IMPORTANT MANUAL INFORMATION
EAU10133
Particularly important information is distinguished in this manual by the following notations:
*Product and specifications are subject to change without notice.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury
or death.
A WARNING indicates a hazardous situation wh
ich, if not avoided, could result in
death or serious injury.
A NOTICE indicates special precautions that must be taken to avoid damage to the
vehicle or other property.
A TIP provides key information to make procedures easier or clearer.
WARNING
NOTICETIP
1DX-9-E2.book 1 ページ ２０１３年２月２６日　火曜日　午後２時３４分

INSTRUMENT AND CONTROL FUNCTIONS
3-13
1
23
4
5
6
7
8
9
EAU53100
Steering lock To lock the steering1. Turn the handlebar all the way to the left.
2. Insert the key into the steering lock under the steering head pipe, and
then turn it 1/2 turn in either direc-
tion.
3. Check that the steering is locked, and then remove the key from the
lock.
To unlock the steering 1. Insert the key into the steering lock.
2. Turn the key 1/2 turn in either di- rection.
3. Remove the key. WARNING!
Never ride with the key inserted
into the steering lock, which
may result in loss of control and
an accident.
[EWA16160]

EAU53200
Seat To remove the seat
Remove the bolts, and then slide the
seat to the rear and pull upward.
1. Steering lock
1
1. Bolt
1. Bolt
11
