SPECIFICATIONS
8-3
2
3
4
5
6
789
Front turn signal light: 12 V, 10.0 W  2
Rear turn signal light:
12 V, 10.0 W  2
Auxiliary light: 12 V, 5.0 W  1
License plate light: 12 V, 5.0 W  1
Meter lighting:
EL (Electroluminescent)
Neutral indicator light: 12 V, 1.7 W  1
High beam indicator light: 12 V, 1.7 W  1
Turn signal indicator light:
12 V, 1.7 W  1
Fuel level warning light: LED
Engine trouble warning light: 12 V, 1.7 W  1Fuses:Main fuse:
15.0 A
