock button on the remote control
transmitter briefly. The beeper sounds once
and the “UNLOCK” indicator light blinks
once, then goes off. This indicates the lock
mode is selected.
To select the unlock mode:
Push the “L-Mode” (unlock) button on the re-
mote control transmitter briefly. The beeper
sounds two or three times and the “UN-
LOCK” indicator light blinks two or three
times, then comes on. This indicates the un-
lock mode is selected.
Number of
beepsYamaha Security
System mode“UN-
LOCK” in-
dicator
light
Lock Goes off
Unlock
(normal operation
mode)Comes
on
Unlock
(Low RPM Mode)Comes
on
1Lock button
2“UNLOCK” indicator light
1“L-Mode” (unlock) button
2“UNLOCK” indicator light
21
2L-Mode1
UF2W70E0.book Page 26 Tuesday, December 8, 2015 9:03 AM

Watercraft operation
35
EJU40001
Watercraft operation modes
EJU36787Low RPM Mode
The Low RPM Mode is a function that limits
the maximum engine speed to approximately
70% of the maximum engine speed in the
normal mode.
The Low RPM Mode can only be activated
and deactivated by operating the remote
control transmitter that is included with this
watercraft. (See page 25 for information on
the remote control transmitter.)
TIP:
The Low RPM Mode can only be activated
when the engine is stopped in the unlock
mode of the Yamaha Security System.
Activating and deactivating the Low RPM
Mode
Activation of the Low RPM Mode will be con-
firmed by the number of beeps when the re-
mote control transmitter is operated, and by
the “L-MODE” indicator light of the multifunc-
tion information center. (See page 37 for in-
formation on the multifunction information
center.)
TIP:
If the remote control transmitter is operated
while the multifunction information center is
in the standby state, the center performs the
initial operation, and then the setting is se-
lected.
To activate the Low RPM Mode:
Push the “L-Mode” (unlock) button on the re-
mote control transmitter for more than 4 sec-
onds. Once the beeper sounds three times
and the “UNLOCK” indicator light blinks
three times, then comes on, the “L-MODE”
indicator light comes on and the Low RPM
Mode is activated.
TIP:
If the Low RPM Mode is activated immediate-
ly after the information display turns off, the
“L-MODE” indicator light will not come on.1Remote control transmitter
Number of
beepsLow RPM Mode
operation“L-
MODE”
indicator
light
ActivatedComes
on
Deactivated Goes off
UF2W70E0.book Page 35 Tuesday, December 8, 2015 9:03 AM

Pre-operation checks
57
EJU31982
WARNING
EWJ00412
Failure to inspect or maintain the watercraft properly increases the possibility of an ac-
cident or damage to the watercraft. Do not operate the watercraft if you find any prob-
lem. If a problem cannot be corrected by the procedures provided in this manual, have
the watercraft inspected by a Yamaha dealer.
EJU41234Pre-operation checklist
Before using this watercraft, be sure to perform the checks in the following checklist.
ITEM ROUTINE PAGE
PRE-LAUNCH CHECKS
Engine compartmentVentilate the engine compartment.
Check inside the engine compartment for damage.59
Fuel systemCheck the fuel system for leakage.
Check the fuel level in the fuel tank.59
Water separatorCheck the water separator for water. 60
Engine unitCheck the exterior of the engine unit for damage. 60
Engine oil levelCheck the engine oil level. 60
Bilge waterCheck the engine compartment for bilge water. 60
BatteryCheck the battery connections and electrolyte level. 60
Steering systemCheck the steering system for proper operation. 61
RiDE leverCheck the RiDE lever for proper operation. 62
Throttle leverCheck the throttle lever for proper operation. 62
Remote control transmitterCheck the remote control transmitter for proper op-
eration.62
Engine shut-off cord (lan-
yard)Check the engine shut-off cord (lanyard) for dam-
age.62
SwitchesCheck the start switch, engine stop switch, and en-
gine shut-off switch for proper operation.63
Storage compartmentsCheck the storage compartments for damage and
water.63
Fire extinguisher holder,
cover, and bandCheck the fire extinguisher holder, cover, and band
for damage.63
Fire extinguisherCheck the condition of the fire extinguisher. 64
Safety equipmentCheck that safety equipment meeting the applica-
ble regulations is on board.64
Hull and deckCheck the hull and deck for damage. 64
Jet intakeCheck the jet intake for damage and clogging. 64
Jet thrust nozzle and re-
verse gateCheck the jet thrust nozzle and reverse gate for
damage.64
Stern drain plugsCheck the stern drain plugs for damage and foreign
material and check that they are securely installed.64
UF2W70E0.book Page 57 Tuesday, December 8, 2015 9:03 AM

