5. Remove the bulb holder cover.
6. Turn the bulb holder counterclockwise
and remove the defective bulb.
WARNING
The headlight bulb is hot when it is on and im-
mediately after it is turned off. Wait for the
bulb to cool before touching or removing it.
You can be burned, or a fire could start if thebulb touches something flammable.
1. Bulb holder cover
1. Cache de la fixation d’ampoule
1. Cubierta del portabombillas1. Defective bulb
1. Ampoule défectueuse
1. Lámpara defectuosa

8-89
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350-8.frame
EL
7. Put a new bulb into position and secure it
in place with the bulb holder.
8. Install the bulb holder cover.CAUTION:Make sure the bulb holder cover is securely fit-
ted over the bulb holder and seated againstthe reflector.
9. Install the headlight assembly and the
guard.
Adjust the headlight beam if necessary.
EBU00409
Headlight beam adjustmentCAUTION:It is advisable to have a Yamaha dealer makethis adjustment.
1. Vertical adjustment:
To raise the beam, turn the adjusting
screw clockwise.
To lower the beam, turn the screw coun-
terclockwise.
1. Vertical adjusting screw (´ 2)
1. Vis de réglage vertical (´ 2)
1. Tornillo de ajuste vertical (´ 2)1. Bulb holder cover 2. Bulb holder
3. Reflector
1. Cache de la fixation d’ampoule 2. Fixation d’ampoule
3. Réflecteur
1. Cubierta del portabombillas 2. Portabombillas
3. Reflector

8-91
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350-8.frame
EL
EBU00413
Troubleshooting
Although Yamaha machines receive a rigid in-
spection before shipment from the factory,
trouble may occur during operation.
Any problem in the fuel, compression, or igni-
tion systems can cause poor starting and loss
of power. The troubleshooting chart describes
a quick, easy procedure for making checks. If
your machine requires any repair, take it to a
Yamaha dealer.
The skilled technicians at a Yamaha dealership
have the tools, experience, and know-how to
properly service your machine. Use only genu-
ine Yamaha parts on your machine. Imitation
parts may look like Yamaha parts, but they are
often inferior. Consequently, they have a short-
er service life and can lead to expensive repair
bills.
WARNING
Do not smoke when checking the fuel system.
Fuel can ignite or explode, causing severe inju-
ry or property damage. Make sure there are no
open flames or sparks in the area, including pi-lot lights from water heaters or furnaces.

9-9
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350-
EL
5. Block up the frame to raise all wheels off
the ground.
6. Tie a plastic bag over the exhaust pipe
outlet to prevent moisture from entering.
7. If storing in a humid or salt-air atmo-
sphere, coat all exposed metal surfaces
with a light film of oil. Do not apply oil to
any rubber parts or the seat cover.
8. Remove the battery and charge it. Store it
in a dry place and recharge it once a
month. Do not store the battery in an ex-
cessively warm or cold place (less than
0 ˚C or more than 30 ˚C).
NOTE:

Make any necessary repairs before storing the
machine.

10-5
Yuki_Data:Yuki_data:Yuki:Yuki_1:ATV:HM00B067_YFM350X-60:YFM350-SPEC-E.frame
EL
Shock absorber:
Front
RearCoil spring / Oil damper
Coil spring / Gas-Oil damper
Wheel travel:
Front
Rear200 mm
200 mm
Electrical:
Ignition system
Generator system
Battery type/voltage, capacityC.D.I.
C.D.I. Magneto
GM12CZ-4A-2/12V, 12AH
Headlight type: Krypton bulb
Bulb voltage, wattage
´
quantity:
Headlight
Taillight
Indicator light:
Neutral
Reverse12V, 30W/30W
´
2
12V, 3.8W
´
1
12V, 3.4W
´
1
12V, 3.4W
´
1 MODEL YFM350X
