SPECIFICATIONS
8-2
2
3
4
5
6
789
2nd: 1.733 (26/15)
3rd:
1.313 (21/16)
4th: 1.050 (21/20)
5th: 0.840 (21/25)
Chassis:Frame type: Semi double cradle
Caster angle: 27.00 
Trail:
115 mm (4.5 in)Front tire:Type: With tube
Size:
80/100-21M/C 51P
Manufacturer/model: BRIDGESTONE/GRITTY-ED03 ERear tire:Type:
With tube
Size: 120/90-18M/C 65P
Manufacturer/model: BRIDGESTONE/GRITTY-ED04 E
Maximum load:
90 kg (198 lb)
* (Total weight of rider, cargo and accesso- ries)
Tire air pressure (measured on cold
tires):Loading condition: 0–90 kg (0–198 lb)
Front:
150 kPa (1.50 kgf/cm
2, 22 psi)
Rear:
200 kPa (2.00 kgf/cm2, 29 psi)
Front wheel:Wheel type: Spoke wheel
Rim size:
21x1.60Rear wheel:Wheel type: Spoke wheel
Rim size:
18x2.15Front brake:Type: Single disc brake
Operation:
Right hand operation
Specified brake fluid: DOT 4Rear brake:Type:
Single disc brake
Operation: Right foot operation
Specified brake fluid: DOT 4
Front suspension:Type: Telescopic fork
Spring/shock absorber type: Coil spring/oil damper
Wheel travel: 300.0 mm (11.81 in)Rear suspension:Type: Swingarm (link suspension)
Spring/shock absorber type: Coil spring/gas-oil damper
Wheel travel:
299.0 mm (11.77 in)Electrical system:Ignition system: TCI
Charging system:
AC magnetoBattery:Model: YTZ7S(F)
Voltage, capacity:
12 V, 6.0 AhHeadlight:Bulb type: Halogen bulbBulb voltage, wattage  quantity:Headlight:
12 V, 35.0 W/35.0 W  1
Tail/brake light: LED
Front turn signal light:
12 V, 10.0 W  2
1DX-9-E2.book 2 ページ ２０１３年２月２６日　火曜日　午後２時３４分

SPECIFICATIONS
8-3
1
2
3
4
5
6
78
9
Rear turn signal light: 12 V, 10.0 W  2
Auxiliary light:
12 V, 5.0 W  1
License plate light: 12 V, 5.0 W  1
Meter lighting: EL (Electroluminescent)
Neutral indicator light:
12 V, 1.7 W  1
High beam indicator light: 12 V, 1.7 W  1
Turn signal indicator light: 12 V, 1.7 W  1
Fuel level warning light:
LED
Engine trouble warning light: 12 V, 1.7 W  1Fuse:Main fuse:
15.0 A
1DX-9-E2.book 3 ページ ２０１３年２月２６日　火曜日　午後２時３４分

9-1
2
3
4
5
6
7
89
CONSUMER INFORMATION
EAU48612
Identification numbers Record the vehicle identification num-
ber and model label information in the
spaces provided below for assistance
when ordering spare parts from a
Yamaha dealer or for reference in case
the vehicle is stolen.
VEHICLE IDENTIFICATION
NUMBER:
MODEL LABEL INFORMATION:
EAU26400
Vehicle identification number
The vehicle identification number is
stamped into the steering head pipe.
Record this number in the space pro-
vided.TIPThe vehicle identification number is
used to identify your motorcycle and
may be used to register your motorcy-
cle with the licensing authority in yourarea.
EAU26460
Model label
The model label is affixed to the loca-
tion shown. Record the information on
this label in the space provided. This in-
formation will be needed when ordering
spare parts from a Yamaha dealer.
1. Vehicle identification number
1
1. Model label
1
1DX-9-E2.book 1 ページ ２０１３年２月２６日　火曜日　午後２時３４分

INDEXAAir filter element and check hose, cleaning .................................................6-14
Auxiliary light bulb, replacing ...................6-35BBattery......................................................6-30
Brake and clutch levers, checking and lubricating ..............................................6-27
Brake fluid, changing ...............................6-24
Brake fluid level, checking .......................6-23
Brake lever .................................................3-8
Brake lever free play, checking ................6-21
Brake light switches .................................6-22
Brake pedal ................................................3-9
Brake pedal, checking and lubricating .....6-28CCables, checking and lubricating .............6-27
Care ...........................................................7-1
Catalytic converter ...................................3-11
Clutch lever ................................................3-8
Clutch lever free play, adjusting ...............6-20
Coolant.....................................................6-12DDimmer switch ...........................................3-7
Drive chain, cleaning and lubricating .......6-26
Drive chain slack ......................................6-25EEngine break-in ..........................................5-4
Engine idling speed..................................6-17
Engine oil and oil filter element ..................6-8
Engine, starting a warm .............................5-3
Engine stop switch .....................................3-7
Engine trouble warning light.......................3-2
FFront and rear brake pads, checking ....... 6-23
Front fork, adjusting ................................. 3-14
Front fork, bleeding.................................. 3-15
Front fork, checking ................................. 6-29
Fuel.......................................................... 3-10
Fuel consumption, tips for reducing........... 5-4
Fuel level warning light .............................. 3-2
Fuel tank breather hose........................... 3-11
Fuel tank cap ............................................. 3-9
Fuse, replacing ........................................ 6-32HHandlebar switches ................................... 3-7
Headlight bulb, replacing ......................... 6-32
High beam indicator light ........................... 3-2
Horn switch ................................................ 3-7IIdentification numbers ............................... 9-1
Ignition circuit cut-off system ................... 3-19
Indicator lights and warning lights ............. 3-1KKickstarter................................................ 3-12LLicense plate light bulb, replacing ........... 6-35MMain switch ................................................ 3-1
Maintenance and lubrication, periodic ....... 6-4
Maintenance, emission control system...... 6-3
Matte color, caution ................................... 7-1
Model label ................................................ 9-1
Multi-function display ................................. 3-2NNeutral indicator light ................................. 3-1
PPanel, removing and installing .................. 6-7
Parking ...................................................... 5-5
Part locations ............................................ 2-1SSafety information ..................................... 1-1
Seat ......................................................... 3-13
Shifting ...................................................... 5-3
Shift pedal ................................................. 3-8
Shift pedal, checking ............................... 6-22
Shock absorber assembly, adjusting ...... 3-16
Sidestand ................................................ 3-18
Sidestand, checking an d lubricating........ 6-28
Spark plug, checking ................................. 6-7
Specifications ............................................ 8-1
Starter knob............................................. 3-12
Starting a cold engine ............................... 5-1
Start switch................................................ 3-7
Steering, checking................................... 6-30
Steering lock ........................................... 3-13
Storage...................................................... 7-3
Supporting the motorcycle ...................... 6-36
Swingarm pivots, lubricating ................... 6-29TTail/brake light ......................................... 6-34
Throttle grip and cable, checking and lubricating ............................................. 6-27
Throttle grip free play, checking .............. 6-17
Tires ........................................................ 6-18
Tool kit....................................................... 6-2
Troubleshooting ...................................... 6-40
Troubleshooting charts............................ 6-41
