8-65
EBU00570
Cable inspection and lubrication
WARNING
Inspect cables frequently and replace if dam-
aged. Corrosion can result when the outer cov-
ering of control cables becomes damaged.
Cables can also become frayed or kinked. Op-
eration of controls could be restricted, which
could cause an accident or injury.Lubricate the inner cables and the cable ends. If
the cables do not operate smoothly, ask a Yamaha
dealer to replace them.
EBU00737
Brake and shift pedal/brake and clutch lever lu-
brication
Lubricate the pivoting parts of each lever and pedal.Recommended lubricant:
Engine oil
Recommended lubricant:
Lithium-soap-based grease
(all-purpose grease)
U5NF61.book Page 65 Wednesday, June 13, 2001 5:18 PM

8-99
EBU00440*
Troubleshooting chart1. Fuel
Check if there is fuel
in the fuel tank.There is fuel.Turn the fuel
cock to “OFF”.No fuel.Fuel cock
clogged.
Clean fuel
cock. Some fuel.Turn the fuel
cock to “RES”.Restart engine.
No fuel.Supply fuel.
2. Compression
Use the electric starter
to see if there is
compression.There is compression.
Compression normal.
No compression.Ask a Yamaha dealer to
inspect.
3. Ignition
Remove plug and
check electrodes.WetWipe clean with dry cloth.
DryAttach plug cap and
ground to chassis.Use the
electric starter.Spark good.Ignition system
normal.
Spark weak.
Adjust plug gap
or replace plug. No spark.
Ask a Yamaha dealer to
inspect. 4. Battery
Use the electric
starter.Engine turns over
quickly.Battery good.
Engine turns over
slowly.Check fluid, recharge,
check connections.Check fuel
flow.
Turn the fuel
cock to “ON”.
Remove the
fuel hose.
U5NF61.book Page 99 Wednesday, June 13, 2001 5:18 PM

9-1
EBU00418
CLEANING AND STORAGE
A. CLEANING
Frequent, thorough cleaning of your machine will
not only enhance its appearance but will improve
its general performance and extend the useful life
of many components.
1. Before cleaning the machine:
a. Block off the end of the exhaust pipe to pre-
vent water entry. A plastic bag and strong
rubber band may be used.
b. Make sure the spark plug and all filler caps
are properly installed.
2. If the engine case is excessively greasy, ap-
ply degreaser with a paint brush. Do not ap-
ply degreaser to the chain, sprockets or
wheel axles.
3. Rinse the dirt and degreaser off with a garden
hose. Use only enough pressure to do the
job.
U5NF61.book Page 1 Wednesday, June 13, 2001 5:18 PM

9-5
8. Automotive type wax may be applied to all
painted and chrome plated surfaces. Avoid
combination cleaner-waxes. Many contain
abrasives which may mar the paint or protec-
tive finish. When finished, start the engine
and let it idle for several minutes.
WARNING
Wet brakes may have reduced stopping ability,
increasing the chance of an accident. Test the
brakes after washing. Apply the brakes several
times at slow speeds to let friction dry out the
linings.
U5NF61.book Page 5 Wednesday, June 13, 2001 5:18 PM

9-7
EBU00526
B. STORAGE
Long term storage (60 days or more) of your ma-
chine will require some preventive procedures to
guard against deterioration. After thoroughly
cleaning the machine, prepare for storage as fol-
lows:
1. Fill the fuel tank with fresh fuel and add fuel
stabilizer (if available).NOTE:Use of fuel stabilizer eliminates the need to drain
the fuel system. Consult a Yamaha dealer if the
fuel system is to be drained instead.2. Remove the spark plug, pour about one ta-
blespoon of SAE 10W30 or 20W40 motor oil
in the spark plug hole and reinstall the spark
plug. Ground the spark plug wire and turn the
engine over several times to coat the cylinder
wall with oil.
3. Clean the drive chain thoroughly and lubri-
cate it. (See page 8-63.)
4. Lubricate all control cables.
U5NF61.book Page 7 Wednesday, June 13, 2001 5:18 PM

10-1
EBU00428
SPECIFICATIONS
MODEL YFM350X
Dimension:
Overall length
Overall width
Overall height
Seat height
Wheel base
Minimum ground clearance
Minimum turning radius1,840 mm
1,080 mm
1,080 mm
765 mm
1,200 mm
125 mm
3,500 mm
Basic weight:
With oil and full fuel tank 191 kg
Engine:
Type
Cylinder arrangement
Displacement
Bore
× Stroke
Compression ratio
Starting system
Lubrication systemAir-cooled, 4-stroke, SOHC
Forward inclined single cylinder
348 cm
3
83.0
× 64.5 mm
9.2 : 1
Electric starter
Wet sump
U5NF61.book Page 1 Wednesday, June 13, 2001 5:18 PM

10-2
10
Engine oil:
Type
Recommended engine oil classification: API Service SE, SF, SG type or higherMODEL YFM350X
-20˚-10˚0˚
10˚20˚30˚40˚50˚C
10W/30
15W/4020W/4020W/50
10W/40
5W/30
CAUTION:
Be sure to use motor oils that do not contain anti-
friction modifiers. Passenger car motor oils (often
labeled “ENERGY CONSERVING II”) contain anti-
friction additives which will cause clutch and/or
starter clutch slippage, resulting in reduced com-
ponent life and poor engine performance.
U5NF61.book Page 2 Wednesday, June 13, 2001 5:18 PM

10-3
Quantity:
Periodic oil change (engine oil)
Periodic oil change
(engine oil with oil filter replacement)
Total amount2.4 L
2.5 L
3.2 L
Air filter: Wet type element
Fuel:
Type
Tank capacity
Reserve amountREGULAR UNLEADED GASOLINE ONLY
9.0 L
1.9 L
Carburetor:
Type/manufacturer BTM36SH / MIKUNI
Spark plug:
Type/manufacturer
GapDR8EA / NGK
0.6 ~ 0.7 mm
Clutch:
Type
OperationWet, Multiple-disc
Left hand operation
Transmission:
Primary reduction system
Primary reduction ratio
Secondary reduction system
Secondary reduction ratio
Transmission type
OperationSpur gear
76/24 (3.166)
Chain drive
40/13 (3.076)
Constant mesh, 6-speed forward, 1-speed reverse
Left foot operation MODEL YFM350X