Pre-operation checks
62
right and left fully turned positions of the jet
thrust nozzle.
EJU43212RiDE lever checks
Operate the RiDE lever several times to make
sure that operation is smooth throughout the
whole range. Also, make sure that the RiDElever returns automatically to its fully closed
position when released.
EJU42181Throttle lever checks
Operate the throttle lever several times to
make sure that operation is smooth through-
out the whole range. Also, make sure that the
throttle lever returns automatically to its fully
closed (idle) position when released.
EJU40113Remote control transmitter check
Make sure that the remote control transmitter
operates properly. (See page 26 for Yamaha
Security System setting procedures and
page 35 for Low RPM Mode activation pro-
cedures.)
EJU32664Engine shut-off cord (lanyard) check
Make sure that the engine shut-off cord (lan-
yard) is not damaged. If the cord is damaged,
replace it. WARNING! Never try to repair
the engine shut-off cord (lanyard) or tie it
together. The engine shut-off cord (lan- Difference between fully turned posi-
tions of jet thrust nozzle (distances A
and B):
Maximum 5 mm (0.20 in)
UF2W70E0.book Page 62 Tuesday, December 8, 2015 9:03 AM

Index
101
Low RPM Mode ....................................... 35
Lubrication ............................................... 84
M
Main components, location of ................. 21
Maintenance ............................................ 85
Manufactured date label ............................ 2
Model information ...................................... 2
Multifunction information center .............. 37
Multifunction information center check ... 65
O
Oil pressure warning ................................ 40
Operating in weeded areas ...................... 78
Operating the watercraft .......................... 70
Operating the watercraft in reverse or
neutral ................................................... 73
Operating your watercraft ........................ 68
Operation requirements ........................... 12
P
Periodic maintenance chart ..................... 87
Post-launch checks ................................. 65
Post-operation care ................................. 80
Pre-launch checks ................................... 59
Pre-operation check points ..................... 59
Pre-operation checklist ............................ 57
Primary Identification (PRI-ID) number ...... 1
R
Raising the reverse gate .......................... 95
Reboarding step (VXR) ............................. 44
Recommended equipment ...................... 14
Remote control transmitter ...................... 25
Remote control transmitter check ........... 62
RiDE lever................................................. 28
RiDE lever checks .................................... 62
Riding position ......................................... 69
Rustproofing ............................................ 84
S
Safe boating rules .................................... 18
Safety equipment check .......................... 64
Seats ........................................................ 43
Shift indicator ........................................... 39
Shift system ............................................. 31
Shift system check................................... 66
Speedometer ........................................... 37
Start switch .............................................. 27
Starting off ............................................... 76Starting off from a trailer .......................... 77
Starting the engine on water .................... 69
Steering system ....................................... 28
Steering system checks ........................... 61
Stern drain plug checks ........................... 64
Stern eyes ................................................ 45
Stopping the engine ................................. 70
Stopping the watercraft ........................... 72
Storage compartment checks.................. 63
Storage compartments ............................ 46
Submerged watercraft ............................. 98
Switch checks .......................................... 63
T
Tachometer .............................................. 38
Throttle lever ............................................ 28
Throttle lever checks ................................ 62
Tool kit ..................................................... 85
Towing the watercraft .............................. 98
Transporting on a trailer ........................... 55
Trim indicator ........................................... 39
Trim indicator check ................................ 67
Troubleshooting ....................................... 91
Troubleshooting chart .............................. 91
Turning the watercraft .............................. 71
V
Voltmeter .................................................. 41
W
Wakeboarding and water-skiing .............. 17
Water separator ....................................... 29
Water separator check ............................. 60
Watercraft characteristics ........................ 15
Watercraft control functions..................... 25
Watercraft operation functions ................ 31
Watercraft operation modes .................... 35
Watertight storage compartment ............. 48
Y
Yamaha Security System ......................... 26
Yamaha Security System settings ........... 26
UF2W70E0.book Page 101 Tuesday, December 8, 2015 9:03 AM
