set clock YAMAHA WOLVERINE 2018 Owners Manual

4-6
4
EBU31386Multi-function meter unitThe multi-function meter unit is equipped with
the following:
speedometer
 odometer
 two tripmeters
 clock 
hour meter
 voltage display
 fuel gauge
 error code display
Speedometer
The speedometer shows the vehicle’s travel-
ing speed. The speedometer can be set to
“mph” or “km/h”. This also changes the
odometer and tripmeter units between miles
and kilometers. To change the display be-
tween “mph” and “km/h”, turn the key to “ ”
(off), then while holding the “SELECT” button
pushed, turn the key to “ ” (on).1. “CLOCK” button
2. “RESET” button
3. “SELECT” button
4. Speedometer
5. Fuel gauge
6. Clock/Hour meter/Voltage display
7. Odometer/Tripmeter A/Tripmeter B321
4
5
6
7
UB3D7AE0.book Page 6 Tuesday, November 7, 2017 9:38 AM

4-8
4
Clock, hour meter and voltage display
The clock displays time in 12-hour format.
The hour meter shows the total time the en-
gine has been running. The voltage display
shows the battery voltage.
Push the “CLOCK” button to switch between
the clock “CLOCK”, the hour meter mode
“HOUR” and the voltage display
mode “ ” in the following order:
CLOCK → HOUR → → CLOCK To set the clock
1. Set the display to the clock.
2. Push both the “SELECT” button and
“RESET” button for three seconds. The
hour digits will start flashing.
3. Push the “RESET” button to set the hours.
4. Push the “SELECT” button, and the mi-
nute digits will start flashing.
5. Push the “RESET” button to set the minu- tes.
6. Push the “SELECT” button and then re- lease it to start the clock.
1. “SELECT” button
2. “RESET” button
3. “CLOCK” button
4. Clock/Hour meter/Voltage display
4
123UB3D7AE0.book Page 8 Tuesday, November 7, 2017 9:38 AM
