EAU24331
License plate lightIf the license plate light does not come
on, have a Yamaha dealer check the
electrical circuit or replace the bulb.
EAU25882
TroubleshootingAlthough Yamaha scooters receive a
thorough inspection before shipment
from the factory, trouble may occur dur-
ing operation. Any problem in the fuel,
compression, or ignition systems, for
example, can cause poor starting and
loss of power.
The following troubleshooting charts
represent quick and easy procedures
for checking these vital systems your-
self. However, should your scooter re-
quire any repair, take it to a Yamaha
dealer, whose skilled technicians have
the necessary tools, experience, and
know-how to service the scooter prop-
erly.
Use only genuine Yamaha replace-
ment parts. Imitation parts may look like
Yamaha parts, but they are often inferi-
or, have a shorter service life and can
lead to expensive repair bills.
WARNING
EWA15142
When checking the fuel system, do
not smoke, and make sure there are
no open flames or sparks in the ar-
ea, including pilot lights from water heaters or furnaces. Gasoline or
gasoline vapors can ignite or ex-
plode, causing severe injury or
property damage.
U53BE1E0 32 ページ ２０１５年９月１５日　火曜日　午後１時４８分

8-1
1
2
3
4
5
6
78
9
10
11
12
Specifications
EAU72940
Dimensions:Overall length: 1990 mm (78.3 in)
Overall width: 690 mm (27.2 in)
Overall height: 1135 mm (44.7 in)
Seat height:
785 mm (30.9 in)
Wheelbase: 1385 mm (54.5 in)
Ground clearance: 140 mm (5.51 in)Weight:Curb weight:142 kg (313 lb)Engine:Combustion cycle:
4-stroke
Cooling system: Liquid cooled
Valve train: SOHC
Number of cylinders:
Single cylinder
Displacement: 125 cm
3
Bore  stroke:
52.0  58.7 mm (2.05  2.31 in)
Compression ratio:
11.0 : 1
Starting system: Electric starter Lubrication system:
Wet sump
Engine oil:Recommended brand:YAMALUBE
Type: SAE 10W-40
Recommended engine oil grade:
API service SG type or higher, JASO stan-
dard MA or MB
Engine oil quantity:
Periodic oil change:1.10 L (1.16 US qt, 0.97 Imp.qt)Final transmission oil:Type:SAE 10W-30 type SE motor oil
Quantity: 0.20 L (0.21 US qt, 0.18 Imp.qt)
Coolant reservoir (up to the maximum level
mark):
0.25 L (0.26 US qt, 0.22 Imp.qt)
Radiator (including all routes):
0.56 L (0.59 US qt, 0.49 Imp.qt)Air filter:Air filter element:Oil-coated paper element
V-belt filter element:
Dry elementFuel:Recommended fuel:Regular unleaded gasoline only
Fuel tank capacity:
8.0 L (2.1 US gal, 1.8 Imp.gal)
Fuel injection:Throttle body: ID mark:52S1 01Spark plug(s):Manufacturer/model: NGK / CPR9EA-9
Spark plug gap: 0.8–0.9 mm (0.031–0.035 in)Clutch:Clutch type:Dry, centrifugal automaticTransmission:Primary reduction ratio:
1.000
Final drive: Gear
Secondary reduction ratio: 10.320 (46 / 13) × (35 / 12)
Transmission type:
V-belt automatic
Gear ratio:Chassis:Frame type: Underbone
Caster angle: 23.8 
Trail:
84 mm (3.3 in)Front tire:Type:Tubeless
Size:
100 / 80 - 16M/C 50P
